Diamond Multimedia ATI Radeon X1650 Pro PCIE Specification Sheet

SKU
PRODUCT
PRODUCT SHORT DESCRIPTION
PRODUCT DETAILED DESCRIPTION
PRODUCT FEATURES
SYSTEM REQUIREMENT
OPERATING SYSTEM
FORM FACTOR
DIMENSIONS
WEIGHT
UPC
PACKAGE CONTENT
PRODUCT WEBPAGE
PRODUCT NOTES California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth
defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if
heating the solder.
The information presented in this document is for information purposes only. The information contained herein is subject to change and may be rendered inaccurate for many reasons, including, but not limited to product and specification
changes, new model and/or product releases, product differences between differing manufacturers, software changes, BIOS flashes, firmware upgrades, or the like. Diamond Multimedia assumes no obligation to update or otherwise correct or
revise this information. Diamond Multimedia makes no representations or warranties with respect to the contents hereof and assumes no responsibility for any inaccuracies, errors or omissions that may appear in this information. However,
Diamond Multimedia reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Diamond Multimedia to notify any person of such revisions or changes. Please see your Diamond
Multimedia sales representative for any questions regarding this product information.
Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.
ATI, Graphics by ATI, and Radeon are trademarks of ATI Technologies, Inc.
All other trademarks are property of their respective owners.
© 2009 Diamond Multimedia. All rights reserved.
DIAMOND MULTIMEDIA - SPECIFICATION SHEET
SKU x1650PCIE256I
BRAND X1650
February 4, 2011 - 6:23 am
x1650PCIE256I
DIAMOND AMD ATI Radeon™ X1650 Pro PCIE 256MB DDR2 Video Card
INTERFACE
GPU
CORE CLOCK
MEMORY CLOCK
MEMORY CONFIGURATION
MEMORY TYPE
MEMORY BANDWIDTH
MEMORY SIZE
MEMORY CONTROLLER INTERFACE
PORTS
DUAL LINK DVI
The Radeon™ X1650 PRO Video Card delivers excellent performance and all the extensive features of a high-end
graphics card. Your system will be able to handle high definition digital video and Windows Vista™ with aplomb. The
X1650 PRO is capable of displaying a billion colors more than competing graphics cards. Radeon X1650 PRO Video
Card graphics technology. Exceptional graphics performance.
Bus Type: PCI Express x16
Memory Support: 256MB GDDR2 128 bit
Output: One DVI (Dual Link), HDTV, SVGA
Core Clock: 600 MHz
Memory Clock: 400 MHz
EXTERNAL POWER REQUIREMENT
CPU
CPU SPEED
MEMORY
HARD DISK
SYSTEM BUS
SLOT
CHASSIS
MONITOR
INTERNET ACCESS
USB
CD DVD
POWER SUPPLY
WINXP WINXP64 WINVISTA32 WINVISTA64 MCE
[PRODUCT] : 11.75 X 9.5 X 3 inches [RETAIL BOX] : 11.75 X 9.5 X 3 inches [S BUILDER] : 11.5 X 7.25 X 2 inches
[PRODUCT WEIGHT] : 0.45LBS [PRODUCT WITH CONTENT WEIGHT] : 2.0 LBS
RETAIL PACKAGE UPC : 757448006995
DIAMOND VIPER X1650 PRO PCIE 256MB DDR2
QUICK START GUIDE
INSTALL CD
http://www.diamondmm.com/x1650PCIE256I.php
PCI Express x16
X1650PRO
600MHz
400MHz
16Mx16
GDDR2
22.4GB/sec
256MB
128-Bit
Dual Link DVI , VGA , HDTV-out
Hydravision 3
AMD Athlon® or Intel ® Pentium ® 4
2.4 GHz or higher CPU
256MB
480 MB
PCI Express x16
SINGLE
ATX
Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
YES
YES
420 Watt ATX 2.0 or greater power supply.Consult your
computer system manual to ensure the power supply is
designed to accommodate a high-end graphics card with a
peak dissipation above 75 watts.
20740 Plummer St. Chatsworth, CA 91311
Tel: (818) 534-1414 Fax: (818) 773-9619
ENG APVD - LK 2008-12-04
MRKTG APVD - LL 2008-12-02
Diamond Multimedia
http://www.diamondmm.com
