- Page 1 Mechanic’s Roller Seat with Drawer Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #52970 SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Northern Tool & Equipment product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 5 Main Parts of Product ........................... 5 Parts Diagram ............................6 Parts List ..............................6 Assembly Instructions .......................... 6 Replacement Parts ..........................8 Limited Warranty ........................... -
Page 4: Intended Use
Intended Use This Mechanic’s Roller Seat with Drawer has a cushioned vinyl seat and heavy-duty frame with a durable, power coated finished. It’s great for the garage or workshop. Technical Specifications Property Specification Dimensions W x H (in.) 17.5 x 15.5 Tool Tray Drawer Casters... -
Page 5: Specific Operation Warnings
⚠CAUTION SEAT USE AND CARE Do not force the seat. Products are safer and do a better job when used in the manner for which they are designed. Plan your work, and use the correct product for the job. ... -
Page 6: Parts Diagram
Parts Diagram Parts List Reference Part Number Item Description Qty. Remark Bottom U-frame Tool tray Left side frame Right side frame Seat Caster nut Spring washer Bolt M6 Bolt M6-longer Lock nut Drawer Caster Assembly Instructions Assembly Steps Place the tool tray (2) with the round corners to the front of the bottom U-frame (1). Page 6 of 10... - Page 7 Insert the casters (12) into the provided holes of the bottom frame and tool tray from below, and then secure the caster nuts (6) and washers (7) from the top with the provided hex key wrench. Ensure the bottom (1), the tool tray (2), and the casters (2) have been assembled securely. Place the seat pad (5) on a flat surface, face down.
-
Page 8: Replacement Parts
Turn the completed unit upside down, and then secure it to the bottom U-frame (1) with a long bolt (9) and lock nut (10). Tighten all bolts. Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. ... -
Page 9: Limited Warranty
Limited Warranty Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the NTE product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 10 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 10 of 10...
