Triton ARGO 15 Manual

Hide thumbs Also See for ARGO 15:

Advertisement

Quick Links

Download this manual
ARGO 15 Touch Screen
Glass Replacement Manual
©2025 Triton Systems of Delaware, LLC. All Rights Reserved. ATMGurus®, the ATMGurus logo and tagline,
Triton®, and the Triton logo are all registered trademarks of Triton Systems of Delaware, LLC.  e third
party trademarks that may be identi ed herein are the trademark of their respective owners. Triton disclaims any
affi liation, connection, or association between its products and services, and those of the respective trademark
owners, or any sponsorship or approval of its products and services by such trademark owners.
TDN 07000-00446 Rev A

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARGO 15 and is the answer not in the manual?

Questions and answers

Related Manuals for Triton ARGO 15

Summary of Contents for Triton ARGO 15

  • Page 1 ©2025 Triton Systems of Delaware, LLC. All Rights Reserved. ATMGurus®, the ATMGurus logo and tagline, Triton®, and the Triton logo are all registered trademarks of Triton Systems of Delaware, LLC.  e third party trademarks that may be identi ed herein are the trademark of their respective owners. Triton disclaims any affi...

  • Page 2: Contact Information

    1 (800) 259-6672 (opt 3), 1 (228) 575-3175 (opt 3)   is document serve as instructional aid to technicians performing eld upgrade the ARGO 15 touch glass.   is manual applies to all service personnel involved in installing, converting, or upgrading hardware on Triton ATMs nationwide and abroad.
  • Page 3 ARGO 15 Touch glass and Display Bracket (Units manufacturer prior to January 9,2025) 09200-15002 Tools Required #1 and #2 Phillips screwdriver Parts Supplied Description Quantity Touch Screen, Display Bracket, and USB Data Cable Screw | #8-32 | 3/8 Inch | Pan Phil Head w/Ext Tooth Wash | RoHS...
  • Page 4 OFF (0) position. 3. Wear an Electrostatic Discharge device, wrist strap or gloves, grounded to ATM chassis before continuing. 4. Remove Baseboard cover. 5. Remove all cables connected to the Baseboard. TDN 07000-00446 Rev A Triton Systems ©...
  • Page 5 6. Remove and save the four screws, circles. Place Baseboard in a safe location for later re-installation. 7. On the Printer circuit board, disconnect the 6-pin connector, CN1, and the USB-B connector CN8 arrows. YELLOW TDN 07000-00446 Rev A Triton Systems ©...
  • Page 6 Remove YELLOW ribbons from the connectors, arrows. 11. Remove 2 screws securing the touch glass controller board to the bracket. Dispose the USB Cable and controller according to local law. TDN 07000-00446 Rev A Triton Systems ©...
  • Page 7  e Right Image, remove the ground wire connected to the printer chute, circle. • Remove the ground wire from display top-le , circle. 13. Remove and save the 4 screws across the top of the display bracket, arrows. TDN 07000-00446 Rev A Triton Systems ©...
  • Page 8 15. Hold hand against the touch-glass side of the display. Push glass up and li the display out of the Control Panel. 16. Place display assembly on a so surface, touch glass side up. TDN 07000-00446 Rev A Triton Systems ©...
  • Page 9 Le Image. Place bracket with the touch glass. Dispose of glass and bracket according to the local law. 20.  e Right Image, verify the two connectors are still connected to the display circuit board. TDN 07000-00446 Rev A Triton Systems ©...

  • Page 10: Installation

    23. Carefully li and rotate the Display Bracket onto lint-free so surface. 24. Le Image, li the display bracket, and carefully feed the ribbon cable out the bracket opening, arrows and place bracket on a lint-free so surface, Right Image. TDN 07000-00446 Rev A Triton Systems ©...
  • Page 11 28.  e Right Image, secure the Controller board to the bracket, and re-connect the USB cable. 29. Li and adjust display bracket to touch only the insulation tape on the Touchscreen glass, arrows. TDN 07000-00446 Rev A Triton Systems ©...
  • Page 12  e Le Image, install 2 screws on the lower le of the display, arrows. Screw may be under the cable bundle. •  e Right Image, install center lower display screw, le of the printer chute, Right Image, circle. TDN 07000-00446 Rev A Triton Systems ©...
  • Page 13  e Le Image, secure ground wires lower-le of the display bracket, circles. •  e Right Image, secure ground wire connecting to the printer chute, circle. • Secure ground wire on display top-le , circle. TDN 07000-00446 Rev A Triton Systems ©...
  • Page 14 Place paper roll on bracket, rectangle.  e Right Image, insert paper into the printer head, YELLOW and press Feed button, BLUE circle. 39. Return ATM to normal operations. E  P TDN 07000-00446 Rev A Triton Systems ©...
