Summary of Contents for DTS DIVE N Series

  • Page 2 Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S . D.T.S.
  • Page 3 INDEX: 1- SYMBOLS ........................ 4 2- GENERAL WARNING ....................5 3- GENERAL WARRANTY CONDITIONS ..............5 4- TECHNICAL FEATURES ..................5 5- ACCESSORIES ......................9 6- IMPORTANT SAFETY INFORMATION ..............11 6.1 Fire prevention ....................11 6.2 Prevention of electric shock ................11 6.3 Safety.........................
  • Page 4 1- SYMBOLS Graphic symbols used on this manual: THIS SYMBOL INDICATES A HOT SURFACE THIS SYMBOL INDICATES ELECTRICSHOCK RISK THIS SYMBOL INDICATES GENERAL RISK THIS SYMBOL INDICATES THE MAXIMUM OPERATING AMBIENT TEMPERATURE THIS SYMBOL INDICATES THE MINIMUM DISTANCE FROM THE ILLUMINATED OBJECTS THIS SYMBOL MEANS “DO NOT STARE AT THE OPERATING LIGHT...
  • Page 5 2- GENERAL WARNING Read the instruction contained in this user manual carefully, as they give important information regarding safety during installation, use and maintenance. The unit is not for household use and must be installed by a qualified electrician or experienced person.
  • Page 6 Connections End-stripped 8-pole cable Operating temperature + 1° / + 45°C Storage temperature -40° / + 85°C Physical IP68 Housing: Bronze / Stainless steel 316 Weight: 3.7 Kg Beware Underwater installation only allowed Never make the joints of the cables in water Certifications...
  • Page 7 Product codes: 03.LIB100E99FC25 DIVE 12 N FC MF 48VDC IP68 03.LIB100E99FC10 DIVE 12 N FC SP 48VDC IP68 03.LIB100E99FC40 DIVE 12 N FC WF 48VDC IP68 03.LIB100E99FY25 DIVE 12 N HQS MF 48VDC IP68 03.LIB100E99FY10 DIVE 12 N HQS SP 48VDC IP68 03.LIB100E99FY40 DIVE 12 N HQS WF 48VDC IP68 03.LPB100E99FC25...
  • Page 8 Physical IP68 Housing: Bronze / Stainless steel 316 Weight: 5.6 Kg Beware Underwater installation only allowed Never make the joints of the cables in water Certifications...
  • Page 9 DIMENSIONS DIVE 6 N 5- ACCESSORIES DIVE 6 N Optional (on request) ● 8-pole underwater cable (code 0509C159 ) ● HUB – IP56 Screw terminals 1 IN / 3 OUT (code 03.LA.131.IP56 ) ● HUB – IP20 Screw terminals 1 IN / 3 OUT (code 03.LA.131 )
  • Page 10 DIMENSIONS DIVE 12 N 5- ACCESSORIES DIVE 12 N Optional (on request) ● 8-pole underwater cable (code 0509C159 )
  • Page 11 Do not use any cleaning towels that are abrasive. Use only microfiber towels. If unsure about the suitability of a product for cleaning bronze, contact DTS. Maintenance period can vary depending on water quality and environment conditions.
  • Page 12 If any parts are broken or missing, contact DTS to determine the availability of replacements. Replace any screw only by 316 stainless steel screws. To replace cable or gaskets, contact DTS.
  • Page 13 7- CONNECTIONS DIVE 6 N DIVE 6 N 48Vdc and DIVE 6 N 24Vdc is provided with an end-stripped 8-pole cable The maximum distance between DRIVENET PSU and DIVE 6 N 48 Vdc unit should not exceed 250 meters. The maximum distance between DRIVENET 832 POWER 24Vdc PSU and DIVE 6 N 24Vdc unit should not exceed 80 meters.
  • Page 14 7- CONNECTIONS DIVE 12 N DIVE 12 N 48Vdc and DIVE 12 N 24Vdc is provided with an end-stripped 8-pole cable The maximum distance between DRIVENET PSU and DIVE 12 N 48 Vdc unit should not exceed 150 meters. The maximum distance between DRIVENET 832 POWER 24Vdc PSU and DIVE 12 N 24Vdc unit should not exceed 40 meters.
  • Page 15 8- CONNECTION DIAGRAMS DIVE 6 N 48Vdc The maximum number of DIVE 6 N 48Vdc unit connectable to each output of the DRIVENET 28C DIN / 28 EZ / 416 / 832 or 1664 PSU is 1 piece. The maximum distance between DRIVENET PSU and DIVE 6 N 48Vdc unit should not exceed 250 meters.
  • Page 16 DIVE 6 N 24Vdc The maximum number of DIVE 6 N 24Vdc unit connectable to each output of the DRIVENET 28C DIN / 832 or 1664 PSU is 1 piece. The maximum distance between DRIVENET 832 24Vdc PSU and DIVE 6 N 24Vdc unit should not exceed 80 meters.
  • Page 17 DIVE 12 N 48Vdc The maximum number of DIVE 12 N 48Vdc unit connectable to each output of the DRIVENET 28 EZ / 416 / 832 or 1664 PSU is 1 piece. The maximum distance between DRIVENET PSU and DIVE 12 N 48Vdc unit should not exceed 150 meters.
  • Page 18 DIVE 12 N 24Vdc The maximum number of DIVE 12 N 24Vdc unit connectable to each output of the DRIVENET 832 POWER 24Vdc PSU is 1 piece. The maximum distance between DRIVENET 832 POWER 24Vdc PSU and DIVE 12 N 24Vdc unit should not exceed 40 meters.
