DIGITAL CAMERA

SAMSUNG NX1

SERVICE

Manual

CONTENTS

DIGITAL CAMERA

1. Repair information

2. Product specifications

3. Disassembly and reassembly

4. Troubleshooting

5. PCB diagrams

6. Block diagram

7. Firmware update

8. Adjustment

9. Exploded view and parts list

Need help?

Do you have a question about the NX1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung NX1

Page 1 DIGITAL CAMERA SAMSUNG NX1 SERVICE Manual CONTENTS DIGITAL CAMERA 1. Repair information 2. Product specifications 3. Disassembly and reassembly 4. Troubleshooting 5. PCB diagrams 6. Block diagram 7. Firmware update 8. Adjustment 9. Exploded view and parts list...
Page 2 Contents 1. Repair information 1-1 Warranty and repair service information ......1-1 1-2 Precaution for disassembly and reassembly ....1-4 2. Product specifications 2-1 Specifications ..............2-1 2-2 Product comparison ............2-4 2-3 Accessories information ...........2-5 2-4 About the memory card ...........2-8 2-5 About the battery .............2-9 2-6 New Features - Bluetooth ..........2-10 3.
Page 3 Contents 5. PCB diagrams 5-1 MAIN PCB ...............5-1 5-2 STROBO FPCB ...............5-2 5-3 TOP FPCB ...............5-2 5-4 BACK KEY PCB ..............5-2 5-5 DRIVE FPCB ..............5-3 5-6 HOTSHOE FPCB ............5-3 5-7 PROX FPCB ..............5-3 5-8 VGRIP FPCB ..............5-4 5-9 POWER KEY FPCB ............5-4 5-10 CIS HPCB ..............5-4 5-11 COMMAND FPCB ............5-4 6.
Page 4 Contents 9. Exploded view and parts list 9-1 BODY ASSEMBLY ............9-1 9-2 CMOS ASSEMBLY ............9-2 9-3 REAR ASSEMBLY ............9-3 9-4 VGRIP FPCB ASSEMBLY ..........9-4 9-5 FRONT CASE ASSEMBLY ..........9-5 9-6 TOP CASE ASSEMBLY ..........9-7 9-7 TOP SUB CASE ASSEMBLY ..........9-8 9-8 TOP LCD ASSEMBLY .............9-8...
Page 5 The warranty does not affect the consumers' rights against the company related to its information. For the length of the period indicated on the chart below, it starts with the date of original purchase. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 6 Our liability under this warranty shall be limited to the following: a. For the product which has been repaired by Samsung or Samsung authorised CSP, the item will be repaired free of charge when the same fault occurs within the warranty period.
Page 8 Use an anti-static mat as well as an anti-static wrist strap to avoid ESD damage to PCB. The use wooden or plastic tweezers is recommended for manual placement. CONNECTOR Metal tip tweezer might make marks or damage. BARREL Always follow proper direction while assembling the components of the barrel. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 9 • Total AF point: 205 points (Phase Detection AF), 209 points (Contrast AF) Focusing point • AF Range: EV -4–20 Mode Active AF, Single AF, Continuous AF, Manual Focus AF Assist Lamp Shutter • Auto: 1/8,000 sec.–1/4 sec. • Manual: 1/8,000 sec.–30 sec. Speed • Bulb Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 10 Mode Auto, Program, Aperture Priority, Shutter Priority, Manual, Custom1, Custom2, Smart Beauty Face, Landscape, Action Freeze, Rich Tones, Panorama, Waterfall, Silhouette, Sunset, Smart mode Night, Fireworks, Light Trace, Multi Exposure, Samsung Auto Shot Quality Super Fine, Fine, Normal Color space...
Page 11 0–40 °C Operating Humidity 5–85 % Software i-Launcher (web version included), Adobe Photoshop Lightroom, Samsung DNG Converter, Samsung Movie Converter, Power Media Player System Requirement Windows Windows 7/8/8.1, Intel 3rd Gen. i5 3.4 GHz or higher (equivalent AMD processor) Macintosh Mac OS 10.7 or higher...
Page 12 • Built-in flash : A-TTL popup flash • Built-in flash : A-TTL popup flash Flash • External flash : Optional Samsung external flashes • External flash : Optional Samsung external flashes • Wi-Fi : IEEE 802.11/b/g/n/ac, Bluetooth 3.0 • Wi-Fi : IEEE 802.11b/g/n support Dual Band Network and •...
Page 13 AD39-00194A Accessories Battery Charger CHARGER_CN/TW AD44-00261A NX BATTERY(BP1900)_CN AD43-00254A NX BATTERY(BP1900)_TW AD43-00255A Rechargeale Battery NX BATTERY(BP1900) _UAE AD43-00256A Software CD-ROM AD46-00450A (User manual included) Service Adobe Photoshop Lightroom DVD-ROM does not apply Strap AD63-08062A Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 14 NX1_QSG_ITA AD68-08599A NX1_QSG_ENG(SEA) AD68-08607A NX1_QSG_RUS NX1_QSG_SPA(SEA) AD68-08608A Accessories NX1_QSG_SWE AD68-08600A NX1_QSG_LAV NX1_QSG_DAN AD68-08601A NX1_QSG_LIT NX1_QSG_BUL NX1_QSG_T.CHI AD68-08606A NX1_QSG_CZE NX1_QSG_GRE NX1_QSG_ARA AD68-08602A NX1_QSG_SER NX1_QSG_FIN AD68-08603A NX1_QSG_CRO NX1_QSG_HUN NX1_QSG_VIT NX1_QSG_PER NX1_QSG_POR_BR(BR,PY) NX1_QSG_NOR AD68-08604A NX1_QSG_THA NX1_QSG_POR(PT) NX1_QSG_HEB Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 15 Compatibility lens(60, 50200) ED-LF58ND4/KR Compatibility lens(1855, 1224) ED-LF43PL/KR Compatibility lens(30, 45, 16, 20) CPL Filter ED-LF52PL/KR Compatibility lens(60, 50200) ED-LF58PL/KR Compatibility lens(1855, 1224) USB 2.0 Cable EA-CB5MU05E HDMI Cable(A to D Type) EA-CBHD10D Vertical Grip ED-VGNX01 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 16 • Available recording time may vary if you use the zoom. • Several videos were recorded in succession to determine the total recording time. • The maximum recording time is 29 minutes and 59 seconds per file. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 17 • The gures above are based on the CIPA test standards. Your results may dier depending on your actual usage. • Available shooting time diers depending on background, shooting interval, and use conditions. • Several videos were recorded in succession to determine the total recording time. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 18 This feature allows you to exchange files with other devices. Set to connect your camera to a smart phone automatically via the Bluetooth feature. If the devices have previously been connected and you launch Samsung Camera Manager on the smart phone, they will connect via Bluetooth automatically. 2-10...
Page 19 Disassembly and reassembly 3. Disassembly and reassembly 3-1 Body disassembly - General repair SCREW-MACHINE:1.4X5.0 SCREW-MACHINE:1.4X5.0 Remove two screws. Remove one screw.  VGRIP COVER  SCREW-MACHINE:1.4X5.0 Open the VGRIP cover and remove three screws. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 20 Disassembly and reassembly EYE PIECE ASSY Slide the EYE PIECE ASSY and lift it up in the direction of the arrow as in the picture above. SCREW TAP 14X60 SCREW-MACHINE:1.4X5.0 Remove five screws. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 21 Separate the LOCK, and slowly lift up the BACK COVER. LCD FPCB and KEY FPCB are connected each other inside of the body. Open the BATTERY COVER, and separate the LOCK using the REMOVE TOOL as in the picture above. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 22 Be very careful when you take apart the connector in step 8 and 10. FPCB can be easily damaged.  Pull the connector to take it apart..    Pull FPCB in the direction of the arrow to remove. Remove two connectors. FRONT CASE ASSY Remove the FRONT CASE ASSY. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 24 Remove the WHEEL KEY ASSY and the EVF BUTTON FPCB ASSY.  RUBBER  RUBBER HOLDER FRONT KEY HOLDER BUTTON  PMO WIFI KEY  PMO EVF KEY Remove the components in numerical order as it shown in the picture above. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 25 Disassembly and reassembly SCREW (1440 TAP) WP FRONT SPONGE TAPE Take two screws apart and remove the sponge tape. OLED BASE ASSY Remove the OLED BASE ASSY. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 26 Open the connector, and remove FPCB.  Pull FPCB to take it apart.   SCREW-MACHINE Pull the connector to take it apart. (PH,+,B,M1.4,L4.0SL) Remove eleven connectors and sockets. Remove six screws. MAIN PCB Remove the MAIN PCB. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 27 Disassembly and reassembly SCREW TAP 1.4X3.5 SCREW-MACHINE:PH,+,B,M1.4,L4.0SL Remove one screw. Remove one screw. SCREW-MACHINE:1.4X5.0 Open the flash, and remove one screw under the flash. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 28 PH,+,M1.4,L3.0 BK Remove two screws. Remove the TOP ASSY in the direction of the arrow as in the picture above. - Be very careful. There is a connector attached to the TOP ASSY. 3-10 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 29 The location to be discharged Touch a discharger to the marked area to discharge electricity. Pull the connector in the direction of the arrow to take it apart as it shown in the picture above. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-11...
Page 31 Lift up the EVF ASSY and remove it. HOLDER POP UP ASSY Slide the HOLDER POP UP ASSY in the direction of the arrow to take it apart as it shown in the picture above. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-13...
Page 32  SCREW (1460 TAP)   SCREW (1440 TAP) Open the connector and remove FPCB. Remove one connector and four screws.  SCREW (1435 MAC - SL)  SCREW (1435 TAP) Remove five screws. 3-14 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 33  LEVER POWER ASSY Remove the components in numerical order as it shown in the picture above.  SCREW (1435 MAC - SL) Pull FPCB to take it apart. Remove two connectors and four screws. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-15...
Page 34  SCREW TAP, M1.4,L3.0,ZPC(BLK)  TOP ASSY FPCB  HOLDER-HANGER R  TOP LCD ASSY  SCREW TAP, M1.4,L3.0,ZPC(BLK)  AF LED Remove the components in numerical order as it shown in the picture above. 3-16 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 35 Disassembly and reassembly  HOT SHOE-PMO COVER  IPR-PLATE SPRING SHOE Remove the HOT SHOE-PMO COVER and the IPR-PLATE SPRING SHOE. SCREW (1435 MAC - SL) Remove two screws. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-17...
Page 37 Disassembly and reassembly SCREW-MACHINE ;CH,M1.4,L3,NI Remove three screws.  HDMI COVER ASSY  HOLDER TRIPOD Remove the HDMI COVER ASSY and the HOLDER TRIPOD. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-19...
Page 38 Disassembly and reassembly 3-2 Body disassembly - Professional repair SCREW-MACHINE ;FH,+,M1.7,L4.0,NI Remove three screws.  SPRING CMOS ADJUST  CMOS-ASSY Remove the CMOS-ASSY and three SPRING CMOS ADJUSTS. 3-20 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 41 Be careful not to lose PIN when you follow step 7.  ICT DECO MOUNT  PLATE-MOUNT LENS  SHAFT-LENS DETECT SPRING LENS DETECT PIN Remove the components in numerical order as it shown in the picture above. SCREW-MACHINE;CH,M1.4,L3,NI Remove four screws. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-23...
Page 42  HOLDER-MOUNT Remove the components in numerical order as it shown in the picture above. - When you remove the HOLDER-MOUNT, first remove the adhesive of the speaker. SCREW-TAPTYPE ;PH,+,B,M1.4,L3.5,ZPC(BLK) Remove three screws. 3-24 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 45 Disassembly and reassembly  SPRING ETC-BATTERY PUSH  PLATE CHAMBER BATTERY  Insert-M1.4-H2.5  COVER BATTERY ASSY Remove the components in numerical order as it shown in the picture above. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-27...
Page 46  SPRING ETC-BATTERY PUSH  PLATE CHAMBER BATTERY  Insert-M1.4-H2.5  COVER BATTERY ASSY Put the components together in numerical order as it shown in the picture above. Make sure three locks are assembled properly. 3-28 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 47 Disassembly and reassembly  CHAMBER BODY ASSY  COVER SD ASSY Put the components together in numerical order as it shown in the picture above. SCREW-TAPTYPE ;PH,+,B,M1.4,L3.5,ZPC(BLK) Tighten two screws. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-29...
Page 49 Put the components together in numerical order as it shown in the picture above. - Check the assembly appearance of the Speaker & FPCB & wire of HOLDER INNER MOUNT-ASSY. SCREW-MACHINE;CH,M1.4,L3,NI Tighten four screws. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-31...
Page 50 Put the components together in numerical order as it shown in the picture above. - Align the holes when you put the ICT DECO MOUNT and the PLATE-MOUNT LENS together. SCREW-MACHINE;PH,M1.7,L5,NI Tighten four screws. 3-32 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 52 Disassembly and reassembly CIS FPCB Attach FPCB to the connector and close the connector. Attach the CIS FPCB.  SPRING CMOS ADJUST  CMOS-ASSY Attach the CMOS-ASSY and three SPRING CMOS ADJUSTS. 3-34 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 54 Disassembly and reassembly 3-4 Body assembly - General repair  HDMI COVER ASSY  HOLDER TRIPOD Attach the HDMI COVER ASSY and the HOLDER TRIPOD. SCREW-MACHINE ;CH,M1.4,L3,NI Tighten three screws. 3-36 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 56 M1.4,L3.0,ZPC(BLK)  TOP ASSY FPCB  HOLDER-HANGER R  TOP LCD ASSY  SCREW TAP, M1.4,L3.0,ZPC(BLK)  AF LED Put the components together in numerical order as it shown in the picture above. 3-38 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 57 KEY ASSY Put the components together in numerical order as it shown in the picture above.  SCREW (1435 MAC - SL) Connect FPCB to the connector. Tighten four screws and attach two connectors. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-39...
Page 58 SHOT ASSY  LEVER POWER ASSY Put the components together in numerical order as it shown in the picture above.  SCREW (1435 MAC - SL)  SCREW (1435 TAP) Tighten five screws. 3-40 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 59 Tighten four screws and attach one connector.  IPR-PLATE SPRING SHOE  HOT SHOE-PMO COVER Slide the IPR-PLATE SPRING SHOE in the direction of the arrow as in the picture above. Attach the HOT SHOE-PMO COVER. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-41...
Page 60 Disassembly and reassembly HOLDER POP UP ASSY Slide the HOLDER POP UP ASSY in the direction of the arrow as in the picture above. EVF ASSY Attach the EVF ASSY. 3-42 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 61 SCREW (1435 MAC - SL) Tighten three screws. Attach the TOP ASSY and two connectors. - Make sure that FPCB or the wires are not stuck between covers when you attach the TOP ASSY. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-43...
Page 62 Disassembly and reassembly SCREW MACHINE; PH,+,M1.4,L3.0 BK Tighten two screws. SCREW TAP 1.4X3.5 SCREW-MACHINE:PH,+,B,M1.4,L4.0SL Tighten one screw. Tighten one screw. 3-44 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 63 Disassembly and reassembly SCREW-MACHINE:1.4X5.0 Open the flash, and tighten one screw under the flash. MAIN PCB Attach the MAIN PCB. - Pull all FPCB out over the MAIN PCB. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-45...
Page 64  Connect FPCB to the connector.   SCREW-MACHINE Attach the connector. (PH,+,B,M1.4,L4.0SL) Tighten six screws and attach eleven connectors and sockets. OLED BASE ASSY Attach the OLED BASE ASSY. 3-46 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 65 Tighten two screws and attach the WP FRONT SPONGE TAPE.  RUBBER  RUBBER HOLDER FRONT KEY HOLDER BUTTON  PMO EVF KEY  PMO WIFI KEY Put the components together in numerical order as it shown in the picture above. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-47...
Page 66 EVF BUTTON FPCB ASSY WHEEL KEY ASSY Attach the WHELL KEY ASSY and the EVF BUTTON FPCB ASSY. SCREW (1430 MACHINE) Connect FPCB to the connector. SCREW (1440 TAP) Tighten eleven screws and attach FPCB. 3-48 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 67 Disassembly and reassembly  Attach the connector.    Connect FPCB to the connector. Attach two connectors. FRONT CASE ASSY Attach the FRONT CASE ASSY. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-49...
Page 68 Disassembly and reassembly  KNOB EVF ASSY  EVF COVER ASSY Attach the EVF COVE ASSY and the KNOB EVF ASSY. SCREW TAP 14X60 SCREW-MACHINE:1.4X5.0 Tighten five screws. 3-50 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 69 Disassembly and reassembly EYE PIECE ASSY Slide the EYE PIECE ASSY in the direction of the arrow as in the picture above. SCREW-MACHINE:1.4X5.0 SCREW-MACHINE:1.4X5.0 Tighten two screws. Tighten one screw. Copyright© 1995-2014 SAMSUNG. All rights reserved. 3-51...
Page 71 Make sure there is no dirt on the contacts. - Check if the SD card is damaged. - Check the SMD of the SD card socket on Main PCB. - Check the detect pins of your SD card. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 72 Check the connection of LCD FPCB.  (It can be a display problem.) Images for reference   4-3 LCD related problems Problem Touchscreen is not responding. Solution Check the connection of LCD FPCB. Images for reference Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 73 Check the connection of the SHUTTER WIRE HARNESS on MAIN PCB. Images for reference Problem “There is no lens.” appears on the screen. (The camera does not recognize the lens.) Solution Check the connection of the LENS DETECT WIRE HARNESS. Images for reference Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 74 Check the connection between MAIN PCB and TOP FPCB.. Images for reference Problem Check the connection between MAIN PCB and TOP FPCB. Solution Check the connection between Main PCB and DRIVE FPCB. Images for reference Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 75 Check the connection between MAIN PCB and EVF FPCB. Images for reference 4-7 Shutter related problems Problem When I turn on the camera, the shutter is malfunctioning itself. Solution Check the connection of SHUTTER FPCB on MAIN PCB. Images for reference Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 76 (Menu, Fn, Record, Playback, Delete and 5-way controller button) no longer work. Solution Check the connection of BACK KEY FPCB. Images for reference 4-9 Proximity sensor related problems Problem Proximity sensor is not working. Solution Check the connection of proximity sensor FPCB. Images for reference Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 77 The speaker works, but the audio is not recording. Solution Check the soldering points of the built-in microphone at the TOP ASSY, and see if FPCB is damaged. Make sure the wires are soldered to the right positions.) Images for reference Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 78 Make sure that all soldering points of the earphone jack are properly connected to the board.  Make sure that all soldering points of the microphone jack are properly connected to the board.  Images for reference   Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 79 / The image on the display is distorted. / LCD monitor is blank. Solution Check the connection of LCD FPCB.  Check the connection of CIS FPCB.  Images for reference    Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 80 The flash does not fire. Solution Check the connection between MAIN PCB and STROBO FPCB.  Check the connection between the internal STROBO WIRE HARNESS and STROBO FPCB.  Images for reference   4-10 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 81 (You should remove the front cover to check the antenna module.) Images for reference 4-15 BT/Wi-Fi problems Problem BT/Wi-Fi is not working. Solution See if a RF antenna is properly assembled. Make sure it is not damaged. Images for reference Copyright© 1995-2014 SAMSUNG. All rights reserved. 4-11...
Page 82 R175 C218 R234 R575 C216 C570 C246 R117 R146 R110 R116 R145 R147 C188 C141 C145 ZD12 R233 R402 C192 C120 C190 C119 C544 C263 C118 C117 C539 C147 ZD11 R593 C146 R531 C637 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 86 SHUTTER_KEY2 TSP_SCL/SDA I2C_CH2 MIPI_SCL/SDA JOG_FRONT_L Touch TSP_INT JOG_FRONT_R I2C_CH5 BACK_KEY_ADC1/2 GRIP_JOG JOG_BACK_R GREEN_LED/RED_LED JOG_BACK_L Back_Key WHEEL_KEY_L/R 1.8V 24Mhz eMMC 4.5 X_TRG_OUT X-SYNC Reference Clock LPDDR3 #A LPDDR3 #B eMMC 8GB 8Gbit 8Gbit (eMMc 5.0) Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 87 1. Save the ‘nx_dev.adj’ file in the top-level folder of your SD card and insert the card into your camera. nx_dev.adj Fig. 7-1 2. Turn the camera on. Fig. 7-2 3. Select ‘Smart Auto’ mode. Fig. 7-3 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 88 4. Press the buttons in numerical order below. Down → OK → Up → OK → Right → EV + OK(Hold down EV button and press OK.)          ,  Fig.7-4 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 89 (3) DISABLE DISPLAY SAVE  (4) DISABLE POWER SAVE (5) DISABLE MOVIE REC LIMIT (6) NOLENS RELEASE ENARLE Fig. 7-6 7. Turn the camera off. 8. Turn the camera on and check if the initialization is complete. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 90 Formatting will erase all saved data on the device. Please back up your data before updating. ■ 1. Save the latest firmware file (nx1.bin) in the top-level folder of your SD card and insert the card into your camera. nx.bin Fig.
Page 91 - When the update is completed, the camera will turn itself on and the monitor will display the update completed message. - If the message will not disappear, press the shutter button one time. Updating Do not power off. F/W Check Update Update Finish Fig. 7-10 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 92 → Device Information → Software Update”. 4. Select “Lens Firmware”. Menu Back Device Informatio Software Update Software Update Body Firmware Lens Firmware Body Firmware Lens Firmware 01.10 Bluetooth Mac Address Wi-Fi Mac Address 20:13:EO:OA:A9:32 Fig. 7-12 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 93 - When the update is completed, the camera will turn itself on and the monitor will display the update completed message. - If the message will not disappear, press the shutter button one time. Updating Do not power off. F/W Check Update Update Finish Fig. 7-14 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 94 1. Save the ‘nx_dev.adj, nx.bin’ file in the top-level folder of your SD card and insert the card into your camera. nx_dev.adj nx.bin Fig. 7-15 2. Turn the camera on. Fig. 7-16 3. Select ‘Smart Auto’ mode. Fig. 7-17 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 95 4. Press the buttons in numerical order below.  Down →  OK →  Up →  OK →  Right →  EV + OK(Hold down EV button and press OK.)    ,  Fig.7-18 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 96 6. Select “(1) BODY F/W UPDATE” and press the OK button. 1. FW UPDATE  (1) BODY F/W UPDATE (2) LENS F/W UPDATE (3) DSP FW BACKUP  (4) RESET USERDATA (5) MICOM F/W UPDATE (6) TSP F/W VERSION Fig. 7-20 7-10 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 97 - When the update is completed, the camera will turn itself on and the monitor will display the update completed message. - If the message will not disappear, press the shutter button one time. Updating Do not power off. F/W Check Update Update Finish Fig. 7-22 Copyright© 1995-2014 SAMSUNG. All rights reserved. 7-11...
Page 98 1. Save the ‘nx_dev.adj, lens.bin’ file in the top-level folder of your SD card and insert the card into your camera. nx_dev.adj lens.bin Fig. 7-23 2. Turn the camera on. Fig. 7-24 3. Select ‘Smart Auto’ mode. Fig. 7-25 7-12 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 99 4. Press the buttons in numerical order below.  Down →  OK →  Up →  OK →  Right →  EV + OK(Hold down EV button and press OK.)    ,  Fig.7-26 Copyright© 1995-2014 SAMSUNG. All rights reserved. 7-13...
Page 100 6. Select “(2) LENS F/W UPDATE” and press the OK button. 1. FW UPDATE (1) BODY F/W UPDATE  (2) LENS F/W UPDATE (3) DSP FW BACKUP  (4) RESET USERDATA (5) MICOM F/W UPDATE (6) TSP F/W VERSION Fig. 7-28 7-14 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 101 - When the update is completed, the camera will turn itself on and the monitor will display the update completed message. - If the message will not disappear, press the shutter button one time. Updating Do not power off. F/W Check Update Update Finish Fig. 7-30 Copyright© 1995-2014 SAMSUNG. All rights reserved. 7-15...
Page 102 3. Get recovery files: downloader.bin, nx1.bin - File will differ depending on the model. Do not mix files. 1. Save recovery files(downloader.bin, nx1.bin) to memory card. 2. Remove all the Exterior screws → EYE PIECE → EVF COVER screws → EVF COVER → BACK COVER.
Page 103 - Light Source Box 4 : PAF Light box & Controller - Master Lens - 30mm Lens - 16-50mm PWZ Lens - Tilt adjustment : RSM-5000(CSC center) - Shutter adjustment : RFS-5910A (CSC center) 3200K 5500K PAF Light Box & Controller Fig. 8-1 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 104 3. After adjustment completion, Apply glue on three screws to fix the screw position as illustrated in Fig. 8-6. The screw for CMOS Tilt adjustment Fig. 8-2 <Adjustment Result> Adjust specification for Mount side and FLANGE BACK side : 25.55mm(-35mm/+15mm) Adjust specification for CMOS sensor TILT side from center: -30um/+30um Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 105 Fig. 8-4 3. Copy “info.tgw” the file SD card. 4. Insert the card and connect the camera to PC. 5. Excute USBSet1.1.exe. 6. Cut USB ID, Clear channels and move to Channel 1. Fig. 8-5 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 106 Adjustment 7. Execute NX1_ShutterTester_Ver5.1.exe Program. Fig. 8-6 8. Select Option → Script File Open →“NX1 DOT DATA Shutter_141114.txt”. -Please check script file name & script command on window as below. Script file name Script command Fig. 8-7 9. Open “setup.ini” and change port number as shutter adjustment port Fig.
Page 107 1. Save the ‘Adjustment, nx_cs.adj’ file in the top-level folder of your SD card and insert the card into your camera. - The files inside the Adjustment folder as shown below. Fig. 8-9 2. Turn the camera on. Fig. 8-10 3. Select ‘Smart Auto’ mode. Fig. 8-11 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 108     ,  Fig. 8-12 5. Displayed the CS Mode as shown below. CS Mode 1. CIS Dot Data 2. Shutter 3. ISO 4. AWB 5. EFS 6. VFPN&DEFECT Fig. 8-13 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 109 4. When you select the ISO, adjustment will automatically start. CS Mode 1. CIS Dot Data 2. Shutter 3. ISO 4. AWB 5. EFS 6. VFPN&DEFECT Fig. 8-15 5. If the adjustment is completed, “ADJ. Finished!”message is displayed. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 110 4. When you select the AWB, adjustment will automatically start. CS Mode 1. CIS Dot Data 2. Shutter 3. ISO 4. AWB 5. EFS 6. VFPN&DEFECT Fig. 8-17 5. If the adjustment is completed, “ADJ. Finished!”message is displayed. Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 111 4. If the adjustment is completed, “EFS SUCCESS!” message is displayed. 5. Check the adjustment result. - With Shutter speed of 1/4000s, MF focus, take a picture of LV16 of Light box. Check if there’s horizontal noise on the image. Fig. 8-20 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 112 4. When you select the VFPN&DEFEC, adjustment will automatically start. CS Mode 6. VFPN&DEFECT 7. COLOR_SHADING 8. COUNTRY CODE 9. SN & MAC ADDR A. WIFI ON B. Show information Fig. 8-22 5. If the adjustment is completed, “ADJ. Finished!”message is displayed. 8-10 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 113 4. When you select the COLOR_SHADING, adjustment will automatically start. CS Mode 6. VFPN&DEFECT 7. COLOR_SHADING 8. COUNTRY CODE 9. SN & MAC ADDR A. WIFI ON B. Show information Fig. 8-24 5. If the adjustment is completed, “ADJ. Finished!”message is displayed. Copyright© 1995-2014 SAMSUNG. All rights reserved. 8-11...
Page 114 - If the camera is not set region after replacing the Main PCB or is purchased from overseas, there are some issues as below. 1) User does not use SNS service country-specific. 2) Do not support multiple languages for display and input when using Wi-Fi. 3) Wi-Fi telecommunication speed may be down. 8-12 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 115 5. If the setting is completed, “ADJ. Finished!” message is displayed. - When the original Mac address is gone and is changed to new one, please change SSID of NFC tag as new Mac address. Copyright© 1995-2014 SAMSUNG. All rights reserved. 8-13...
Page 116 3. Read Script file - Select LOG2 → Script Load →“NX1_CH2_PAF.txt”PAT Script → Close and open the program again. 4. If the script is loaded correctly, then the script name is on channel 2. Fig. 8-30 8-14 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 117 3) Select “SETUP VIEW” and then Change COM port number in second channel and its speed as 9600. 4) Close and open the program again. Fig. 8-31 6. Execute USBSet1.1.exe. 7. Cut USB ID, Clear channels and move to Channel 2. Fig. 8-32 Copyright© 1995-2014 SAMSUNG. All rights reserved. 8-15...
Page 118 9. SN & MAC ADDR A. WIFI ON B. Show information Fig. 8-34 2. When ON / OFF switch appears, the switch is select to OFF. - If you select OFF, the Wi-Fi is turned off. 8-16 Copyright© 1995-2014 SAMSUNG. All rights reserved.
Page 119 UGANDA PALESTINE GERMANY UKRAINE PARAGUAY GHANA UNITED_KINGDOM PARAGUAY Greece UNITED_STATES PHILIPPINES GSS_CO UNITEDARABEMIRATES POLAND GUINEA URUGUAY PORTUGAL Guinea-Bissau UZBEKISTAN HONGKONG REUNION VIETNAM HUNGARY ROMANIA YUGOSLAVIA RUSSIA INDIA ZAMBIA INDONESIA RWANDA ZIMBABWE SAMPLE IRAN Copyright© 1995-2014 SAMSUNG. All rights reserved. 8-17...
Page 120 Remark AD97-24516A ASSY-CASE REAR;NX1 AD97-24527A ASSY-COVER TOP;NX1 AD97-24519A ASSY-CASE FRONT;NX1 AD97-24492A ASSY CMOS;NX1 AD97-24447A ASSY-EYEPIECE;NX1 AD97-24450A ASSY COVER-EVF;NX1 AD97-24451A ASSY-EVF_KNOB;NX1 AD67-02982A RUBBER-VGRIP COVER AD63-07462A CUSHION SHIELD FOAM-BACK AD61-06447A HOLDER-TRIPOD;NX1,ZN,BLACK AD92-02268A ASSY PBA MAIN-NX1 MAIN Copyrightⓒ 1995-2013 SAMSUNG. All rights reserved.
Page 121 SCREW-MACHINE;PH,+,M1.4,L3,NI PLT,SWRCH1 6003-001630 SCREW-TAPTYPE;PH,+,B,M1.4,L3.5,ZPC(BLK) 6003-001658 SCREW-TAPTYPE;PH,B,M1.4,L6,ZPC(BLK) 6009-001410 SCREW-SPECIAL;CH,+,M1.4,L4.7(2.5),ZPC(WHT) AD59-00248A UNIT-BODY_PROX SENSOR AD62-00227A PAD GAP-THERMAL;NX1,SI RUBBER,BLACK 9-2 CMOS ASSEMBLY Loc. No Parts No. Description Q ty Available Remark AD92-02270A ASSY PBA MAIN-NX1 CIS FPCB;NX1,NX1 CIS F Copyrightⓒ 1995-2013 SAMSUNG. All rights reserved.
Page 122 9-3 REAR ASSEMBLY Loc. No Parts No. Description Q ty Available Remark 6001-001811 SCREW-MACHINE;CH,+,M1.4,L3,NI PLT,SWRCH1 6003-001630 SCREW-TAPTYPE;PH,+,B,M1.4,L3.5,ZPC(BLK), 6107-001781 SPRING-CS;SUS304WPB,PI0.18,3.8,ID1.8,OD2 AD02-00286A TAPE SPONGE-GRIP REAR R;ACRYL FOAM,WL10, AD02-00321A TAPE SPONGE-DECO MOUNT;NX1,ACRYL AD61-05314A PLATE-MOUNT SPRING;NX200,STS AD61-06445A HOLDER-MOUNT;NX1,AL,SILVER Copyrightⓒ 1995-2013 SAMSUNG. All rights reserved.
Page 123 AD63-08024A GRIP-REAR R;NX1,TPU,BLACK,PC GF10% AD64-04167A DECORATION-MOUNT;NX1,SUS,SILVER AD66-00945A SHAFT-LENS DETECT;NX200,SUS303,SILVER AD67-02616A CAP-MOUNT;NX300,PC,BLACK AD67-02990A RUBBER-O-RING PLATE MOUNT;NX1,S AD92-02265A ASSY PBA MAIN-NX1 VGRIP FPCB;NX1,NX1 AD92-02276A ASSY PBA MAIN-NX1 STROBO FPCB;NX1,NX1 AD97-24440A ASSY-CASE REAR SUB;NX1 AD97-24442A ASSY-HDMI;NX1 AD97-24452A ASSY-INNER MOUNT HOLDER;NX1 AD97-24489A ASSY COVER-BATTERY;NX1 AD97-24548A ASSY-CHAMBER_SUB;NX1...
Page 124 Q ty Available Remark 6001-001811 SCREW-MACHINE;CH,+,M1.4,L3,NI PLT 6001-002742 SCREW-MACHINE;CH,M1.4,L2.5,ZPC(BLK) 6003-001659 SCREW-TAPTYPE;PH,+,B,M1.4,L4,ZPC(BLK) AD02-00283A TAPE SPONGE-WP SD CARD B;NX1 AD02-00310A TAPE SPONGE-WP FRONT A; AD02-00311A TAPE SPONGE-WP FRONT B; AD02-00312A TAPE SPONGE-WP FRONT C; AD02-00333A TAPE SPONGE-BTOB VGRIP;NX1 AD02-00336A TAPE SPONGE-WP FRONT F;NX1 AD02-00338A TAPE DOUBLE FACE-FRONT GRIP;NX1...
Page 125 AD97-24520A ASSY COVER BACK-OLED TILT;NX1,BLACK AD97-24536A ASSY-FRONT KEY;NX1 AD97-24537A ASSY-WIFI KEY;NX1 AD97-24538A ASSY-EVF KEY;NX1 AD97-24539A ASSY-PLATE EVF;NX1 AD97-24540A ASSY-CASE FRONT SUB;NX1 AD63-07549A SHEET-TILT FPCB;NX300,EFX01 AD02-00368A TAPE SPONGE-WP FRONT H;NX1 AD02-00369A TAPE SPONGE-WP FRONT I;NX1 Copyrightⓒ 1995-2013 SAMSUNG. All rights reserved.
Page 126 ASSY-EVF;NX1 AD97-24526A ASSY-TOP LCD;NX1 AD97-24542A ASSY-RUBBER LIGHT KEY;NX1 AD97-24543A ASSY-TOP LCD SPONGE;NX1 AD02-00305A TAPE SPONGE-TOP REAR; AD02-00356A TAPE SPONGE-STROBO N;NX1 AD02-00359A TAPE SPONGE-POWER LEVER WASHER;NX1 AD02-00366A TAPE SPONGE-STROBO S;NX1 AD02-00369A TAPE SPONGE-WP FRONT I;NX1 Copyrightⓒ 1995-2013 SAMSUNG. All rights reserved.
Page 127 Parts No. Description Q ty Available Remark AD61-06005B PLATE-SPRING SHOE_WH AD97-24524A ASSY-TOP LEFT AD67-02581A RUBBER-MIC 3003-001198 MIC-CONDENSER 9-8 TOP LCD ASSEMBLY Loc. No Parts No. Description Q ty Available Remark AD67-02581A RUBBER-MIC 3003-001198 MIC-CONDENSER Copyrightⓒ 1995-2013 SAMSUNG. All rights reserved.
Page 128 E.Asia, W.Asia, China, Japan https://gspn2.samsungcsportal.com N.America, S.America https://gspn3.samsungcsportal.com © 2014 SAMSUNG Electronics Co.,Ltd This Service Manual is a property of Samsung Electronics Co.,Ltd. All rights reserved. Any unauthorized use of Manual can be punished under Printed in Korea Code No: NX1...
