MIDLAND 777/MIDLAND 777E
DUAL BAND (PMR446/LPD) AND PMR446 TRANSCEIVER
1
1
8
7
6
The MIDLAND 777 represents the very latest and most advanced technology currently available
on the portable radios'market.
With its stylish lines and modern design, the MIDLAND 777 is a real gem of a radio!
The multitude of features such as the backlit LCD Display and VOX (hands free communication)
offered on this radio are only a fingertip away thanks to its easy to use controls.
Smaller than a credit card, extra slim, light weight and ultra compact design: all means that this
radio is ideal for use in any application, no matter where you are.
The MIDLAND 777 incorporates all of the very latest technical innovations that you might normally
expect to see on a mobile phone such as a Lithium-Ion long life battery and Vibralarm (Vibrating
incoming call alert).
Despite its small size, the MIDLAND 777 is big on features and offers a real alternative to
other forms of communication over short to medium ranges and has the added bonus of being
completely free to operate!
2
3
2
4
3
5
4
5
1. Display
2. 1 pin jack for recharge/earphones
3. Scan/Lock
4. On/Off - MODE
5. Speaker
6. Microphone
7.
/
8. PTT
8
7
6
Advertisement
Table of Contents
Related Manuals for Midland 777
Summary of Contents for Midland 777
- Page 1 The MIDLAND 777 represents the very latest and most advanced technology currently available on the portable radios’market. With its stylish lines and modern design, the MIDLAND 777 is a real gem of a radio! The multitude of features such as the backlit LCD Display and VOX (hands free communication) offered on this radio are only a fingertip away thanks to its easy to use controls.
-
Page 2: Main Features
10 Km. Content 2 MIDLAND 777 transceivers, 2 belt clips, 2 neck collars, 1 double desktop charger, 1 wall charger with double jack, instruction sheet... -
Page 3: Let's Communicate
Simply release the PTT [8] button. When you receive a signal, “RX” is displayed. Automatic power save MIDLAND 777 is supplied with an automatic current economy circuit. If the transceiver receives no signal for 7 seconds or longer the “power save function” automatically activates. This may increase the battery life by up to 50 %. -
Page 4: Key Functions
“Ch” will by replaced by “FL” which will disappear after one minute. If you charge the radio when it’s switched on, “Ch” and the channel in use are alternately displayed. When the recharge is complete, “FL” will be displayed instead of “Ch”. Keypad lock Press and hold the SCAN [3] button for longer than 3 seconds. -
Page 5: Ctcss-Sub-Tone Setting
With this procedure, you won’t hear any beep at the pressure of any button. Call tone MIDLAND 777 can send 3 different call tones. To send this audio signal to other users, press rapidly the PTT [8] key twice. To select the call tones: 1. -
Page 6: Dual Watch
Now, each time your MIDLAND 777 will send out a tone call, it will beep with the selected melody. To disable this feature, set “of” on the display. Note: when Vibralarm is enabled (‘ON’ setting) the call tone won’t be heard. -
Page 7: Frequency Channels
επιτραπέζιος φορτιστής, 1 φορτιστής τοίχου με διπλό βύσμα, οδηγίες χρήσης Frequency channels ΑΣ ΕΠΙΚΟΙΝΩΝΗΣΟΥΜΕ! PMR446 Ενεργοποίηση/ απενεργοποίηση (on/off) του πομποδέκτη Channel Frequency RX/TX (MHz) Channel Frequency RX/TX (MHz) Κρατήστε πατημένο το πλήκτρο MODE [4] για 3 δευτερόλεπτα. Η συσκευή εκπέμπει 3 διαφορετι 446.00625 446.05625 446.01875... - Page 8 Neuerungen bei Ihrem Fachhändler. Pour voir la liste de nôtres accessoires compatibles, vous pouvez consulter notre website www.midlandradio.eu Consulte nuestra web www.midland.es para una lista actuali- zada de los accesorios compatibles Consulte o nosso website www.midlandradio.eu para uma lista actualizada de acessórios Για...
- Page 9 • INFORMAZIONE AGLI UTENTI Ai sensi dell’art. 13 del decreto legislativo 25 luglio 2005, n.151 “Attuazione delle Direttive 2002/95/CE, 2002/96/CE e 2003/108/CE, relative alla riduzione dell’uso di sostanze pericolose nelle apparecchiature elettriche ed elettroniche, nonché allo smaltimento dei rifiuti”. • Il simbolo del cassonetto barrato riportato sull’apparecchiatura indica che il prodotto alla fine della propria vita utile deve essere raccolto separatamente dagli altri rifiuti.
- Page 10 ALAN UK ALAN ELECTRONICS GmbH μια εκπομπή, πατήστε το πλήκτρο PTT [8]. Ο πομποδέκτης MIDLAND 777 θα εκπέμψει στο appositi contenitori per la raccolta. Unit 2, Callenders, Paddington Drive, Churchward Park, Swindon, Wiltshire, Deutschland, Daimlerstraße 1K - D-63303 Dreieich...
