MT10-HW Installation Guide
MT10 Overview
The Cisco Meraki MT10 is wireless Bluetooth-enable sensor type product. The MT10 is designed to be
deployed primarily in a networking environment (e.g., network closet) alongside Meraki equipment enabling
the end-user to receive alerts from the device specific to temperature and humidity.
Package Contents and Wall Mount Hardware
In addition to the MT10, the following are provided:
Installation Instructions
Note: Each MT10 comes with an instruction insert within the box. This insert contains detailed step-by-
step guides and images to assist in the physical installation of the camera. A pdf can be found here.
(Note—this is a draft hyperlink not active yet.)
Note: During first time setup, the MT10 will automatically update to the latest stable firmware. Some
features may be unavailable until this automatic update is completed. This process may take up to 10
minutes due to enabling of whole disk encryption.
1
Advertisement
Table of Contents
Related Manuals for Cisco Meraki MT10-HW
Summary of Contents for Cisco Meraki MT10-HW
- Page 1 MT10-HW Installation Guide MT10 Overview The Cisco Meraki MT10 is wireless Bluetooth-enable sensor type product. The MT10 is designed to be deployed primarily in a networking environment (e.g., network closet) alongside Meraki equipment enabling the end-user to receive alerts from the device specific to temperature and humidity.
-
Page 2: Power Options
Wall Mount Hardware Setup The MT10 has multiple options for mounting to a surface. A mounting plate and two screws allowing it to be mounted to a wall using screws. If necessary, two drywall anchors are included to help if the wooden stud cannot be located. -
Page 3: Pre-Install Preparation
Pre-Install Preparation You should complete the following steps before installing the MT10 in its final location. Configure your MT10 in the Networking using Dashboard The following is a brief overview only of the steps required to add a MT10 to your network. For detailed instructions about creating, configuring, and managing Meraki IoT networks, refer to the online ( https://documentation.meraki.com/MT). -
Page 4: Assigning Ip Addresses
Each MT10 will generate a unique domain name to allow for secured direct streaming functionality. These domain names resolve an A record for the private IP address of the camera. Any public recursive DNS server will resolve this domain. If utilizing an onsite DNS server, please whitelist *.devices.meraki.direct or configure a conditional forwarder so that the local domains are not appended to *.devices.meraki.direct and that these domain requests are forwarded to Google public DNS. -
Page 5: Regulatory Statements
Width: 2.59 inches Height: 1.03 inches Power Rating: 5Vdc Regulatory Statements EU Radiation Exposure Statement Installing or mounting of this device shall be done as such that a minimum separation distance (distance between a person and the device, or the device’s antennas) of 20 cm is always ensured. EU WEEE Position Statement The European Union (EU) WEEE Directive, 2012/19/EU of July 2012, supersedes the original directive, 2002/96/EC of January 2003, and is implemented through national regulations in all European Economic Area (EEA) countries... - Page 6 FCC Caution Any changes or modifications not expressly approved by Cisco Systems, Inc. could void the user’s authority to operate this equipment. This Transmitter must not be co-located or operation in conjunction with any other antenna or transmitter. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
- Page 7 Taiwan Wireless Statements 低功率電波輻射性電機管理辦法 第 12 條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更 原設計之特性及功能。 第 14 條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無 干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 Statement CS-0438 - 台灣 RoHS 台灣RoHS“限用物質含有情況標示聲明書”網址 www.cisco.com/go/taiwanrohs Statement CS-0438 - Taiwan RoHS Taiwan RoHS “Restricted Substances Content Disclosure Table” web address www.cisco.com/go/taiwanrohs...
