- Page 1 Synergis IX Touch Sense LCD Keypad SY-SIX-KLCS Installation Manual...
- Page 2 In no event shall Genetec be liable to any person or entity with respect to any loss or damage that is incidental to or consequential upon the instructions found in this document or the computer software and hardware products described herein.
-
Page 3: Table Of Contents
Contents Introduction ..........................4 Installation Requirements ...................... 5 Configuration .......................... 6 Keypad Address ............................6 Backlight Brightness Setting ......................... 6 Default Configuration ............................ 6 Keypad Version Information ......................... 7 Communication ........................8 Connections .......................... -
Page 4: Introduction
Introduction The Synergis IX Touch Sense LCD Keypad provides a sleek, user friendly human interface to the Synergis System, an advanced technology security product providing seamless and powerful integration of access, security and building automation. The current features of the keypad include: ... -
Page 5: Installation Requirements
Installation Requirements This equipment is to be installed in accordance with: The product installation instructions The National Electrical Code, ANSI/NFPA 70 The Canadian Electrical Code, Part I, CSA C22.1 The Local Authority Having Jurisdiction (AHJ) SY-SIX-KLCS | Synergis IX Touch Sense LCD Keypad | Installation Manual Last Updated July 2018... -
Page 6: Configuration
Configuration Before the keypad will communicate with the Synergis System it must be assigned an address. To program an address using the system configuration menu, apply power to the keypad and when the screen displays the keypad version information, press the [EXIT] key then press [ENTER]. A configuration menu is displayed. -
Page 7: Keypad Version Information
Keypad Version Information The version menu option displays the version and build information about the keypad. The version information is displayed on two lines and can be scrolled. Press the [MENU] key to exit. SY-SIX-KLCS | Synergis IX Touch Sense LCD Keypad | Installation Manual Last Updated July 2018... -
Page 8: Communication
Communication The Synergis System incorporates encrypted RS-485 communications technology for its module network. Each system controller supports up to 250 keypads. Power Supply for Network System Controller Module Network Devices Powering modules Communication Terminals. on the system controller +AUX- Keypad Terminal Connection Next modules on network... -
Page 9: Connections
Connections End of Line Termination (EOL) The EOL (End of Line) jumper should be placed in the ON position when the keypad is inserted as the FIRST or LAST module on the RS-485 network. EOL Jumper OFF EOL Jumper ON Inputs The keypad is capable of connecting to 4 inputs, where each input can then be programmed to perform the required function in the Synergis System. - Page 10 Input Duplex Mode (1K and 2K4): Input 4 Input 3 N.C Input Contact N.C Input Contact N.C Tamper Input 2 (3+4) Input 1 (1+2) N.C Tamper Input 2 Input 1 Common N.C Input Contact N.C Input Contact To utilize the input duplex mode configuration shown above, the input duplex setting must be enabled under the Input programming.
-
Page 11: Trouble Inputs
Trouble Inputs Trouble inputs are used to monitor the status of the keypad and in most cases are not physically connected to an external input. The following table details the trouble inputs that are configured in the system. Trouble Input Function KPXXX:01 Module Tamper. -
Page 12: Outputs
Outputs The keypad has 4 programmable outputs (PGMs). These outputs are used to control the 2 system status LED indicators, system beeper and the open collector output. The outputs can be activated and deactivated based on specific events or functions within the Synergis System. Function KPXXX:01 Open Collector Output on the Touch Sense Keypad terminal block (P1) -
Page 13: Led Indicators
LED Indicators The keypad features three status indicator lights showing the condition of the Synergis system. Power / Trouble Indicator Armed / Alarm Indicator Disarmed Indicator Power / Trouble Indicator When FLASHING, indicates that there is a trouble condition present. When ON, the system is powered and operating normally. -
Page 14: Error Messages
Error Messages When the keypad attempts to register or communicate with the system controller after powering up, errors can be generated indicating access to the Synergis system has been denied or was unsuccessful. This is a normal part of the Synergis system. Keypad Version Error The version of the keypad is incorrect for the system controller. -
Page 15: Technical Specifications
The size of conductor used for the supply of power to the unit should be adequate to prevent voltage drop at the terminals of no more than 5% of the rated supply voltage. Genetec continually strives to increase the performance of its products. As a result these specifications may change without notice. We recommend consulting our website (http://www.genetec.com) for the latest documentation and product information. -
Page 16: New Zealand And Australia
New Zealand and Australia General Product Statement The RCM compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. SY-SIX-KLCS | Synergis IX Touch Sense LCD Keypad | Installation Manual Last Updated July 2018... -
Page 17: European Standards
European Standards CE Statement Conforms to European Union (EU) Low Voltage Directive (LVD) 2014/35/EU, Electro-Magnetic Compatibility (EMC) Directive 2014/30/EU and RoHS Recast (RoHS2) Directive: 2011/65/EU. The CE mark indicates that this product complies with the European requirements for safety, health, environmental and customer protection. - Page 18 By design, all Genetec Synergis DIN Rail Enclosures comply with the EN50131 standards. Tamper protection against removal of the cover as well as removal from mounting is provided by tamper switch. Warning: Enclosures supplied by third parties may not be EN50131 compliant and should not be claimed as such.
-
Page 19: Fcc Compliance Statements
FCC Compliance Statements FCC PART 15, WARNINGS: INFORMATION TO USER This equipment complies with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 20: Industry Canada Statement
Industry Canada Statement This class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. CAN ICES-3 (A)/NMB-3(A) SY-SIX-KLCS | Synergis IX Touch Sense LCD Keypad | Installation Manual Last Updated July 2018... - Page 21 © Genetec Inc., 2018. Genetec, Synergis, Synergis IX, the Synergis IX logo and the Genetec Logo are trademarks of Genetec Inc., and may be registered or pending registration in several jurisdictions. Other trademarks used in this document may be trademarks of the manufacturers or vendors of the respective products.
