- Page 1 User Manuel Freezer - Fridge Bedienungsanleitung Kühl-Gefrierkombination Manuel d’utilisation Congélateur – Réfrigérateur Manuale per l’uso Congelatore - Frigorifero Handleiding Vriezer - Koelkast FC84EN4HM1...
- Page 2 Warning; Risk of fire / flammable materials FIRE BRANDGEFAHR Warnung; Brandgefahr / entflammbare Materialien Avertissement; Risque d'incendie / matières INCENDIE inflammables Avvertenza; Rischio di incendio / Materiali INCENDIO infiammabili Waarschuwing; Gevaar voor brand / ontvlambare BRAND materialen...
-
Page 3: Table Of Contents
INDEX BEFORE USING THE APPLIANCE ............5 General warnings ..................... 5 Safety warnings ....................8 Installing and operating your fridge freezer ............9 Before Using your Fridge ................10 THE VARIOUS FUNCTION AND POSSIBILITIES ........11 Information about New Generation Cooling Technology ........ 11 Display and Control Panel ................ - Page 4 TECHNICAL DATA ................. 32 INFORMATION FOR TEST INSTITUTES ..........32 CUSTOMER CARE AND SERVICE ............32 EN -4-...
-
Page 5: Before Using The Appliance
PART - 1. BEFORE USING THE APPLIANCE General warnings This appliance is not intended to be used as a built-in appliance. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 6 • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • This appliance is intended to be used in household and domestic applications such as: - staff kitchen areas in shops, offices and other working environments.
- Page 7 older children (8-14 years old) and vulnerable people can use appliances safely after they have been given appropriate supervision or instruction concerning use of the appliance. Very vulnerable people are not expected to use appliances safely unless continuous supervision is given. •...
-
Page 8: Safety Warnings
Old and out-of-order fridges or freezer • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore, take care not to harm environment when you are discarding your old fridges. -
Page 9: Installing And Operating Your Fridge Freezer
• Do not place glass bottles or cans in the ice-making compartment as they will burst when the contents freeze. • Do not place explosive or flammable material in your fridge. Place drinks with high alcohol content vertically in the fridge compartment and make sure their tops are tightly closed. -
Page 10: Before Using Your Fridge
• Before using your fridge freezer, wipe all parts with a solution of warm water and a teaspoon of sodium bicarbonate. Then, rinse with clean water and dry. Return all parts to the fridge freezer after cleaning. The bottom cabinet cover is the metal The condenser of your fridge is placed at the bottom of cabinet. -
Page 11: The Various Function And Possibilities
PART - 2. THE VARIOUS FUNCTION AND POSSIBILITIES Information about New Generation Cooling Technology Fridges with new-generation cooling technology have a different operating system to static fridges. Other (static) fridges may experience a build up of ice in the freezer compartment due to door openings and humidity in the food. -
Page 12: Display And Control Panel
Display and Control Panel Using the Control Panel 1. It is cooler set value screen. 2. It is super cooling indicator. 3. It is freezer set value screen. 4. It is super freeze indicator. 5. It is alarm symbol. 6. It is child-lock symbol. 7. -
Page 13: Super Cool Mode
Notes: • The maximum amount of fresh food (in kilograms) that can be frozen within 24 hours is shown on the appliance label. • For optimal appliance performance in maximum freezer capacity, activate Super Freeze mode 3 hours before you put fresh food into the freezer. •... -
Page 14: Holiday Mode
Holiday Mode How Would It Be Used? • Push "MODE" button until holiday symbol appears • If no button is pressed for 1 second. Mode will be set. Holiday symbol will blink 3 times. When mode is set, buzzer will sound beep beep. •... -
Page 15: Screen Saver Mode
Screen Saver Mode Purpose This mode saves energy by switching off all control panel lighting when the panel is left inactive. How To Use? • This mode will be activated when you press on "MODE" button for 3 seconds. • If no button is pressed within 30 seconds when he mode is active, lights of the control panel will go off. -
Page 16: Temperature Settings
Temperature Settings Freezer Temperature Settings • The initial temperature value for the freezer setting indicator is -18°C. • Press the set freezer button once. • When you first push this button, the last set value will blink on the screen. •... -
Page 17: Temperature Adjustment Warnings
Temperature Adjustment Warnings • It is not recommended that you operate your fridge in environments colder than 10°C in terms of its efficiency. • Do not start another adjustment while you are already making an adjustment. • Temperature adjustments should be made according to the frequency of door openings, the quantity of food kept inside the fridge and the ambient temperature in the location of your fridge. -
Page 18: The Freezer Box
The Freezer Box The freezer box allows food to be accessed more easily. Removing the freezer box: • Pull the box out as far as possible • Pull the front of the box up and out Carry out the opposite of this operation when refitting the sliding compartment. -
Page 19: Adjustable Door Shelf
Adjustable Door Shelf Five different height adjustments can be made to provide storage areas that you need by adjustable door shelf. To change the position of adjustable door shelf; Lift up front of the shelf (1) and move up or down adjustable door shelf (2) with both hands (Pict. - Page 20 Cooked dishes must remain covered when they are kept in the fridge. Place them in the fridge when they are cool, otherwise the temperature/humidity inside the fridge will increases, reducing the fridge’s efficiency. Covering food and drink also preserves their flavour and aroma.
-
Page 21: Freezer Compartment
Freezer compartment • The freezer is used for storing frozen food, freezing fresh food, and making ice cubes. • To use the maximum capacity of the freezer compartment, use the glass shelves for the upper and middle section, and use the lower basket for the bottom section. •... - Page 22 The table below is a quick guide to show you the most efficient way to store the major food groups in your freezer compartment. Maximum storage time Meat and fish Preparation (months) Steak Wrap in foil 6 - 8 Lamb meat Wrap in foil 6 - 8 Veal roast...
- Page 23 Maximum storage time Vegetables and Fruits Preparation (months) Spinach Wash and boil in water 6 - 9 Remove the leaves, cut the heart into pieces and leave it in water with a little lemon juice 10 - 12 Cauliflower for a while Eggplant Cut into pieces of 2cm after washing 10 - 12...
-
Page 24: Cleaning And Maintenance
PART - 4. CLEANING AND MAINTENANCE Disconnect the unit from the power supply before cleaning. Do not wash your appliance by pouring water on it. Do not use abrasive products, detergents or soaps for cleaning the appliance. After washing, rinse with clean water and dry carefully. When you have finished cleaning, reconnect the plug to the mains supply with dry hands. -
Page 25: Repositioning The Door
Repositioning the Door • It is not possible to change the opening direction of your appliance door if door handles are installed on the front surface of the appliance door. • It is possible to change the opening direction of the door on models without handles. •... - Page 26 ERROR TYPE MEANING WHAT TO DO 1. Set the freezer temperature to a colder value or set Super Freeze. This should remove the error code once the required temperature has been reached. Keep doors closed to improve time taken to reach the correct temperature.
- Page 27 ERROR TYPE MEANING WHAT TO DO 1. Check is Super Cool mode is activated 2. Reduce the fridge compartment temperature Fridge compartment is too Various 3. Check to see if vents are cold clear and not clogged If this warning continues an authorised technician needs to be contacted.
- Page 28 Air blowing noise occurs: During normal operation of the system due to the circulation of air. There is a build-up of humidity inside the fridge Check if: • All food is packed properly. Containers must be dry before being placed in the fridge. •...
-
Page 29: Hints For Energy Saving
Hints for Energy Saving 1. Install the appliance in a cool, well-ventilated room, but not in direct sunlight and not near a heat source (such as a radiator or oven) otherwise an insulating plate should be used. 2. Allow warm food and drinks to cool before placing them inside the appliance. 3. -
Page 30: The Parts Of The Appliance And The Compartments
THE PARTS OF THE APPLIANCE AND THE PART - 7. COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. A. Fridge compartment 8. Ice tray * B. Freezer compartment 9. -
Page 31: Dimensions
Dimensions Overall dimensions 1860 775,7 Space required in use 2010 815,7 Overall space required in use 1535,2 1547,5 EN -31-... -
Page 32: Technical Data
The original spare parts for some specific components are available for a minimum of 7 or 10 years, based on the type of component, from the placing on the market of the last unit of the model. Visit our website to: Get User manuals: https://www.smeg.com/info/download-manuals Get Service information: https://www.smeg.com/services/customer-service EN -32-... - Page 33 52560533...
