Summary of Contents for ChiQ CTM435W
- Page 1 CTM435W CTM434S CTM433B USER MANUAL FROST FREE BOTTOM MOUNTED REFRIGERATOR Keep this manual in a safe location and use it for reference. Read this manual carefully before commencing operation of this appliance, and comply with the Terms and Conditions. www.chiq.com.au...
-
Page 2: Part Names And Locations
PART NAMES AND LOCATIONS Description Freezer Shelf Air regulating rod Thermostat Refrigerator Glass Shelf Crisper Cover Salad Crisper Adjustable Foot Bottle Rack Upper Bottle Rack Little Bottle Rack Bottom Bottle Rack IN ACCESSORY BAG: USER MANUAL, WARRANTY CARD & DOOR STOPPER (small plastic parts for door reverse purpose ONLY) As the manufacturer holds the authority to redesign or modify its products without notice: Any modifications or upgrades of our products will result in this refrigerator varying slightly from this manual... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Follow these basic precautions to reduce the risk of fire, electrical shock hazards or injury when operating the WARNING refrigerator: It is critical use this appliance safely. Read all instructions before operating the refrigerator and do not attempt to repair or modify this unit in any way as it can cause harm or void the warranty. - Page 4 R600a WARNINGS NOTE: This model uses R600a flammable refrigerant in its sealed system. The following must be observed for your safety: R600a Refrigerant Warning • This appliance contains 0.052kg R600a refrigerant which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect.
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using the Refrigerator Remove the exterior and interior packing. Before connecting the refrigerator to a power source, let the unit stand upright for approximately 4 hours to mitigate the possibility of a malfunction in the cooling system from improper handling during transportation. -
Page 6: Freezer Temperature Adjustment
OPERATING INSTRUCTIONS START The temperature inside the refrigerator is controlled by the potentiometer installed in the refrigerated room. The temperature inside the refrigerator varies depending on the opening and closing doors of the refrigerator, the ambient temperature, and the place of placement. Under normal operating conditions (spring and autumn), it is recommended to set the cold room and cold room temperature control gear in the middle gear. -
Page 7: Storage Of Food
refrigerating appliance is designed The information about the climate range of the appliance is provided on the rated plate. The fact that the internal temperatures could be affected by such factors as the location of the refrigerating appliance, ambient temperature and the frequency of door opening, and, if appropriate, a warning that the setting of any temperature control device might have to be varied to allow for these factors The fact that effervescent drinks should not be stored in food freezer compartments or... -
Page 8: Preparations For Freezing
The care required with regard to frozen food in storage in the event of an extended non- running of the refrigerating appliance (interruption of power supply or failure of the refrigerating system) Do not open the refrigerator door as much as possible so that even in hot summer food can be safely and freshly kept for hours. - Page 9 Use quality food and handle it as little as possible. Freeze food in small quantities, it freezes faster, takes less time to thaw and enables you to eat it in the quantity you need. First, estimate the amount of food you will be freezing. If you are freezing large amounts of fresh food, remember to turn the control dial to the low temperature range.
-
Page 10: General Care And Maintenance
GENERAL CARE AND MAINTENANCE Cleaning the Refrigerator Upon installation of your new appliance, it is recommended that it be cleaned thoroughly and properly maintained thereafter. Turn off the refrigerator and then unplug the unit from the wall outlet. Remove all food content before washing the inside with a damp cloth soaked in lukewarm ... - Page 11 The refrigerator door should remain open only as long as necessary; do not place hot food inside the refrigerator. Organize the refrigerator to reduce door openings .Remove as many items as needed at one time and close the door as soon as possible. The refrigerator door should be properly closed to avoid increased energy consumption, and the formation of excess ice and / or condensation inside.
-
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE Many common refrigerator problems can be easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling for service. PROBLEM POSSIBLE CAUSES Power cord isn’t plugged in properly. ... - Page 13 The gasket/s may be dirty or not properly maintained. Clean properly. the seals and make sure they are dry before closing the door/s. The storage basket and/or shelves are out of position. For any enquiries, please call the CHiQ Cusotmer care on: 1300 796 688.
