Quick Guide
Operating the product
Read "Safety Instructions" section first!
1 2
1. On / Off Key
2.
Remote Control function
3. Menu Key
4. Time Delay Selection / Menu Direction
Selection Keys
5. Selection / Confirmation Key
6. Display
7. Start / Pause / Cancel Key
10. Tablet Detergent Indicator (depends on the model)
11. Liquid Detergent Dosing Indicator (depends on the model)
12. Auto Door Open Indicator (depends on the model)
13. Filter Cleaning Function Indicator (depends on the model)
14. IonFresh Function Indicator (depends on the model)
15. Delay Time / Programme Time Indicator
16. Delayed Start Indicator
17. End of Programme Indicator
18. Rinse Aid Indicator
19. Salt Indicator
20. Water Cut-off Indicator
21. Sound Settings Menu Indicator
22. Water Hardness Settings Menu Indicator
23.
HomeWhiz Indicator
24.
HomeWhiz Setting Indicator
9
10 11 12
13
24
23
22
21
3
4
8
8. Function Selection Keys
F1
Hygiene Care function
F2
SuperDry function
F3
DeepClean function
F4
Express Function
F5
Half Load function/
9. Programme Selection Keys
14
15
20
5
6
7
16 17
19
18
Advertisement
Table of Contents
Related Manuals for Grundig GNLP4630XDW
Summary of Contents for Grundig GNLP4630XDW
- Page 1 Quick Guide Operating the product Read “Safety Instructions” section first! 1. On / Off Key 8. Function Selection Keys Remote Control function Hygiene Care function 3. Menu Key SuperDry function 4. Time Delay Selection / Menu Direction Selection Keys DeepClean function 5.
- Page 2 2/EN...
-
Page 3: Additional Functions
Additional functions Some auxiliary functions cannot be used together. If the function you Washing programs of the machine are selected is not active even though it designed to achieve the best cleaning appears in the "Program information performance by considering the soil level, and average consumption values the amount of dirt and the characteristics of table", you can activate it after turning... - Page 4 Half Load function (Y) Tablet Detergent Function (T) (depends on the model) (depends on the model) Depending on the mains water hardness, It is used when you want to run your machine without fully fill it. it provides better drying performance 1.
- Page 5 TurboWash function (Z) DeepClean function (B) / (Z) (depends on the model) (depends on the model) The TurboWash The Bottle/Pot washing impeller located impeller (A) under the under the lower lower impeller allows impeller ensures that better washing of your your heavily soiled bottles and dishes with dishes placed on the...
- Page 6 SelfCare Active Self Cleaning Function (M) (depends on the model) (depends on model) When you activate this function, your micro This programme is recommended to be filter is cleaned with a special system at operated on each 1-2 months for machine the end of the wash and is ready for the cleaning and necessary hygiene.
- Page 7 7/EN...
- Page 8 HOMEWHIZ FUNCTION Changing the Downloaded Program You can use the HomeWhiz application to Read “Safety Instructions” section first! change the Downloaded Programme, which is You can check your dishwasher and learn the last program on the product. about its status via your smart device with You can check the Table of Program Data and the HomeWhiz function.
-
Page 9: Initial Setup
If you are using the application for the first connect to the same network on your time, complete the registration process with smart device. If your smart device your e-mail address on the application. Once does not get connected automatically, you've completed the registration process, go to its settings and connect it to the you can use all HomeWhiz supported... - Page 10 3. Tap (+) next to the dishwasher you connection indicator will light permanently; if want to add and give a name to the it is off, the wireless connection indicator will appliance. flash at short intervals. 4. Your request to add the appliance will Once the wireless connection has been be sent to its owner via e-mail.
-
Page 11: Adjusting The Water Softening System
Quick Guide Adjusting the water softening system Washing, rinsing and drying performance of your dishwasher will improve when the water softening system is adjusted correctly. To adjust the system, first learn the water hardness in your region and adjust as indicated below. - Page 12 Perform the same hardness level adjustment that you have set on the control panel also with the regeneration adjustment switch. For example, if you have adjusted to “3” in the control panel, also set the regeneration adjustment switch to 3. Regeneration Adjustment Switch Level 0 Level 1...
