McKenzie Twin Storage Beds
Assembly Instructions
Model #
1300AUF
McKenzie Twin
Storage Bed
Model #
1359AUF
McKenzie Twin
Bookcase
Storage Bed
Congratulations!
This fine piece of furniture will make a gorgeous
addition to your home. For the best results, read the
Assembly Instructions and Finishing Hints before you
begin your project.
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, directly contact Whittier Wood Products customer
service department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
800-653-3336 • Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
CALL US FIRST! Do not return this item to the store
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
•
For normal household use only. Not recommended for
commercial use.
•
Remove items before you move this unit.
•
Do not overload the drawers.
•
Before you load or move this unit, tighten all screws
and supports.
• Before you begin your project, completely read the
Assembly Instructions and Finishing Hints.
• Store this item: 1- in its box; 2- in a dry place; 3- in
temperatures that range from 40°F to 90°F (not on a cold
and possibly damp cement floor).
• Periodically inspect your furniture for any loose glue
joints, screws or any other problem that might affect the
stability of your furniture. Tighten or repair as needed.
• This assembly requires two people.
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE
To Order: Provide the furniture model number (upper
portion of this page), the part letter, production code,
quantity needed, reason for replacement and your full
name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery.
Production Code:
VN
03/12
Advertisement
Related Manuals for Whittier Wood Furniture McKenzie 1300AUF
Summary of Contents for Whittier Wood Furniture McKenzie 1300AUF
- Page 1 McKenzie Twin Storage Beds Assembly Instructions IMPORTANT NOTES: Model # • For normal household use only. Not recommended for 1300AUF commercial use. • Remove items before you move this unit. • Do not overload the drawers. McKenzie Twin • Before you load or move this unit, tighten all screws and supports.
- Page 2 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name. 1301AUF Footboard, Pedestal and Side Panel Kit (x1) Part Description...
- Page 3 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Parts List Part Description Quantity Drawer Slides (pre-installed sets) #6 x 1/2" Philtruss Screw (18 inserted) #6 x 3/4" Philtruss Screw (inserted) 1/4" x 1-3/4" Hex Bolt Washer Bracket (2 holes) Bracket (4 holes) Insert Nut (inserted) T-Nut (inserted)
- Page 4 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Parts List 1302AUF Twin Headboard Kit (x1) Part Description Quantity Headboard Assembly Left Bracket (attached) Right Bracket (attached) #8 x 1" Black Screw (inserted) #12 x 2-1/2" Pan Head Screw (inserted) 1300AUF_1359AUF —...
- Page 5 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Parts List 1361AUF Bookcase Headboard Kit (x1) Part Description Quantity Left Bracket (attached) Right Bracket (attached) #8 x 1" Black Screw (inserted) Bookcase Headboard Assembly Assembled Door (attached) False Bottom Power Strip (installed) #8 x 7/8"...
- Page 6 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Assembly Instructions This assembly requires two people. Tools Required: Phillips screwdriver, 7/16" open end or box end wrench. Remove the Foot Assemblies (YM) from the back of the Footboard (YB) as seen in Figure 1 and place them off to the side.
- Page 7 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Assembly Instructions To attach the Side Panel (YH) to the Footboard (YB), align the brackets and slide the Side Panel (YH) down on to the Footboard (YB). See Figures 3 and 3a. Fig.
- Page 8 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Assembly Instructions Place one end of a Trestle with T-Nuts (YI) facing towards the Headboard, behind the rib in the pedestal closest to the Headboard. Place the other end of the Trestle into the notched bracket in the Side Panel (YH).
- Page 9 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Assembly Instructions Using the 90° brackets with two holes (YW) attach the two middle Trestles to the notched brackets in the Side Panel (YH) with four #6 x 1/2" Philtruss Screws (YS). See Figures 7 and 7a.
- Page 10 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Assembly Instructions Facing the Footboard, attach the lower brace of the Pedestal Assembly to the Footboard with the 90° bracket with four holes (YX) and four #6 x 1/2" Philtruss Screws (YS). See Figures 9 and Fig.
- Page 11 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Assembly Instructions 11. If you have a Bookcase Headboard, stand in the open area of the assembly and reach behind the bookcase front legs to find the Large Adjustable Glides (T). Using a slotted screw driver, rotate the Large Adjustable Glides (T) clockwise until they bear weight.
- Page 12 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Assembly Instructions 12. To make sure the bed is square, measure the distance between opposing corners. If one of the measurements is larger tap on a footboard leg until the measurement is equal. See Figure 12. Fig.
- Page 13 1300AUF McKenzie Twin Storage Bed; 1359AUF McKenzie Twin Bookcase Storage Bed Assembly Instructions Steps 14 – 15 are for the Bookcase Headboard Only 14. To adjust the brake tension on the Door Stay (K) turn the screw on the Door Stay clockwise to loosen or counterclockwise to tighten.
- Page 14 Whittier Finishing Hints 2. For glue to properly bond, it is very important to Checklist of materials apply the wood glue to bare wood. Protect your eyes □ □ □ Rubber gloves Tack cloth #220 & #320 and blow into holes to clear excess dust. This will □...
- Page 15 Whittier Finishing Hints Preparing the surface 3. Apply a minimum of two coats when you use polyurethane or varnish (especially on all table top 1. Sand each piece with #220 grit sandpaper. Sand and work surfaces). After allowing the first coat to with the grain of the wood on flat surfaces and dry, sand lightly with #320 grit sandpaper.
