- Page 2 PARTS RIGHT ARM SEAT LEFT ARM BACK CUSHION CONNECTOR SEAT CUSHION HARDWARE BOLT BOLT BOLT BOLT WASHER 1/4” x 35 mm 1/4” x 45 mm 1/4” x 60 mm 1/4” x 20 mm 16 mm 4 pcs 2 pcs 2 pcs 2pcs 12 pcs NUT CAP...
- Page 3 ASSEMBLY INSTRUCTIONS - CHAIR Place the left arm (A) down on a soft, non-abrasive surface. Attach the seat (C) to the left arm (A) using bolts (G) and washers (K). Cover the bolt with cap (N). Attach the left arm (A) to the seat (C) using bolts (H) and washers (K).
- Page 4 ASSEMBLY INSTRUCTIONS - LOVESEAT & SOFA Place two seats (C) upside down on a soft, non-abrasive surface. Put a connector (F) piece between the two seats (C). Attach the seat base to the connector piece using washer (K), bolt (I) and nut (L). Tighten with wrench (P).
- Page 5 ASSEMBLY INSTRUCTIONS - LOVESEAT & SOFA Turn the chair over. Attach the seat (C) to the right arm (B) using bolts (G) and washers (K). Cover the bolt with cap (N). Attach the right arm (B) to the seat (C) using bolts (H) and washers (K).
