- Page 1 EDISTO CHAISE LOUNGE CHAIR...
- Page 2 PARTS FRONT LEGS SEAT MIDDLE LEG 2 pcs ARM 2 pcs CUSHION HARDWARE OUTER SCREW OUTER SCREW INNER SCREW GASKET 5/16” x 35 mm 5/16” x 65 mm 5/16” x 35 mm 16 mm 2 pcs 2 pcs 11 pcs 7 pcs NUT CAP WRENCH...
- Page 3 ASSEMBLY INSTRUCTIONS - SINGLE CHAISE Assemble the front legs (B) to front of the seat (A), aligning the three screw holes. Screw the outer screw (F) and gasket (I) into the screw holes. Cover with a cap (L). Assemble the two arms (C) on the left and right sides of the seat (A), aligning the three screw holes on each arm.
- Page 4 ASSEMBLY INSTRUCTIONS - DOUBLE CHAISE / DAYBED Assemble the front legs (B) to the front of the seat (A) on both chaise chairs, aligning the three screw holes. Screw the outer screw (F) and gasket (I) into the screw holes. Cover with a cap (L).
- Page 5 ASSEMBLY INSTRUCTIONS - DOUBLE CHAISE / DAYBED Set the two chaise chairs upright on the ground. Cover the screw hole at the top of the seats with a middle leg (E). Screw an outer screw (G) with a gasket (I) through the middle leg (E) and hole in the seat.
