AIR CONDITIONER (MULTI TYPE)
SERVICE MANUAL
Indoor unit
<Compact 4-way cassette type>
MMU-UP0051MH-E(TR)
MMU-UP0071MH-E(TR)
MMU-UP0091MH-E(TR)
MMU-UP0121MH-E(TR)
MMU-UP0151MH-E(TR)
MMU-UP0181MH-E(TR)
<4-way cassette type>
MMU-UP0091H-E(TR)
MMU-UP0121H-E(TR)
MMU-UP0151H-E(TR)
MMU-UP0181H-E(TR)
MMU-UP0241H-E(TR)
MMU-UP0271H-E(TR)
MMU-UP0301H-E(TR)
MMU-UP0361H-E(TR)
MMU-UP0481H-E(TR)
MMU-UP0561H-E(TR)
<1-way cassette type>
MMU-UP0151SH-E(TR)
MMU-UP0181SH-E(TR)
MMU-UP0241SH-E(TR)
<Floor standing concealed type>
MML-UP0071BH-E(TR)
MML-UP0091BH-E(TR)
MML-UP0121BH-E(TR)
MML-UP0151BH-E(TR)
MML-UP0181BH-E(TR)
MML-UP0241BH-E(TR)
Revision 1 : Mar.,2021
Revision 2: Apr., 2021
Revision 3: Jun., 2021
Revision 4: Nov., 2021
Revision 5: Aug., 2022
<2-way cassette type>
MMU-UP0071WH-E(TR)
MMU-UP0091WH-E(TR)
MMU-UP0121WH-E(TR)
MMU-UP0151WH-E(TR)
MMU-UP0181WH-E(TR)
MMU-UP0241WH-E(TR)
MMU-UP0271WH-E(TR)
MMU-UP0301WH-E(TR)
MMU-UP0361WH-E(TR)
MMU-UP0481WH-E(TR)
MMU-UP0561WH-E(TR)
<Floor standing cabinet type>
MML-UP0071H-E(TR)
MML-UP0091H-E(TR)
MML-UP0121H-E(TR)
MML-UP0151H-E(TR)
MML-UP0181H-E(TR)
MML-UP0241H-E(TR)
<Floor standing type>
MMF-UP0151H-E(TR)
MMF-UP0181H-E(TR)
MMF-UP0241H-E(TR)
MMF-UP0271H-E(TR)
MMF-UP0361H-E(TR)
MMF-UP0481H-E(TR)
MMF-UP0561H-E(TR)
PRINTED IN JAPAN, Dec., 2020
FILE NO. A10-2004
ToMo
