- Page 1 CD RDS RECEIVER AUTORADIO CD RDS SINTOLETTORE CD RDS REPRODUCTOR DE CD CON RECEPTOR RDS CD RDS-EMPFÄNGER CD RDS-ONTVANGER DEH-S110UB DEH-S111UB DEH-S110UBA DEH-S111UBG DEH-S110UBG DEH-S11UB DEH-S110UBB Quick start guide Guide de démarrage rapide Guida rapida all’uso Guía de iniciación rápida...
- Page 2 - Safety requirements, IEC 60065. CAUTION This product is a class 1 laser product classified under the Safety of laser products, IEC 60825-1:2007. If you experience problems Should this unit fail to work properly, please contact your dealer or nearest authorized PIONEER Service Station.
- Page 3 Connections Important • When installing this unit in a vehicle without an ACC (accessory) position on the ignition switch, failure to connect the red cable to the terminal that detects operation of the ignition key may result in battery drain. ACC position No ACC position • Use of this unit in conditions other than the...
- Page 4 to ground. − Never band together negative cables of multiple speakers. • When this unit is on, control signals are sent through the blue/white cable. Connect this cable to the system remote control of an external power amp or the vehicle’s auto-antenna relay control terminal (max.
-
Page 5: Power Cord
Power cord To power cord input Depending on the kind of vehicle, the function of may be different. In this case, be sure to connect Yellow Back-up (or accessory) Yellow Connect to the constant 12 V supply terminal. Accessory (or back-up) Connect to terminal controlled by the ignition switch (12 V DC). -
Page 6: Power Amp (Sold Separately)
Yellow/black If you use equipment with a Mute function, wire this lead to the Audio Mute lead on that equipment. If not, keep the Audio Mute lead free of any connections. Speaker leads White: Front left White/black: Front left Gray: Front right Gray/black: Front right Green: Rear left or subwoofer... -
Page 7: Installation
Installation Important • Check all connections and systems before final installation. • Do not use unauthorized parts as this may cause malfunctions. • Consult your dealer if installation requires drilling of holes or other modifications to the vehicle. • Do not install this unit where: −... - Page 8 DIN mount installation Insert the supplied mounting sleeve into the dashboard. Secure the mounting sleeve by using a screwdriver to bend the metal tabs (90°) into place. Dashboard Mounting sleeve • Make sure that the unit is installed securely in place. An unstable installation may cause skipping or other malfunctions.
- Page 9 Removing the unit (installed with the supplied mounting sleeve) Remove the trim ring. Trim ring Notched tab • Releasing the front panel allows easier access to the trim ring. • When reattaching the trim ring, point the side with the notched tab down. Insert the supplied extraction keys into both sides of the unit until they click into place.
-
Page 10: Basic Operation
Basic operation DEH-S110UB/S110UBA/S110UBG/S110UBB/S111UB/S111UBG/S11UB BASS USB port (eject) M.C. (multi-control) dial SRC (source)/OFF Disc loading slot DISP (display) Detach button Display window BAND/ AUX input jack (3.5 mm stereo jack) About the main menu You can adjust various settings in the main menu. - Page 11 Frequently used operations Purpose Operation Press SRC/OFF to turn on the Turn on the power power. Press and hold SRC/OFF to turn off the power. Turn the M.C. dial. Adjust the volume Press SRC/OFF repeatedly. Select a source Press DISP repeatedly. Change the display information Press BAND/ Return to the previous display/list...
-
Page 12: Setup Operation
[100], [50] If you experience problems Should this unit fail to work properly, please contact your dealer or nearest authorized PIONEER Service Station [QUIT :YES] appears when all the settings have been made. To return to the first item of the setup menu, turn the M.C. dial to select [QUIT :NO], then press to confirm. -
Page 13: Tuner Operation
Tuner operation Receiving preset stations Press SRC/OFF to select [RADIO]. Press BAND/ to select the band. [FM1] [FM2] [FM3] [MW]/[LW] Press a number button (1/ to 6/ ). Best stations memory (BSM) After selecting the band, press the M.C. dial to display the main menu. - Page 14 CD/USB/AUX operation Insert a disc into the disc loading slot with the label side up. To eject a disc, stop playback first then press . Open the USB port cover. Plug in the USB device using an appropriate cable. MTP connection A device installed with Android OS 4.0 or most of later versions can be connected to the unit via MTP, using the cable supplied with the Android device.
- Page 15 Turn the M.C. dial to select [P.APP AUTO ON], then press to confirm. Turn the M.C. dial to select [ON], then press to confirm. Connect this unit with the Android device via USB. Pioneer ARC APP on the device starts automatically.
- Page 16 Pioneer vakuuttaa, että radiolaitetyyppi [*] on direktiivin Español: 2014/53/EU mukainen. Por la presente, Pioneer declara que el tipo de equipo EU-vaatimustenmukaisuusvakuutuksen täysimittainen radioeléctrico [*] es conforme con la Directiva 2014/53/UE. teksti on saatavilla seuraavassa internetosoitteessa: http:// El texto completo de la declaración UE de conformidad www.pioneer-car.eu/compliance...
