- Page 1 DRNX JETPACK BY BROOD MANUAL V250404...
-
Page 2: Table Of Contents
CONTENTS SAFETY REGULATIONS GENERAL INFORMATION COMPONENTS INSTALLATION OPERATION CARE DRNX JETPACK BY BROOD... -
Page 3: Safety Regulations
Ensure that your beverage has been filtered in order not to clog the pre-filter or if that has been bypassed, not to clog the machine. Thick liquids risk slowing down the liquid pump inside. DRNX JETPACK comes with a pre-filter that is already fitted onto the beverage tube. If the pre-filter is not attached, you can risk damaging components inside. -
Page 4: Components
5 – Prime (Line 2) 10 – Power Supply SPECIFICATIONS Width: 9.00in Power Supply: 120V AC Input / 240V DC Output Height: 14.3in Nominal Power: 14W Depth: 4.5in Amps: 0.6A Weight: 10lbs For Commercial Use Indoors DRNX JETPACK BY BROOD... -
Page 5: Installation
BEVERAGE LINE OUT: Connect the product output line from the Jetpack to the machine. Use a short tube if mounted on the machine or a longer tube if mounted at a distance. DUAL TAP MACHINES: Duplicate the input and output lines as needed. BEVERAGE LINE OUT CONCENTRATE LINE IN WATER LINE IN DRNX JETPACK BY BROOD... -
Page 6: Electrical Connections
(1) and (2) are paired with the corresponding jack ports beneath the DRNX unit, matching the labeled numbers for proper alignment. POWER SUPPLY SERVING LINK SAFETY PRECAUTIONS: ENSURE THAT THE JETPACK AND THE DRNX ARE UNPLUGGED BEFORE MAKING ANY CONNECTIONS. THIS IS VERY IMPORTANT FOR SAFETY REASONS. DRNX JETPACK BY BROOD... - Page 7 2. Attach Strips – Stick two strips horizontally on the wall and two on the mounting bracket. 3. Mount the Bracket – Align and firmly press the bracket onto the wall, ensuring the strips fully engage. 4. Secure & Set – Hold for 30 seconds. Press firmly for maximum support. DRNX JETPACK BY BROOD...
- Page 8 Unscrew the top two screws from the back panel. Mount the bracket on the back panel by returning the two screws through the mounting bracket and onto the back plate of the machine. Option 3. Place the Jetpack flat on a countertop next to the machine. DRNX JETPACK BY BROOD...
- Page 9 7. Press and hold the Prime button for 5 seconds. BiB Replacement: If water is dispensed from the tap, it signals that the Bag in Box (BiB) is empty, and the machine is currently dispensing only water. DRNX JETPACK BY BROOD...
-
Page 10: Operation
ON BOTTOM OF MACHINE 3. Priming: Press and hold the mushroom capped button at the bottom of the DRNX JetPack for 5 seconds. This procedure should be repeated every time an empty concentrate BiB is replaced with a new one. -
Page 11: Care
40 seconds and brew begins to flow freely, let stand for 15 minutes. Then run the remaining then close the tap. solution through the system. DRNX JETPACK BY BROOD...
