Emergency
/ Duress
Keypad and Top
Control Lock
Front Microphone
Current Channel
Menu Select Keys
Home Button
Navigation Keys
Keypad with
Memory Store
Quick Reference Guide
APX™ 8000 Portable Radio
Menu
Radio controls
Channel Select
1 SES STH
001 FIRECOMM
BGNS91 P1
ChSr Zone Chan
Power On / Off,
Volume Control
Zone
Select
(A, B, C)
Current Zone
Radio Alias
Advertisement
Table of Contents
Related Manuals for Motorola APX 8000
Summary of Contents for Motorola APX 8000
- Page 1 Quick Reference Guide APX™ 8000 Portable Radio Radio controls Channel Select Power On / Off, Emergency Volume Control / Duress Zone Select (A, B, C) Keypad and Top Control Lock Front Microphone Current Zone 1 SES STH Current Channel 001 FIRECOMM Radio Alias BGNS91 P1 Menu...
- Page 2 Radio Controls Emergency Antenna / Duress Channel Select Power On / Off, Volume Control Top Display Microphone Main Speaker Audio Playback Push-to-talk (PTT) Battery Dim Backlight Channel Search Battery Latch Top Display Power On / Off, Volume Control Antenna 001 FIRECOM Zone Select (A, B, C) Emergency...
-
Page 3: Menu Options
Menu options TasGRN Conv Function menu menu ChSr ChSr Quick search for a specific channel Zone Zone Selects the zone of the radio Chan Chan Searches for a talkgroup Displays radio Lat/Long co-ordinates Rcnt Rcnt Select, Play or Store received audio Info Info Displays Radio information... - Page 4 Zones TasGRN Description Zone 1 SES STH South region 2 SES NTH North region 3 SES NW Northwest region 4 TFS OPS Incident and Tactical talkgroups 5 SES State, event and SAR talkgroups 6 TFS TRAIN TFS training talkgroups 7 GRN INTEROP Interop TGs accessible to SES Conventional Description...
-
Page 5: Menu Option Selection
Making a Voice Call Hold in the PTT button and wait for: 2 high beeps: network connection established talk. → 1 low beep: network busy release PTT, wait, and try again. → Menu Option Selection 1. Use the navigation buttons as necessary to search for the required menu option (see other side for available options). - Page 6 On: Radio is ready for data services Off: Radio is not ready for data services Blinking: Data registration services have failed Data activity is present Bluetooth is ready Bluetooth is connected to an authorised Motorola device Scan mode enabled...
