K-5208 Transport Cart
EN
Read these instructions and the warnings
and instructions for all equipment and ma-
terial being used before operating this tool
to reduce the risk of serious personal injury.
SAVE THESE INSTRUCTIONS!
• Position the K-5208 Transport Cart on a
clear, level, stable location. This will reduce
the risk of tipping.
• Be aware of the cart weight. Fully loaded cart
can weigh up to 210 lbs. (95 kg). Use appropri-
ate lifting methods.
• Do not lift K-5208 Drain Cleaner to lift cart.
Cart can separate from drain cleaner and fall,
increasing the risk of injury.
If you have any question concerning this RIDGID
product:
com, or in the U.S. and Canada call (800)
519-3456.
Description
RIDGID
K-5208 Transport Cart allows wheeled
®
movement of the K-5208 Drain Cleaning Machine
and Cable Carrier and can support the K-5208
machine during operation (Figure 1).
Specifications
Overall size: ............ 19.5" x 46.2" x 22.1"
Weight:
Transport Cart
only: .....................54lbs (25 kg)
Transport Cart w/K-5208, carrier
and cable: ...........210lbs (95 kg) Max.
Inspection/Maintenance
Clean the K-5208 Transport Cart to aid inspection
and improve control. Inspect before each use for
proper assembly, wear, damage, modification or
other issues that could affect safe use.
If any problems are found, do not use until cor-
rected.
Lubricate all moving parts/joints as needed with
light lubricating oil. Wipe up excess oil.
Set-Up/Operation
Setting Kickstand
Set the kickstand as shown in Figure 2 to help
stabilize and hold the cart in place when not
moving. Clip kickstand up when moving cart.
WARNING
(49.5 x 117.3 x 56.1 cm)
(without K-5208)
19.5" x 46.2" x 25"
(49.5 x 117.3 x 63.5 cm)
(with K-5208)
®
son.
Advertisement
Related Manuals for RIDGID K-5208
Summary of Contents for RIDGID K-5208
- Page 1 • Be aware of the cart weight. Fully loaded cart can weigh up to 210 lbs. (95 kg). Use appropri- ate lifting methods. • Do not lift K-5208 Drain Cleaner to lift cart. Cart can separate from drain cleaner and fall, increasing the risk of injury.
- Page 2 Loading K-5208 and Cable Carrier On Cart 1. Set kickstand. 2. Place K-5208 frame in cart hooks. K-5208 must be fully seated in all four hooks to be properly held to cart (Figure 3). 3. Place the cable carrier on frame against the cable carrier arms.
- Page 3 Patas de soporte Figure 1 – K-5208 Transport Cart Figure -5208 Figura 1 – Carrito transportador de K-5208 Figure 3 – Loading Machine on Cart Figure 3 – Montage du dégorgeoir Figura 3 – Cómo cargar la máquina sobre el carrito Figure 5 –...
- Page 4 Evacuation Desagüe Figure 4 – Operating K-5208 On Cart Figure 4 – Utilisation du dégorgeoir sur chariot Figura 4 – Funcionamiento de la K-5208 montada en el carrito Figure 6 – Storage/Transport Figure 6 – Remisage et transport Figura 6 – Almacenamiento y transporte...
