Television
Téléviseur
Televisor digital a color con
pantalla de cristal líquido
Reference Guide
Manuel de référence / Guía de referencia
XR-98X90L / 85X90L / 85X90CL
XR-75X90L / 75X90CL / 65X90L
XR-65X90CL / 55X90L
Read this manual before using this product
Sony Customer Support
U.S.A.:
https://www.sony.com/tvsupport
Canada:
https://www.sony.ca/support
United States
Canada
1.800.222.SONY
1.877.899.SONY
Call the telephone number that appears
on your warranty card/policy.
Please do not return the product to the
store.
© 2023 Sony Corporation
Lisez ce manuel avant d'utiliser le produit
Service à la clientèle Sony
Canada :
https://www.sony.ca/support
États-Unis :
https://www.sony.com/tvsupport
Canada
États-Unis
1.877.899.SONY
1.800.222.SONY
Appelez le numéro de téléphone qui
apparaît sur votre carte/police de
garantie.
Ne retournez pas le produit au magasin.
5-048-778-12(1)
https://rd1.sony.net/help/tv/
kusltn1/h_usltn/
Lea este manual antes de usar el producto
Centro de Asistencia de
Sony
https://esupport.sony.com/ES/LA/
Llame al número de teléfono que aparece
en su tarjeta/póliza de garantía.
Por favor no devuelva el producto a la
tienda donde adquirió el producto.

Advertisement

loading
Need help?

Need help?

Do you have a question about the XR-98X90L and is the answer not in the manual?

Questions and answers

Related Manuals for Sony XR-98X90L

Summary of Contents for Sony XR-98X90L

  • Page 1 Television Téléviseur Televisor digital a color con pantalla de cristal líquido Reference Guide Manuel de référence / Guía de referencia https://rd1.sony.net/help/tv/ XR-98X90L / 85X90L / 85X90CL kusltn1/h_usltn/ XR-75X90L / 75X90CL / 65X90L XR-65X90CL / 55X90L Read this manual before using this product Lisez ce manuel avant d’utiliser le produit Lea este manual antes de usar el producto Sony Customer Support Service à la clientèle Sony Centro de Asistencia de Sony U.S.A.: Canada : https://www.sony.com/tvsupport https://www.sony.ca/support https://esupport.sony.com/ES/LA/ Canada: États-Unis : Llame al número de teléfono que aparece https://www.sony.ca/support https://www.sony.com/tvsupport en su tarjeta/póliza de garantía. Por favor no devuelva el producto a la United States...
  • Page 2 Dimensions and weight (without Table-Top Stand) / Dimensions et poids (sans support de table) / Dimensiones y peso (sin soporte de sobremesa) (mm)/(inches/pouces/pulgadas) (kg)/(lb.)     2199 / 86 1255 / 49 85 / 3 67.2 / 148.1 XR-98X90L 2 199 / 86 1 255 / 49 85 / 3 67,2 / 148,1 XR-85X90L / 1891 / 74 1085 / 42 59 / 2 44.5 / 98.1 85X90CL 1 891 / 74 1 085 / 42 59 / 2 44,5 / 98,1 XR-75X90L / 1668 / 65 959 / 37 59 / 2 35.4 / 78 75X90CL 1 668 / 65 959 / 37 59 / 2 35,4 / 78 XR-65X90L / 1445 / 57 831 / 32 57 / 2 24.2 / 53.4...
  • Page 3 Light sensor*    Buzzer*  The remote control shape, layout, availability and function of remote control buttons may vary depending on your region/country/TV model/TV settings.*  (Power) Display TV channel list or switch to input. (Quick settings): Display Quick Settings. (Input): Display and select the input source, etc. (Control menu): Display the Control menu.

  • Page 4: Important Notice

    Note: Uses the following device for wireless functionalities: Model: UE878 Brand: UEI * To see the model name of the remote control, open the remote control cover and see the label on the remote control. Safety Information Notice for customers in the United States of America Supplier’s Declaration of Conformity Trade Name: SONY Model: XR-98X90L / XR-85X90L / XR-85X90CL / XR-75X90L / XR-75X90CL / XR-65X90L / XR-65X90CL / XR-55X90L Responsible Party: Sony Electronics Inc. Address: 16535 Via Esprillo, San Diego, CA 92127 U.S.A. Telephone Number: 858-942-2230 Compatible Wall-Mount Bracket Information Use the following Sony Wall-Mount Bracket with your TV model. Sony TV Model No. XR-75X90L / 75X90CL / 65X90L /...
  • Page 5 Wall” if you want to mount the TV to a wall. If you are not mounting the TV to a wall, you will need to attach the Table-Top Stand (refer to the Setup Guide). Be sure to consider the following while setting up your TV: • Disconnect all cables when carrying the TV. • Two or more persons (three or more persons for 214.8 cm (85 inches), four or more persons for 247.7 cm (98 inches) and above TV) are needed to transport a large TV set. • Correct hand placement while carrying the TV is very important for safety and to avoid damage. • When handling or mounting the TV set, do not lay down the TV (for applicable TV model only). XR-98X90L XR-85X90L / 85X90CL XR-75X90L / 75X90CL / 65X90L / 65X90CL / 55X90L Securing the TV Sony strongly recommends taking measures to prevent the TV from toppling over. Unsecured TVs may topple and result in property damage, serious bodily injury or even death.
  • Page 6 Recommended Measures to Secure the TV Consider the following measures when securing your TV to a Stand (not supplied). Secure the Stand for the TV. Make sure the Stand can adequately support the weight of the TV. Use two angle braces (not supplied) to secure the Stand. For each angle brace use the appropriate hardware to: • Attach one side of the angle brace to the wall stud. • Attach the other side to the Stand. Angle brace (not supplied) Stand Secure the TV to the Stand. Use the optional hardware listed as follows (not supplied): • M6 machine screws (screwed into the TV’s Table-Top Stand) (XR-98X90L only). • M6 machine screws (screwed into the TV’s rear cover) (except XR-98X90L). • A screw or similar (attach it to the Stand). • Rope or chain (strong enough to support the weight of the TV). Make sure that there is no excess slack in the rope or chain. XR-98X90L M6 machine screw (not supplied) 1.5 N·m Rope or chain {15 kgf·cm} (not supplied) Screw hole on the TV’s Table-Top Stand Screw (not supplied)
  • Page 7 Screw hole on the rear cover (supplied) M6 machine screw (not supplied) Rope or chain (not supplied) 1.5 N·m Screw {15 kgf·cm} (not supplied) The length of the M6 machine screw differs depending on the rope or chain diameter. Please refer to below illustration. XR-98X90L 6 - 12 (mm) Screw (M6) Rope or chain TV’s Table-Top Stand XR-85X90L / 85X90CL / 75X90L / 75X90CL / 65X90L / 65X90CL / 55X90L 8 – 10 (mm) Screw (M6) Rope or chain Anchor the TV to the wall by using bolts, wall anchor and chain (or rope). XR-98X90L Wall-mount holes Rope or...
  • Page 8 XR-85X90L / 85X90CL / 75X90L / 75X90CL / 65X90L / 65X90CL / 55X90L Wall-mount holes (supplied) Rope or chain (not supplied) M6 eye bolts (not supplied) Wall-anchor (not supplied) Please refer to below illustration for M8 eye bolt length. XR-98X90L 11 - 20 (mm) M8 eye bolt TV’s rear cover Please refer to below illustration for M6 eye bolt length. XR-85X90L / 85X90CL / 75X90L / 75X90CL / 65X90L / 65X90CL / 55X90L 8 - 10 (mm) M6 eye bolt TV’s rear cover Note • Your TV is shipped with screws attached to...
  • Page 9 Installing the TV to the Wall Using the optional Wall-Mount Bracket (SU-WL855 only)* (not supplied) To Customers: For product protection and safety reasons, Sony strongly recommends that installation of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself. To Sony Dealers and Contractors: Provide full attention to safety during the installation, periodic maintenance and examination of this product. Wall-Mount Bracket Installation Information For instructions on Wall-Mount Bracket installation, see the Installation Information (Wall-Mount Bracket) on the Sony Customer Support website for your TV model at the following address.
  • Page 10 For product protection and safety reasons, Sony strongly recommends that installation of your TV on the wall be performed by qualified professionals. Do not attempt to install it yourself. • Follow the instruction guide provided with the Wall-Mount Bracket for your model. Sufficient expertise is required in installing this TV, especially to determine the strength of the wall for withstanding the TV’s weight. • The screws for installing the Wall-Mount Bracket to the TV are not supplied. • Refer to the following table for wall-mount hole pattern. Wall-mount hole...
  • Page 11 Wall-Mount Bracket (not supplied) Screw (not supplied) Note • If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to fasten the Wall-Mount Attachment when attaching them to the TV. Use only a flat head screwdriver to install the Wall-Mount Attachment. Use of another tool might result in over torqueing the Wall-Mount Attachment and damaging the TV. Detaching the Table-Top Stand from the TV XR-98X90L To detach the Table-Top Stand from the TV, remove the screws XR-85X90L / 85X90CL / 75X90L / 75X90CL / 65X90L / 65X90CL / 55X90L Remove one side of the Table-Top Stand at a time. Firmly hold the Table-Top Stand securely with both hands while the other people lift up the TV.  Repeat the previous step and remove the other side of the Table-Top Stand.
  • Page 12 Note • Be careful when lifting the TV as the Table-Top Stand is detached, the Table-Top Stand may topple over and cause personal injury. • Take care when removing the Table-Top Stand from the TV to prevent it from falling over and damaging the surface that the TV is sitting on. • Do not remove the Table-Top Stand for any reason other than to install corresponding accessories on the TV. • Be sure the TV is vertical before turning on. To avoid uneven picture uniformity do not power on the TV with the LCD panel facing down. XR-98X90L only • When attaching the Table-Top Stand again, be sure to fasten the screws (previously removed) to the original holes on the rear of the TV. Except XR-98X90L • Three or more people are required to detach the Table-Top Stand. • Be careful not to use excessive force while detaching the Table-Top Stand from the TV as it may cause the TV set to fall resulting in personal injury or physical damage to the TV. • Take care when handling the Table-Top Stand to prevent damage to the TV. Troubleshooting General troubleshooting for issues like: black screen, no sound, frozen picture, TV does not respond, or network is lost, do the following steps. Restart your TV by pressing the power button on the remote control for about five seconds. The TV will restart. If the TV does not recover, try unplugging the AC power cord then press the power button on the TV and release it. Wait for two minutes, and plug in the AC power cord. Or, press the power button on the TV for about 40 seconds until the TV turns off.
  • Page 13 (Input) on the remote control and select [Help]. If [Help] does not exist, select [Edit] and add [Help]. Specifications System TV system NTSC: National Television System Committee ATSC: 8VSB Terrestrial NEXTGEN TV: ATSC 3.0 compliant (Single tuner)* QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality) Channel coverage Depending on your country/area selection/TV model Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69* Analog Cable: 1 - 135 / Digital Cable: 1 - 135 Panel system LCD (Liquid Crystal Display) Panel, LED Backlight Speaker output (W) XR-98X90L: 10 + 10 + 10 + 10 XR-85X90L / 85X90CL / 75X90L / 75X90CL / 65X90L / 65X90CL / 55X90L: 10 + 10 + 5 + 5 Wireless technology Protocol IEEE 802.11a/b/g/n/ac Bluetooth® Version 4.2 Input/Output jacks CABLE/ANTENNA 75 ohm external terminal for RF inputs HDMI IN 1/2/3/4 (HDCP 2.3-compatible) Video: 4096 × 2160p (60 Hz)* , 4096 × 2160p (24 Hz)* , 3840 × 2160p (60 Hz)* , 3840 × 2160p (24, 30 Hz), 1080p (24, 30, 60, 120 Hz), 1080i (60 Hz), 720p (24, 30, 60 Hz), 480p, PC Formats* 3840 × 2160p (120 Hz)*...

  • Page 14: Online Registration

    Others Optional accessories Wall-Mount Bracket: SU-WL855 (except XR-98X90L / 85X90L / 85X90CL) Camera and Microphone Unit: CMU-BC1 Operating temperature 0 ºC – 40 ºC / 32 ºF – 104 ºF *1 Only for limited region/country/model. *2 2 – 36 for NEXTGEN TV scanning range in U.S.A. *3 When 4096 × 2160p is input and [Wide mode] is set to [Normal], the resolution is displayed as 3840 × 2160p. To display 4096 × 2160p, set [Wide mode] setting to [Full 1] or [Full 2]. *4 Refer to the on screen menu to set [HDMI signal format]. *5 Refer to the online Help Guide for details. *6 HDMI IN 3 and 4 only. Use the Ultra High Speed HDMI Cable to connect. *7 Connect your audio system to the HDMI IN 3 to route TV audio to your audio system. *8 Specified standby power is reached after the TV finishes necessary internal processes. *9 Standby power consumption will increase when your TV is connected to the network. Note • Optional accessories availability depends on countries/region/TV model/stock. • Design and specifications are subject to change without notice. • Subscriptions for services and applications may be required and additional terms, conditions and/or charges may apply when using Google Assistant. • Power consumption will increase when the built-in MIC is enabled as it is always listening. • Visit Sony website for more information on product specifications.
