Northern Tool + Equipment NTEMP10 Owner's Manual

Multi-use dump cart
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

Enlarged version
ntemp10manual.qxp
10/26/10
2:25 PM
Page 1
MULTI-USE DUMP CART
Owner's Manual
Model NTEMP10
• Important Safety Instructions
• Assembly Instructions
• Parts and Hardware Identification
CAUTION:
Read, understand and follow ALL instructions before using this product.
Questions, problems, missing parts? Before returning to your retailer, visit us online at
www.tricam.com or call our customer service department at 1-800-867-6763, 9a.m. - 4p.m., CST,
Monday - Friday.
For product inquiries:
Tricam
7677 Equitable Drive
Eden Prairie, MN 55344
1-800-867-6763
www.gorillacarts.net
U.S. Patent #s 6,851,756, 7,390,065, 7,210,697 and 7,441,792 Other U.S. and Foreign Patents Pending
10/10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTEMP10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Northern Tool + Equipment NTEMP10

  • Page 1 10/26/10 2:25 PM Page 1 MULTI-USE DUMP CART Owner’s Manual Model NTEMP10 • Important Safety Instructions • Assembly Instructions • Parts and Hardware Identification CAUTION: Read, understand and follow ALL instructions before using this product. Questions, problems, missing parts? Before returning to your retailer, visit us online at www.tricam.com or call our customer service department at 1-800-867-6763, 9a.m.
  • Page 2 ntemp10manual.qxp 10/26/10 2:25 PM Page 3 Exploded Drawing for Assembly Parts List A.Bed Frame (1) B. Poly Liner / Cover (1) C. Front Panel (1) D. Left Panel (1) E. Right Panel (1) F. Back Panel (1) G.Front Axle Assembly (1) H.Rear Axle Assembly (1) I.
  • Page 3 ntemp10manual.qxp 10/26/10 2:25 PM Page 5 Important Safety Instructions 1. READ ALL INSTRUCTIONS BEFORE USE. If you do not understand these instructions, need clarification or further explanation, please call our customer service department for assistance at 1-800-867-6763. 2. Do not load the cart with more than 1,200 lb (544 kg). Do not use the dumping feature of the cart with a load of more than 500 lb (226 kg).
  • Page 4 ntemp10manual.qxp 10/26/10 2:25 PM Page 7 Step 3 Attach the front struts (2) to the bed frame using M8x20 carriage bolts (2), M8 flat washers (2) and M8 lock nuts (2). Slide the M8x20 carriage bolts through the bed frame first and then through the struts. Step 4 Next attach the front struts (2) to the underside of the front axle assembly using...
  • Page 5 ntemp10manual.qxp 10/26/10 2:25 PM Page 9 Step 7 Attach the wheels to the cart by first placing the wheel spacers (4) onto the front and rear axles. Step 8 Place the wheels onto each axle (valve stems facing out) using the M12 flat washers (4) and M12 lock nuts (4).
  • Page 6 ntemp10manual.qxp 10/26/10 2:25 PM Page 11 Step 10 Insert the plastic tray by lining up the openings on the rim of the tray with the tabs on the top edges of the side panels. Lock the tray in place by sliding cotter pins through the tabs.
  • Page 7 ntemp10manual.qxp 10/26/10 2:25 PM Page 13 Using the Dumping Returning the Bed to Feature the Lowered Position To operate the dumping Rotate the bed back down to feature, pull the dumping the lowered position. Make release handle outward to sure the dumping release release the bed from the handle is locked into place locking mechanism.
