Installation Instructions
Tracer Summit™BMTB Bridge
Order Numbers: BMTB001AAA000, BMTB001BAA000
1
For more detailed installation instructions refer to the Tracer
Communications Bridge - Comm 3/4 to Tracer SC Setup and Configuration
Guide (BAS-SVX64).
Only qualified personnel should install and service the equipment. The
installation, starting up, and servicing of heating, ventilating, and air-
conditioning equipment can be hazardous and requires specific
knowledge and training. Improperly installed, adjusted or altered
equipment by an unqualified person could result in death or serious
injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the
equipment.
March 2016
SAFETY WARNING
X39641236-01C
