- Page 1 SurePrint C100 Cassette Printer Easy Operation Manual V 1.2 - English version - March 2022...
-
Page 2: Turn On The Equipment
I. Turn on the Equipment The following six steps need to be performed to open the Dakewe intelligent cassette printer: 1) Connect the power cord to a grounded power outlet. 2) Turn on the main power switch on the rear side of the unit and keep the switch at the“丨”position (Figure 1-1). - Page 3 II. Turn off the Equipment The following three steps are required to completely shut down the Dakewe intelligent cassette printer: (1) Select the ON/OFF button on the right side of the equipment (Figure 1-2), and press and hold the button for three seconds;...
-
Page 4: Output Tray
III. Output tray The Dakewe intelligent cassette printer is equipped with a tray with 10 slots. Each slot can be loaded with 10 cassettes, the total unloading capacity is 100 cassettes. The device is also equipped with a tray operation button (Figure 3-1), which allows short and long press operations. -
Page 5: Loading Cassettes
IV.Loading cassettes The Dakewe intelligent cassette printer comes with the function of automatic detection of cassettes in hopper. When the hopper at the feed port is empty, the software system will automatically detect and switch to the next hopper; when the six hoppers are empty, the equipment stops printing, the status is STOP, and the software system makes a voice prompt “Fill Cassette”... - Page 6 1 and can be divided into 2-7 digits, which can be set in the menu interface - “Print Settings” - “ID” - “Main ID” column. When the number of digits entered for the main ID is more than the number of digits set for - 6 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com...
- Page 7 The suffix is entered in the input box on the right or selected by clicking the drop-down button, and can be numbers, English letters, Chinese characters, or special characters. - 7 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com...
-
Page 8: Interface Description
The user name currently logged in and the authority icon to which it belongs have three levels of authority: Ordinary user (default level), administrator (Figure 6-2), and manufacturer.. Prompt message area: message for prompting the user to operate, the software system shows the prompt in - 8 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com... -
Page 9: Main Interface
Pending List, and Buttons. (1) Print Settings: the main screen for print template setup. The main functions include: print template selection, Color Recognition, customization in print template, prefix selection, suffix selection, custom ID - 9 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com... - Page 10 1 GB of hard disk space. Compatible Operating System: Windows 7, Windows 10, Linux. - 10 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com...
- Page 11 The main functions include: template selection, ID sub number setup, custom ID setup, add list, clear list, Prior, terminate printing, pause, print. See 5.3.2 Main Interface. Print preview - 11 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com...
-
Page 12: Color Recognition
ID that does not need to be printed. VII. Color Recognition The Dakewe intelligent cassette printer is equipped with a Color Recognition module, the system determines the color of the embedding box by identifying the RGB color value on the surface of the embedding box; The user can print the corresponding pathological number of embedding boxes with different colors by setting the color recognition configuration. - Page 13 "collect" button. after color collection, please confirm the printing process type again: automatic color recognition. Figure 7- 1 Add Organization list Figure 7- 2 Add cassette color - 13 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com...
-
Page 14: Channel Selection
Calibration VIII. Channel Selection The Dakewe intelligent cassette printer is equipped with a channel printing system, which prints the embedding box according to the channel identification of the turntable; The user can print the corresponding pathological number for the embedding boxes of different channels by setting the channel configuration. - Page 15 1, 2, 3, 4, 5 and 6, and cannot be changed. channel configuration is not required for channel process. after completing the channel configuration, please confirm the printing process type again: channel process. - 15 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com...
- Page 16 IX. Pathological System The Dakewe intelligent cassette printer is analyzes the pathological number file generated by the pathological system through the analysis function of the pathological system analysis program to print the corresponding pathological number. The user does not need to input the pathological number again. The following four steps are required for setting the pathological system analyzer: Select "select pathological system";...
- Page 17 As shown in Figure 9- 5, if the separator "-" cannot find the corresponding field in the corresponding relationship, it can be replaced by a user-defined field. - 17 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com...
- Page 18 Figure 9- 7 Excel File Correlation 3. Joint Rules The Dakewe intelligent cassette printer the pathological number to be displayed according to the Joint Rules. As shown in Figure 8-4, the contents to be displayed for printing : The Joint Rules are shown in Figure 9- 8 if the main pathological number, separator, trumpet and suffix.
- Page 19 Figure 9- 8 Joint Rules - 19 - Dakewe (Shenzhen) Medical Equipment Co., Ltd. www.dakewemedical.com...
