Installation instructions for 4 button remote control kits (NO GRAY WIRE) 4 buttons 1 function
TO BE USED ON 12 OR 24 VOLT DC POWER SUPPLIES ONLY
Remote Function- SEE Figure 1 yellow wire is activated with S1, White wire is activated with S2,
Green wire is activated with S3, and Blue wire is activated with S4. Red wire is DC power supply,
Black wire is ground.
We have programmed the keychain remote to your base unit for you unless otherwise noted.. If you need
to reprogram see page 3
No more than 10 amps total at any given time can run through the receiver. We recommend the use of 6
amp diodes on the control wires to prevent any power feedback into the receiver. For higher amp uses you
must use relays... with the unit. It is recommended to wire in a on off switch on the power (red wire) of the
receiver to prevent battery drainage when the unit is not in use. . USE THEN ENCLOSED 10 AMP IN-LINE
FUSE ON THE RED POWER WIRE.THERE ARE NO REFUNDS FOR BURNT OUT UNITS
Tools you will need:
12vdc test light
wire connectors (varies depending on application) and or scotch locks. NOTE: use dielectric grease on all
splice connections to prevent corrosion.
Wire stripper / crimper
This kit contains the following:
1- 4 button keychain remote
1- Wireless base unit box with pigtails (and optional external antenna if ordered)
1- External antenna
1-10 amp in line fuse link
FOLLOW THESE STEPS CAREFULLY. DC POWER ONLY
Mount unit (base unit with wiring pigtails) near equipment motor.
1. Run a 14 gauge wire from a 12 volt DC power supply or keyed ignition power to red terminal
2. Connect the black wire from the base unit to the battery ground or a good ground.
3. Connect the white wire (which is activated with lower button (B) see figure1) to the activation side
of the valve / coil... that you want to send power to activate this function.
4. Connect the wires as described on top of page.
9. Test toggle switch and remote functions. Your control is now ready for use.
10. MAKE SURE YOU HAVE SECURE AND CLEAN CONNECTIONS EVERYWHERE
4DP0L0EFA
each
1
Advertisement
Table of Contents
Related Manuals for Control All Wireless 4DP0L0EFA
Summary of Contents for Control All Wireless 4DP0L0EFA
- Page 1 4DP0L0EFA Installation instructions for 4 button remote control kits (NO GRAY WIRE) 4 buttons 1 function each TO BE USED ON 12 OR 24 VOLT DC POWER SUPPLIES ONLY Remote Function- SEE Figure 1 yellow wire is activated with S1, White wire is activated with S2, Green wire is activated with S3, and Blue wire is activated with S4.
- Page 2 FIGURE 1...
-
Page 3: Battery Replacement
SETUP KEYCHAIN REMOTE TO BASE UNIT ADDRESS Your keychain remote was setup to your receiver at the factory. If you need to reprogram your existing remote or are adding or replacing one follow the instructions below. Please follow these steps: Video link 1. -
Page 4: Troubleshooting
TROUBLESHOOTING Follow these steps: Make sure the LED is lit when the receiver power is turns on. If the LED is not on, check your power supply to the receiver. With the receiver powered up, make sure the LED comes on when the buttons are depressed on the key fob.
Need help?
Do you have a question about the 4DP0L0EFA and is the answer not in the manual?
Questions and answers
