- Page 1 Touch Sense LCD Keypad SY-SIX-KLCS Installation Manual Document last updated July 01, 2024...
- Page 2 In no event shall Genetec Inc. be liable to any person or entity with respect to any loss or damage that is incidental to or consequential upon the instructions found in this document or the computer software and hardware products described herein.
-
Page 3: Table Of Contents
Contents Introduction Installation Requirements Mounting Instructions Mechanical Layout Configuration Keypad Functions Keypad Address Backlight Brightness Setting Default Configuration Keypad Version Information Communication Connections End of Line Termination (EOL) Inputs Trouble Inputs Outputs LED Indicators Error Messages Technical Specifications New Zealand and Australia European Standards UK Conformity Assessment Mark FCC Compliance Statements... -
Page 4: Introduction
Introduction The Synergis™ IX Touch Sense LCD Keypad provides a sleek, user friendly human interface to the Synergis™ IX system, an advanced technology security product providing seamless and powerful integration of access control, security and building automation. The current features of the keypad include: ⦁... -
Page 5: Installation Requirements
Installation Requirements This equipment is to be installed in accordance with: ⦁ The product installation instructions ⦁ AS/NZS 2201.1 Intruder Alarm Systems ⦁ The Local Authority Having Jurisdiction (AHJ) SY-SIX-KLCS | Touch Sense LCD Keypad | Installation Manual Last updated July 2024... -
Page 6: Mounting Instructions
Mounting Instructions The keypad should be mounted in an accessible location, such as near an external door. Cables are intended to be run inside the wall. 1. Select where to mount the keypad, ensuring that it is in an accessible location. 2. -
Page 7: Mechanical Layout
Mechanical Layout The mechanical layout shown below outlines the essential details needed to help ensure the correct installation of the keypad. All measurements are shown in millimeters. 125.00 41.17 41.17 Ø 4.5mm Mounting Hole (4x) 7.8mm x 4.5mm Mounting Slot 9.0mm x 4.5mm Mounting Slot 25.17... -
Page 8: Configuration
Configuration Before the keypad will communicate with the Synergis™ IX system it must be assigned an address. To program an address using the system configuration menu, apply power to the keypad. When the screen displays the keypad version information press the [CLEAR] key then press [ENTER]. A configuration menu is displayed. -
Page 9: Keypad Address
Keypad Address The address selection sets the address of the keypad. This address must be a unique address in the Synergis™ IX system that is below an address of 200. Enter device address: 256 Use the numerical keys 0 to 9 to program the address and press [ENTER] to save the setting. To exit without making changes press the [MENU] key. -
Page 10: Communication
Communication The Synergis™ IX system incorporates encrypted RS-485 communications technology for its module network. Each system controller supports up to 250 keypads. Power Supply for Network Devices Powering modules System Controller Module Network on the system controller Communication Terminals. +AUX- Keypad Terminal Connection Next modules... -
Page 11: Connections
Connections End of Line Termination (EOL) The EOL (End of Line) jumper should be placed in the ON position when the keypad is inserted as the first or last module on the RS-485 network. EOL Jumper OFF EOL Jumper ON Inputs The keypad is capable of connecting to 4 inputs, each of which can be programmed to perform the required function in the Synergis™... - Page 12 Input (1K and 1K): Input Duplex Mode (1K and 2K4): To utilize the input duplex mode configuration shown above, the Duplex Inputs setting must be enabled in the keypad programming (Keypads | Options 2). SY-SIX-KLCS | Touch Sense LCD Keypad | Installation Manual Last updated July 2024...
-
Page 13: Trouble Inputs
Trouble Inputs Each keypad can monitor up to 8 trouble inputs. Trouble inputs are used to monitor the module status and in most cases are not physically connected to an external input. The following table details the trouble inputs that are configured in the system and the trouble groups that they are associated with. -
Page 14: Outputs
Outputs The keypad has 4 programmable outputs. These outputs are used to control the 2 system status LED indicators, system beeper and the open collector output. The outputs can be activated and deactivated based on specific events or functions within the Synergis™ IX system. Output Function KPXXX:01... -
Page 15: Led Indicators
LED Indicators The keypad features three status indicator lights showing the condition of the Synergis™ IX system. Power Indicator Armed / Alarm Indicator Disarmed Indicator Confidentiality Mode Keypads include a confidentiality mode where activation of the onboard output will cause all lights (Power, Disarm, Arm and LCD backlight) to turn off when the keypad is not in use. - Page 16 ⦁ To illuminate this LED when an area is armed, program it as the Armed output for the area. ⦁ To flash this LED when an area is in alarm (until the alarm times out or the area is disarmed), add it to the Bell output group for the area.
-
Page 17: Error Messages
Error Messages When the keypad attempts to register or communicate with the system controller after powering up, errors can be generated indicating access to the Synergis™ IX system has been denied or was unsuccessful. This is a normal part of the Synergis™ IX system. Keypad Version Error The version of the keypad is incorrect for the system controller. -
Page 18: Technical Specifications
5% of the rated supply voltage. Genetec Inc. continually strives to increase the performance of its products. As a result these specifications may change without notice. We recommend consulting our website (www.genetec.com) for the latest documentation and product information. -
Page 19: New Zealand And Australia
New Zealand and Australia General Product Statement The RCM compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. SY-SIX-KLCS | Touch Sense LCD Keypad | Installation Manual Last updated July 2024... -
Page 20: European Standards
European Standards CE Statement Conforms where applicable to European Union (EU) Low Voltage Directive (LVD) 2014/35/EU, Electromagnetic Compatibility (EMC) Directive 2014/30/EU, Radio Equipment Directive (RED)2014/53/EU and RoHS Recast (RoHS2) Directive: 2011/65/EU + Amendment Directive (EU) 2015/863. This equipment complies with the rules, of the Official Journal of the European Union, for governing the Self Declaration of the CE Marking for the European Union as specified in the above directive(s). - Page 21 Tests EMC (operational) according to EN 55032:2015 Radiated disturbance EN 55032:2015 Power frequency magnetic field immunity tests (EN 61000-4-8) EN50131 In order to comply with EN 50131-1 the following points should be noted: ⦁ Ensure for Grade 3 or 4 compliant systems, the minimum PIN length is set for 6 digits. ⦁...
-
Page 22: Uk Conformity Assessment Mark
UK Conformity Assessment Mark General Product Statement The UKCA Compliance Label indicates that the supplier of the device asserts that it complies with all applicable standards. SY-SIX-KLCS | Touch Sense LCD Keypad | Installation Manual Last updated July 2024... -
Page 23: Fcc Compliance Statements
FCC Compliance Statements FCC Rules and Regulations CFR 47, Part 15, Subpart B This equipment complies with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. Operation is subject to the following two conditions: ⦁... -
Page 24: Industry Canada Statement
Industry Canada Statement ICES-003 This class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. CAN ICES-3 (A)/NMB-3(A) SY-SIX-KLCS | Touch Sense LCD Keypad | Installation Manual Last updated July 2024... - Page 25 © Genetec Inc., 2024. Genetec™, Synergis™ IX, Synergis™ IX, the Synergis™ IX logo and the Genetec™ Logo are trademarks of Genetec Inc., and may be registered or pending registration in several jurisdictions. Other trademarks used in this document may be trademarks of the manufacturers or vendors of the respective products.
