SCPH-30002 R

SCPH-30003 R

SCPH-30004 R

SCPH-30000 R series

SERVICE MANUAL

6th edition

for GH015(31/41) MOUNT

( F-type model )

Quality Asurance Department

Published in Japan

2.2002. 9-927-093-61

Need help?

Do you have a question about the SCPH-30002 R and is the answer not in the manual?

Questions and answers

Summary of Contents for Sony SCPH-30002 R

Page 1 All manuals and user guides at all-guides.com SCPH-30002 R SCPH-30003 R SCPH-30004 R SCPH-30000 R series SERVICE MANUAL 6th edition for GH015(31/41) MOUNT ( F-type model ) Quality Asurance Department Published in Japan 2.2002. 9-927-093-61...
Page 2 6. Check the b+ voltage to see it is at the values specified. Replace the battery with a Sony CR2032 battery. Use of any other type of battery may present the risk of fire or 7. Check the antenna terminals, metal trim, “metalized” knobs, screws, and all other exposed metal parts for ac explosion.
Page 3 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model TABLE OF CONTENTS SCPH-30000 R F-type model with GH015(31/41) MOUNT NOTICE AND REVISION ............ GH015(31/41)-2 SPECIFICATIONS ............. GH015(31/41)-4 SUPPLIED ACCESSORIES AND PACKING BLOCK ..GH015(31/41)-5 INSTRUCTION MANUAL BLOCK .........
Page 4 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model SPECIFICATIONS General Inputs/Outputs on the front Power requirements Controller ports (2) 220 -240 V AC, 50/60 Hz Memory card slots (2) USB ports (2) S400 (i-Link) port (1) Inputs/Outputs on the rear HDD bay slot (1) Power consumption...
Page 5 • RESISTORS METAL : Metal-film resistor. F : nonflammable Unit is SUPPLIED ACCESSORIES and PACKING GROUP PLACE CODE #23 *********************************************************************** SCPH-30002 R F-type model SCPH-30003 R F-type model SCPH-30004 R F-type model ************************* ************************* ************************* Ref. Part No. Description Ref. Part No.
Page 6 • RESISTORS METAL : Metal-film resistor. F : nonflammable Unit is INSTRUCTION MANUAL BLOCK ASSY PLACE CODE #23 ******************************************************* SCPH-30002 R F-type model SCPH-30003 R F-type model SCPH-30004 R F-type model ************************* ************************* ************************* Ref. Part No. Description Ref. Part No.
Page 7 TERMINAL BOARD (FRONT) 1-694-874-11 TERMINAL BOARD (FRONT) 1-694-875-11 TERMINAL BOARD (FRONT) 3-072-419-01 LABEL, MODEL NUMBER (AU3) for SCPH-30002 R F 3-072-418-01 LABEL, MODEL NUMBER (CEK) for SCPH-30003 R F Power Switch, 3-072-417-01 LABEL, MODEL NUMBER (CEL) for SCPH-30004 R F...
Page 8 GUIDE (R) 3-065-557-01 SCREW (M2X6.0) CAUTION : EEPROM DATA is different between optical device made by Sony and made by Sanyo.EEPROM DATA have to rewrite BASED ON replacing OPTICAL DEVICE. CAUTION : OPTICAL DEVICE is very delicate to static electricity.
Page 9 SHEET (DRIVER), ELECTRIC HEAT X-3952-061-1 SHIELD A (F) ASSY X-3952-256-1 SHIELD A ASSY (F) GH015 A-6715-504-A GH-015(31/41) COMPL #25GH for SCPH-30002 R A-6714-504-A GH-015(31/41) MOUNT 3-059-652-01 SHEET (A), ELECTRIC HEAT GH015 A-6715-505-A GH-015(31/41) COMPL #25GH for SCPH-30003 R /-30004 R...
Page 10 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model Switch Assy Block ------------------- SWITCH ASSY BLOCK ------------------- A-6705-439-A SWITCH ASSY BLOCK Ref-No. Part No. Description Remark Place code 3-059-665-03 BUTTON, SWITCH #25SW 3-059-666-05 BRACKET, SWITCH #25SW 3-066-494-01 BRACKET, SWITCH...
Page 11 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model Power Switch, Fan and Rear Panel Assy Block CAUTION The components identified by CAUTION : mark or dotted line with mark. Use of controls or adjustments or performance are critical for safety.
Page 12 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model BLOCK DIAGRAM IOP+EDO-DRAM EE+RDRAM GS+VIDEO IC202 IC210 CN302 IC303 IC104 IC206 VCLK EMOTION ENGINE 221,268 CN201 CONTROLLER 1 DATA 394-425 RO0-7 6,7,10-15 270-274 DIGITAL AD0-31 11-74 CONTROLLER 1 DATA 3-34 C-OUT...
Page 13 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. Note on Printed Wiring Boards : • Through hole is omitted. •...
Page 14 All manuals and user guides at all-guides.com SCPH-30000 R series DIG_+1.8V1 DIG_+1.5V1 DIG_+1.5V1 CL107 IOP Interface R139 MSCLK IC303 1 pin PLL SELECT /SRST IC303 49 pin 1:NEW 2:OLD /SGINT IC303 47 pin IC101 FB103 R133 /SINT IC303 48 pin /BGNT IC303 43 pin FB102...
Page 15 All manuals and user guides at all-guides.com SCPH-30000 R series C278 C279 C282 C286 0.47u 0.47u 0.47u 0.47u R214 DIG_+3.5V1 DIG_+2.5V1 DIG_-1.5V3 RB242 NTPAL IC206 8 pin BO00 BO01 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 BO02 BO03 BO04...
Page 16 All manuals and user guides at all-guides.com SCPH-30000 R series R328 DIG_+1.8V2 SD15 DREQ9 SA26 IC501 57 pin IC505 34 pin, IC504 133 pin IC501 25 pin DIG_+3.5V1 SA25 IC501 58 pin SD14 IC505 32 pin, IC504 132 pin DACK9 IC501 29 pin SD13 DREQ8...
Page 17 All manuals and user guides at all-guides.com SCPH-30000 R series IC403 JL412 PS001 EVER_+3.3V REGULATOR Q411 IC415 PS009 /7VDET /RESET HDD_+5V C458 0.001u PS005 JL427 0.7A HDD_+12V 3.5V C476 C462 C426 0.1u 0.001u C407 C408 0.1u Q415 C425 0.1u 0.1u L413 Q412 L412...
Page 18 All manuals and user guides at all-guides.com SCPH-30000 R series IC505 IC502 C517 0.47u C508 BOOT+DVD ROM 0.47u C516 DRAM 0.47u CL520 CL521 IC303 239 pin, IC605 164 pin /CS5 IC303 220 pin, IC605 168 pin /INT5 R531 JL550 IC303 232 pin, IC605 166 pin DREQ5 /CS1 SA21...
Page 19 All manuals and user guides at all-guides.com SCPH-30000 R series (RFDC) JL608 /INT5 IC303 220 pin, IC501 33 pin C601 1.50V - 2.45VDC 0.1u DACK5 IC303 227 pin, IC501 30 pin (HXL-505 PLAYBACK) JL607(CE) RFDC DREQ5 IC303 232 pin, IC501 26 pin R651 /CS5 IC303 239 pin, IC501 18 pin...
Page 20 All manuals and user guides at all-guides.com SCPH-30000 R series IC806 IC803 PS012 R853 1.2A SPINDLE DRIVER R854 C882 R855 R875 IC807 IC805 C883 R868 R873 R856 2.2 0.1u 220k 1/10W R876 CN804 13P Q814 5V REG CL805 C791 R872 R874 R877 PS013...
Page 21 All manuals and user guides at all-guides.com SCPH-30000 R series ANA_+5V R251 R259 Q204 1.8k R253 IC205 70 pin MODE2 IC205 69 pin MODE1 IC205 68 pin MODE0 C263 R257 R252 1.8k C285 IC202 252 pin 0.47u RGBYC R261 4.7k IC205 72 pin TRSNK1 IC205 71 pin...
Page 22 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model CN303 12 11 IC303 IC305 RB332 FB314 C313 R320 C314 C369 C368 EDO-DRAM X301 C373 C372 C338 C490 C355 CL101 C132 R102 C425 X401 R101 RB148 R139 R395 CL107...
Page 23 All manuals and user guides at all-guides.com SCPH-30000 R series F-type model USB PORTS i-Link PORTS CN303 CL503 D501 R531 C339 C337 RB511 JL550 C518 FROM (BR) C843 (16.4MHz) RB317 C341 C340 CL513 LOADING CL809 CN302 (TRAY-OUT) MOTOR R347 C334 C868 FL303 C324...
Page 24 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited ELECTRIC PARTS LIST F-type model Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description 1-683-434-12 PWB, GH-015 C164 1-128-964-91 CAP, CHIP TANTALUM ELECT 100MF C270 1-107-826-91 CAP, CHIP CERAMIC 100000PF B C364 1-107-826-91...
Page 25 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description C475 1-164-227-91 CAP,CERAMIC 22000PF B (1608) C630 1-164-173-91 CAP,CERAMIC 3900PF B (1608) C792 1-104-851-91 CAP, CHIP TANTALUM ELECT 10MF...
Page 26 LINK, IC (CCP2E63) <DIODE> FB315 1-469-324-21 FERRITE, EMI (SMD) IC505 6-702-303-01 IC K3NSV106SB-TC1AT00 PS004 1-576-398-21 LINK, IC (CCP2E63) for SCPH-30002 R PS005 1-533-915-41 FB316 1-469-324-21 FERRITE, EMI (SMD) IC505 6-801-708-01 IC MR27V4812F-018TMZ LINK, CHIP IC for SCPH-30002 R IC505 6-702-304-01...
Page 27 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description PS011 1-533-282-21 LINK, IC Q814 8-729-029-13 TRANSISTOR DTC143ZUA-T106 R278 1-218-859-91 RES, CHIP 3.3K (1608) R442...
Page 28 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description R649 1-216-833-91 RES, CHIP 10K (1608) R874 1-216-828-91 RES, CHIP 3.9K (1608) RB403 1-233-415-21 RES, CHIP NETWORK 10K...
Page 29 All manuals and user guides at all-guides.com SCPH-30000 R series Reproduction Prohibited F-type model SWITCH MOUNT CN751 R753 OP/CL_SW R751 R752 2.4k 10k/8.2k 15k/6.8k POWER_SW S751 S752 TRAY_LED_ON D752 S752 S751 CL–190UB2–X–T /GREEN_ON /RED_ON D751 D752 R753 D751 Q751 EVER_+12V CL–165HR/G1–D–T / CL–165HR/G2–D–T SW-367/SW-367(VA)
