Control All Wireless 2DP2L0EFA Installation Instructions

Installation instructions for 2 button remote control kit. BOTH BUTTONS HAVE OPTIONAL
TO BE USED ON 12 VOLT OR 24 VOLT DC POWER SUPPLIES ONLY
Remote Function- SEE Figure 1 When the (A) button is pressed on the remote power is sent to the blue
wire and the gray wire until the button is released. When the (B) button is pressed, power is sent to the
white wire only.
We have programmed the keychain remote to your base unit for you. If you need to reprogram see page 3
No more than 10 amps total at any given time can run through the receiver. We recommend the use of 6
amp diodes on the control wires to prevent any power feedback into the receiver from any accessories you
may use. For higher amp uses you must use relays... with the unit. It is recommended to wire in a on off
switch on the power (red wire) of the receiver to prevent battery drainage when the unit is not in use. . USE
THE ENCLOSED 10 AMP IN-LINE FUSE ON THE RED POWER WIRE. THERE ARE NO REFUNDS FOR
BURNT OUT UNITS
The Grey wire is a double pull wire which means whenever any button is depressed this wire is also
actuated, commonly used for when you want to open a valve and engage a solenoid at the same time to
start a motor.... If not needed tuck and tape.
What you need:
12vdc test light
Wire connectors (varies depending on application) and or scotch locks. NOTE: use dielectric grease on
all splice connections to prevent corrosion.
Wire stripper / crimper
This kit contains the following:
1- 2 button keychain remote
1- Wireless base unit box with pigtails
1-10 amp in line fuse link
1. Mount unit (base unit with wiring pigtails) near equipment motor.
2. Run a 14-gauge wire from a 12 volt power supply or keyed ignition power to red terminal
3. Connect the black wire from the base unit to the battery ground or a good ground.
4. Connect the gray wire from the base unit to the small terminal that activates the solenoid that
controls (OR SENDS POWER TO) the motor.
5. Connect the white wire (which is activated with lower button (B) see figure1) to the hot side of the
lower valve wire (you can find this wire on your equipment by activating the function and the
probing the wire with a test light)
6. Connect the blue wire (which is activated with the raise button (A) see figure 1) to the hot side of
the raise valve wire.
9. Test toggle switch and remote functions. Your control is now ready for use.
10. MAKE SURE YOU HAVE SECURE AND CLEAN CONNECTIONS EVERYWHERE
2DP2L0EFA Extended Antenna
DOUBLE PULL
