AirStation Pro Quick Setup Guide
WAPS-APG600H / WAPS-AG300H
Package Contents
• Wireless LAN access point ...............................................................................1
• Antennas (Dual-band, 2.4 GHz and 5 GHz)................................................2
• Antenna caps (already attached to antennas) .........................................2
• AC adapter.............................................................................................................1
• Power cable.................................................................................................. 1 or 2
• Bracket ....................................................................................................................1
• Ceiling-mounting screws (large)...................................................................4
• Wall-mounting screws (medium) .................................................................4
• Wall-mounting anchor (for medium-size screws)...................................4
• Screws (small, 5 mm *) ......................................................................................2
• Screws (small, 4 mm *) ......................................................................................2
• Spacers (Ring-shaped metal part).................................................................2
• Ejector (L-shaped part)......................................................................................1
• Serial number stickers........................................ one sheet with 2 stickers
• Quick Setup Guide..............................................................................................1
• Warranty Statement...........................................................................................1
*
The "length" here refers to the length of the section shown in the
figure.
Installation
Antenna Placement
Connecting the AC Adapter
If PoE is not available, connect the AC adapter to the AirStation as
shown below.
AC adapter
1
Use the supplied AC adapter to connect the equipment to a
UPS, power strip, or outlet.
2 Turn on the AirStation.
3 Confirm that the power LED on the front panel of the AirStation
is lit.
Remove the antenna caps and attach the
supplied antennas. Avoid touching the
conductive parts of the antenna
connectors while installing as they can be
easily damaged.
Note: These antennas support both 2.4 GHz and 5
Power button
Ethernet cable
GHz.
EN
Administrator
Computer
Advertisement
Related Manuals for Buffalo AirStation Pro
Summary of Contents for Buffalo AirStation Pro
- Page 1 AirStation Pro Quick Setup Guide WAPS-APG600H / WAPS-AG300H Package Contents • Wireless LAN access point ................1 • Antennas (Dual-band, 2.4 GHz and 5 GHz)..........2 • Antenna caps (already attached to antennas) .........2 • AC adapter......................1 • Power cable....................1 or 2 •...
- Page 2 Setup Setting the AirStation IP Address Start AirStation Configuration Tool. To start, select Start > All Programs > BUFFALO > AirStation Utility > AirStation Con guration Tool. Click Next. Select the AirStation to configure, then click Next. Click Change IP Address.
- Page 3 Accessing the Admin Interface Start the AirStation Configuration Tool. Click Next. Select the AirStation to configure and click Next. Click Go to Settings. Click OK. To log in to the admin interface, enter "admin" for the username and "password" for the password. Click OK. Wireless &...
- Page 4 AirStation off the bracket. Main Default Settings Wireless Radio Disabled SSID 1 BUFFALO-XXXXXX (the last 6 digits of the AirStation's Wired LAN MAC Address) + "_A" or "_G". Multiple SSIDs Disabled Wireless Channel...
