We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• ATTENTION: during use, the
appliance and its accessible
parts become very hot.
Children must be kept away
from the appliance.
• ATTENTION: during use, the
appliance and its accessible
parts become very hot. Never
touch the heating elements
during use.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
91477B646/A
35
35
38
39
39
39
39
39
39
40
40
40
40
40
41
41
41
41
42
42
42
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may be used by
children aged at least 8 and by
people of reduced physical,
sensory or mental capacity, or
lacking in experience in the use
of electrical appliances,
provided that they are
supervised or instructed by
adults who are responsible for
their safety.
• Children must not play with the
43
43
43
48
49
49
49
49
51
52
54
54
54
55
56
57
57
58
59
60
60
PRECAUTIONS - 35
Advertisement
Table of Contents
Related Manuals for Smeg SFP9302TN
Summary of Contents for Smeg SFP9302TN
-
Page 1: Table Of Contents
Electrical connection Preliminary operations We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions • Never try to put out a fire or... - Page 2 appliance. APPLIANCE WHILST IT IS IN • Keep children under the age of USE. 8 at a safe distance unless they • DO NOT MODIFY THIS are constantly supervised. APPLIANCE. • Keep children under the age of • Installation and servicing should 8 away from the appliance be carried out by qualified when it is in use.
- Page 3 and towards the back of the paper, place it so that it will not oven cavity. interfere with the hot air circulation inside the oven cavity. • Do not use the open door to rest pans or trays on the internal glass pane.
-
Page 4: For This Appliance
• The appliance must not be maintenance, positioning or installed on a pedestal. movement). • Position the appliance into the • Before performing any work on cabinet cut-out with the help of the appliance, switch off the a second person. power supply. -
Page 5: Appliance Purpose
• Do not install/use the • use of non-original spare parts. appliance outdoors. Identification plate The identification plate bears the technical data, • Only use the temperature serial number and brand name of the probe provided or appliance. Do not remove the identification recommended by the plate for any reason. -
Page 6: Energy Efficiency Technical Data
Information on power consumption in off/stand-by mode Technical data on the appliance's power consumption in off/stand-by mode can be found at www.smeg.com under the page corresponding to the product in question. Light sources • This appliance contains user-replaceable 40 - PRECAUTIONS... -
Page 7: Description
DESCRIPTION General description 1 Control panel 4 Door 2 Seal 5 Fan 3 Light bulb Frame shelf Control panel 1 Function knob • The duration of a function. • Programmed cooking procedures These touch buttons or this knob can be used to: •... -
Page 8: Accessories
Cooling fan supplied by the manufacturer. Rack Used for supporting containers with food during cooking. Tray The fan cools the appliance and comes into operation during cooking. The fan causes a steady outflow of air from above the door which may continue for a short period of time even after the appliance has been turned off. -
Page 9: Using The Accessories
Digital programmer 2. Heat the empty oven compartment at the maximum temperature to burn off any residues left by the manufacturing process. When heating the appliance • air the room; • don't stay. Using the accessories Racks and trays Racks and trays have to be inserted into the side guides until they come to a complete stop. -
Page 10: Using The Oven
4. Turn the temperature knob to adjust the low light. hours. 5. Press the button to set the hours and move to the minutes. 6. Turn the temperature knob to adjust the minutes. 7. Press the button to confirm. It may be necessary to change the current time, for example for daylight saving time. - Page 11 2 Turn the temperature knob to the right or left 4. Check the progress of the cooking by to select the required temperature (e.g. switching on the oven light. “200°C”). End of cooking 5. To stop cooking, turn the functions knob back to 0 to exit the function.
- Page 12 display. appears on the display. 4. Turn the temperature knob to set the cooking 7. Turn the function knob back to 0. end time (for example “13:15”). When the button is pressed, the function is displayed again with the same parameters as the function that has just ended.
- Page 13 Minute minder timer during cooking GRILL It allows to obtain excellent grilling and The minute minder timer does not stop grating results. Used at the end of the cooking operation but rather informs cooking, it gives a uniform browning to the user when the set time has run out.
-
Page 14: Cooking Advice
Cooking advice • To defrost meat, use the rack placed on the second level and a tray on the first level. In General advice this way, the liquid from the defrosting food • Use a fan assisted function to achieve drains away from the food. -
Page 15: Mini Guide To Accessories
QR Press and hold the button to exit code on the leaflet supplied with the product. - Page 16 remain disabled. 5. Press the button to confirm. After activating the Sabbath function, the settings cannot be altered. Any action on the knobs and/or the buttons on the display will have no effect; only the functions knob remains active to allow you to return to the main menu.
-
Page 17: Secondary Functions
flash on the display. 5. Press the button to confirm. 2. Turn the temperature knob to set the duration 6. Press the button of the minute minder timer (from 1 minute to 7. Turn the temperature knob to set the defrost 23 hours). -
Page 18: Settings
inactivity. 7. Press the button to confirm. During normal operation, the controls To cancel the operation, press and hold lock is indicated by the light coming button for a few seconds. If the buttons on the display are touched Settings or the position of the knobs is changed, •... - Page 19 1. After having accessed the settings menu, 1. After having accessed the settings menu, press the button to select the press the button to select the keep showroom function. warm function. 2. Turn the temperature knob to activate the 2. Turn the temperature knob to activate the showroom function.
-
Page 20: Other Settings
2. Turn the temperature knob right or left to 2. Turn the temperature knob to disable the select the required brightness, from 1 (low sound associated with touching the symbols brightness) to value 5 (high brightness). on the display. 3. Press the button to move to the next setting or press the button to confirm. -
Page 21: Cleaning The Door
microfibre cloth. Cleaning the door glazing Do not allow residues of sugary foods (such as The glass in the door should always be kept jam) to set inside the oven. If left to set for too thoroughly clean. Use absorbent kitchen roll. In long, they might damage the enamel lining of case of stubborn dirt, wash with a damp sponge the oven. -
Page 22: Cleaning The Oven Cavity
glass 8. Be sure to fit the 4 pins of the inner glass well into their seats on the door. 5. Clean the external glass pane and the panes removed previously. Cleaning the oven cavity In order to keep your oven in the best possible condition, clean it regularly after letting it cool down. -
Page 23: Special Cleaning Functions
slide it out of the seats B at the back. the deflector. We recommend spraying approx. 20 times at the most. Do not spray the deflector if it has a self- cleaning coating. • Close the door. • During the assisted cleaning cycle, wash the self-cleaning panels (where fitted), which were previously removed, separately in warm water and a small amount of... -
Page 24: Pyrolytic (On Some Models Only)
3. Press the button to start the function. We recommend removing the door in order to make the manual cleaning of The duration and temperature the parts that are difficult to reach parameters cannot be changed by the easier. user. Pyrolytic (on some models only) When finished, flashes on the display... -
Page 25: Extraordinary Maintenance
the display (factory set to 2:30 hours). During the first Pyrolytic cycle, unpleasant odours may occur due to the normal evaporation of oily manufacturing substances. This is an absolutely normal phenomenon which disappears after the first pyrolytic cycle. If the pyrolytic cycle gives unsatisfactory results at minimum duration, it is recommended to set a longer time for subsequent cleaning cycles. -
Page 26: Installation
Replacing the internal light bulb Do not touch the halogen light bulb Power voltage directly with your fingers, use an Danger of electrocution insulating material. 5. Replace the light bulb with one of the same • Unplug the appliance. type (40 W). •... - Page 27 • 220-240 V~ A = position of the power cable 2. Lift the rear casing slightly and remove it to gain access to the terminal board. 3. Replace the cable. 4. Make sure that the cables (for the oven or any hob) follow the best route in order to avoid any contact with the appliance.
- Page 28 5. Cover the bushings with the previously removed covers. Appliance overall dimensions (mm) 62 - INSTALLATION 91477B646/A...
- Page 29 Mounting into a column (mm) Make sure that the cabinet top/rear section has an opening approx. 35-40 mm deep. 91477B646/A INSTALLATION - 63...
- Page 30 Mounting under worktops (mm) If the appliance is to be built-in under a worktop, a wooden bar has to be installed order to use the seal that is glued to the back of the front panel to prevent water or other liquids leaking in. A min.
- Page 31 Built-in under hobs (mm) Whenever a hob is installed above the oven, a wooden separator has to be installed at a minimum distance of 20 mm from the top of the oven to prevent overheating when the two appliances are used at the same time. It must only be possible to remove the separator by using suitable tools.
