Quick Start Reference
G100
(.5~10HP)
Introduction
This quick start reference is
meant to be a supplement to
the User Manual. This reference
informs the installer of the
proper steps for mounting,
wiring, and basic programming
& operation of the G100 VFD up
to 7.5kW/10HP.
CAUTION!
Improper wiring and operation
may result in serious personal
injury or death.
Follow the recommended wiring
practices suggested in this
document as well as the User
Manual. The minimum size of
the protective earth (ground)
conductor shall comply with
local safety regulations and
applicable codes.
LSIS USA Inc.
980 Woodlands Parkway
Vernon Hills, IL 60061
800‐891‐2941
Advertisement
Related Manuals for LSIS G100
Summary of Contents for LSIS G100
- Page 1 Quick Start Reference G100 (.5~10HP) Introduction This quick start reference is meant to be a supplement to the User Manual. This reference informs the installer of the proper steps for mounting, wiring, and basic programming & operation of the G100 VFD up to 7.5kW/10HP. CAUTION! Improper wiring and operation may result in serious personal injury or death. Follow the recommended wiring practices suggested in this document as well as the User Manual. The minimum size of the protective earth (ground) conductor shall comply with local safety regulations and applicable codes. LSIS USA Inc. 980 Woodlands Parkway Vernon Hills, IL 60061 800‐891‐2941...
- Page 2 Step 1 – G100 Model Number and Mounting Verify that you have ordered and received the correct VFD by checking the nameplate information. Utilize the example name plate below to assist you with this. Model # and Order Code Input Ratings Output Ratings Serial # Important! Verify that the input voltage rating matches the voltage source which will be applied to the VFD. Confirm that the output power of the VFD is equal to or greater than the rating of the motor which will be connected. Mounting In order to maximize the lifespan of your G100 VFD, follow the proper installation and environment recommendations. The User Manual contains further details on the exact dimensions and weights of each capacity G100. Cover Removal To access power and control terminal wiring, the front cover and control terminal cover must be disassembled. Loosen the captive screw that secures the front cover (right side). Push and hold the latch on the right side of the cover, then remove the cover by lifting it from the bottom and away from the inverter.
- Page 3 Step 2 – Connect Line and Motor Power Utilize the below wiring diagrams to properly wire the main power connections to the VFD. This step should be done with power OFF! Refer to the User Manual for proper wire gauge recommendations. Be sure to follow good wiring and grounding practices. Follow applicable local codes if needed. Danger! Lethal voltages are present. Be sure that all power is turned OFF while performing the recommended power wiring. Reinstall all protective covers on the G100 before reapplying power Below is the proper wiring for both Single Phase and Three phase applications. The physical terminal layout will change across the different G100 capacities and enclosure types. Terminal names (e.g. R, S, T, etc) will remain consistent. Single Phase Input G100 1‐phase AC Input Three Phase Input G100 Grounding Chassis ground terminals can be found near the bottom on all chassis types and sizes.
- Page 4 Then press the ENT key TWO Times to save the Setting Command Source value. Press DN arrow to Press Mode/Shift and Press UP arrow until change setting to a 0 the Up or Down arrow drv is displayed. Then press ENT key to return to the TWO Times to save. frequency display. Then press ENT to display the setting. This makes the RUN/STOP keys the command source. Checking Direction Check that it is safe to run the motor at low speed. When ready, press to RUN the motor. The display will briefly show the output frequency of the VFD until it reaches 10Hz. Look at the motor shaft to verify rotation is correct. Press the key to STOP. If motor direction is incorrect, stop the motor with the key, and power down the VFD. Wait at least 5 minutes to let the VFD capacitors discharge. Swap any two output leads between the VFD and the motor. This will change motor direction. Verify correct rotation via the previous steps. LSIS S100 Quick Start Reference .5‐30HP Rev B...
- Page 5 Step 4 – S100 Keypad Navigation and Parameter Changes Navigate and select different parameters by using the directional arrows on the keypad ( ). From the main screen (0.00), the UP and DN arrows will navigate through the operation group. The drive group contains many basic start up parameters and monitors. See a partial list of operation group parameters below. Pressing the Mode/Shift key will move through the different parameter groups. While the UP and DN arrows will navigate through the different parameter code #’s in the selected group. Any of the parameters and monitor settings can be accessed by pressing the ENT key. Pressing the ENT key again, or the following key combinations will return to the initial display. Changing Acceleration Time Example Press UP arrow from the main display (0.00) until is displayed. Press ENT key one time to display the current setting. Use the UP and DN arrows to increase and decrease the value. Use the LEFT or RIGHT arrows to move the cursor over to select different digits. Press the ENT key TWO TIMES once the desired value is set. This saves the change. will be displayed again indicating the parameter change has taken effect. Important: Press the ENT key two times to save parameter changes!
-
Page 6: Step 5 - Control Wiring
Step 5 – Control Wiring This step shows common wiring examples for both the run command and frequency reference. Run Command Wiring 2‐Wire Control 2‐wire control consists of maintained run signals. This can be accomplished via toggle switches, relays, jumpers, etc. Default parameters support this operation. P1=Forward Run (Fx) P2=Reverse Run (Rx) CM=Common 3‐Wire Control 3‐Wire control consists of momentary push buttons to run and stop the VFD. The Forward and Reverse buttons are Normally Open while the Stop button is Normally Closed. Set parameter In67=14 if using P3 (like below) for the Stop button. P1 = Forward Run (Fx) P2 = Reverse Run (Rx) P3 = Stop (3‐Wire) CM = Common Frequency Reference Wiring Speed POT Wiring (0‐10VDC) Controlling the VFD with an external speed POT can be accomplished by setting frq=2 and wiring like below. For 0‐10VDC signals from a PLC or Controller simply wire to V1 and CM. VR = 10VDC VI = Wiper CM = Common PLC or Controller Wiring (4‐20mA) For speed control over a 4‐20mA signal set frq=5. I2 = + Signal CM = ‐ Common... -
Page 7: Basic Setup Parameters
Step 6 – Basic Setup Parameters The basic drive and motor parameters are shown on the below table. Set the parameters according to your specific application. Required Motor Parameters Set the below motor parameters based on the motor nameplate. HP to kW conversion chart Motor RPM to Poles chart Example: If actual motor RPM is 3450. Set Motor Poles = 2. This is due to motor slip. In this example The motor has 150 RPM of slip. (Slip=Synchronous speed‐Rated Speed) Commonly Set Parameters Optional Parameters • To automatically start after a power loss, set Ad.10=1. • Enable phase loss protection by setting the virtual dipswitches in Pr.5 both to the up (top) position. • Enable auto restart after a fault trip by setting the below… • Pr.8= 1 • Pr.9= # of retry attempts LSIS USA Inc. 980 Woodlands Parkway Vernon Hills, IL 60061 LSIS S100 Quick Start Reference 800‐891‐2941 .5‐30HP Rev B...
