- Page 1 FR NOTICE EN INSTRUCTIONS DE ANLEITUNG WINDY HZ ACCEL SIMU S.A.S. au capital de 5 000 000 € Zone Industrielle Les Giranaux 70100 ARC-LÈS-GRAY - FRANCE RCS VESOUL B 425 650 090 SIRET 425 650 090 00011 N° T.V.A CEE FR 87 425 650 090...
- Page 2 FR: Par la présente SIMU déclare que l’équipement radio couvert par ces instructions est conforme aux exigences de la Directive Radio 2014/53/UE et aux autres exigences essentielles des Directives Européennes applicables. Le texte complet de la déclaration UE de conformité...
- Page 3 Never drop, knock, drill or submerge from extending to protect it. sensor. The Windy Hz Accel is designed only for roller, Do not use abrasive products or solvents encased or cassette type folding arm patio clean the sensor.
- Page 4 Abbild Figure C pas. s enregistrer un Windy Hz darüber informieren, was bei der Benutzung Le Windy Hz Accel se fixe sur la barre ’eau, ni En fonction du moyen de fixation choisi, à plusieurs moteurs. Bezeichnung und Wartung des Produkts zu beachten ist.
- Page 5 Replace the sensor b motor, see section 6.1. 7. Method of operation Figure K ocedure for deleting the Windy Hz Accel from a motor Slide the assembly onto the bracket (g) until it hits the stop: programmed are low. see section 8.1.
- Page 6 FR - Veiller à séparer les piles et batteries des autres types de déchets et à les recycler via le système local de collecte. EN - Please separate storage cells and batteries from other types of waste and recycle them via your local collection facility. DE - Batterien und Akkus gehören nicht in den Hausmüll.
-
Page 7: Technical Data
After set up, make sure that the threshold ccording to pre-set values. set enables the awning to be raised. The Windy Hz Accel will only function is sufficient to provide protection when the assembly (e) + (f) is fixed to the of applications. - Page 8 Windy Hz Accel will detect motion and prevent the awning from extending to protect it. The Windy Hz Accel is designed only for roller, encased or cassette type folding arm patio awnings. The Windy Hz ACCEL is compatible with Hz motors: Hz.02, DMI Hz, ESP Hz, ZSP Hz from...
-
Page 9: Specific Safety Advice
If in doubt when installing this product and/or to obtain additional information, contact a SIMU adviser or go to the website www.simu.com. 2.2. Specific safety advice Never drop, knock, drill or submerge the ... - Page 10 Green indicator light k. Battery housing l. Programming button (PROG.) 5. Installation 5.1. Recommendations Figure C The Windy Hz Accel is fixed to the front bar at either end or in the middle. Vibration detection is more effective at either end.
- Page 11 The Windy Hz Accel must never be enclosed in the front bar! The sensor must not be more than 20 m from the motor. Operation can be affected by devices with high power radio functions (such as wire- less headphones) that operate on the same transmission frequency.
-
Page 12: Fitting The Batteries
If the position is on the inner face of the front bar: check that the Windy Hz Accel, when mounted on its bracket (g), does not obstruct the closure of the awning and is not damaged during this operation. - Page 13 Figure G The motor must have already been set and programmed to a control point. Do not program a Windy Hz Accel to several motors. Take a remote control that is already programmed in the memory of the motor.
- Page 14 of the awning according to pre-set values. This sensitivity is sufficient to provide protection for the majority of applications. Setting “Pre-defined threshold” Figure H Set the potentiometer (h) to the required threshold using a flat blade screwdriver: Threshold 1: light vibration will trigger the retraction of the awning.
- Page 15 After the threshold is set, the sensor will switch to demonstration mode for the first two cycles. This mode enables users to easily modify the selected setting. Pressing the STOP button once will stop the awning retracting and allow the user to modify the sensitivity threshold by manually shaking the awning.
-
Page 16: Method Of Operation
When the sensor stops detecting any vibration for 30 seconds: the application can be controlled in manual mode. If the Windy Hz Accel is connected to a sun sensor and the sun comes out, then the awning will extend after 12 mins. - Page 17 (g) until it reaches the stop. 8.2. Deleting a Windy Hz Accel from a motor Figure K The procedure for deleting the Windy Hz Accel from a motor is identical to the programming procedure: see section 6.1. “Programming the Windy Hz Accel to a motor”.
-
Page 18: Tips And Recommendations
9. Tips and recommendations 9.1. Questions on the Windy Hz Accel ? Possible Observations Solutions causes The batteries Check the direction in which None of the LEDs come on after the are incorrectly the batteries are inserted into batteries are fitted. - Page 19 Possible Observations Solutions causes External radio The awning does equipment Turn off all radio equipment not automatically is interfering retract when the nearby. with the radio wind increases. reception The batteries Replace the sensor batteries, are low. see section 8.1. The sensor Engage the sensor in the is incorrectly...
- Page 20 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: - this device may not cause harmful interference, and - this device must accept any interference received, inclu- ding interference that may cause undesired operation. Warning ! Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate...
