Kenwood 8452 - KAC Amplifier Instruction Manual

4/3/2 channel power amplifier.
Hide thumbs


Advertisement

KAC-8452
KAC-8402
4/3/2 CHANNEL POWER AMPLIFIER 7 page 2-7
INSTRUCTION MANUAL
AMPLIFICATEUR DE PUISSANCE 4/3/2 CANAUX 7 page 8-13
MODE D'EMPLOI
AMPLIFICADOR DE POTENCIA DE 4/3/2 CANALES 7 página 14-19
MANUAL DE INSTRUCCIONES
Take the time to read through this instruction manual. Familiarity
with installation and operation procedures will help you obtain the
best performance from your new power amplifier.
For your records
Record the serial number, found on the back of the unit, in the spaces
designated on the warranty card, and in the space provided below.
Refer to the model and serial numbers whenever you call upon your
KENWOOD dealer for information or service on the product.
Model KAC-8452/8402
Serial number
© B64-3015-00/01 (KV/EV)

Advertisement

   Related Manuals for Kenwood 8452 - KAC Amplifier

   Summary of Contents for Kenwood 8452 - KAC Amplifier

  • Page 1

    Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the model and serial numbers whenever you call upon your KENWOOD dealer for information or service on the product. Model KAC-8452/8402 Serial number...

  • Page 2: Safety Precautions

    • If the unit does not seem to be working right, consult your Kenwood dealer. • For the power cord and ground, use a vehicle type (fireproof ) power wring cord with a current capacity greater than the unit’s fuse capacity.

  • Page 3

    Installation Accessories Part name External View Number of Items Self-tapping screws (ø5 × 18 mm) Terminal cover (Power terminal) Speaker level input cable Hexagon Wrench Installation procedure Since there are large variety of settings and connections possible according to applications, read the instruction manual well to select the proper setting and connection.

  • Page 4

    Connection ■ RCA cable or Speaker level input connection 2WARNING To prevent fire caused by a short in the wiring, • RCA cable Connections connect a fusible link or breaker nearby the battery’s positive terminal. Power control wire CENTER UNIT 2CAUTION (CD receiver, etc.) •...

  • Page 5

    If you can’t find the specified capacity fuse at your $ FILTER switch (B.ch) cable input jacks and the speaker level input store etc., consult your Kenwood dealer. terminals simultaneously, for this may cause This switch allows to apply high-pass or low-pass 2 Battery terminal malfunction or damage.

  • Page 6

    System examples ■ 4-channel system ■ High-power 2-channel system Front Left speaker Left speaker (Bridged) CENTER UNIT CENTER UNIT Front Right speaker Rear Left speaker Right speaker (Bridged) Rear Right speaker ■ 2-channel + Subwoofer system (1) ■ 2-channel + Subwoofer system (2) Left speaker (High pass) Left speaker (High pass) CENTER UNIT...

  • Page 7: Troubleshooting Guide

    Troubleshooting Guide What might appear to be a malfunction in your unit may just be the result of slight misoperation or miswiring. Before calling service, first check the following table for possible problems. PROBLEM POSSIBLE CAUSE SOLUTION No sound. • Input (or output) cables are disconnected. •...
