Summary of Contents for Midland 777 PRO
- Page 1 User manual 777 PRO PMR446/LPD TRANSCEIVER...
- Page 2 Index Main features The package includes Coverage referred to the PMR446 frequency band Above all... Safety! Warnings Identifying the parts Radio Display Recharging the Li-Ion battery pack “PB-777PRO” Basic operations Turning on/off Selecting the PMR446 bands: 16CH or 8CH How to activate the PMR446 bands Volume adjustment Squelch adjustment Transmission and reception...
-
Page 3: Table Of Contents
Channel selection CTCSS /DCS tones selection Selecting high or low transmission power (PMR band) ROGER BEEP function (End transmission tone) CALL function Keypad Beep Vibra-Call function Dual Watch Troubleshooting and radio reset Reset Technical specifications Midland 777 PRO user manual... -
Page 4: Main Features
Jack 1 Pin 4 contacts 3.5mm for external earphone/mike • Recharge through the microUSB port or desktop charger Extended PMR446 band: it is possible to use either the PMR446 traditional band or a “new” one (8 further PMR446 channels). Midland 777 PRO user manual... -
Page 5: The Package Includes
• Do not throw batteries into fire or place them near heat as this may cause ex- plosions or personal injuries. Dispose of the batteries according to procedures set out by local regulations Midland 777 PRO user manual... -
Page 6: Identifying The Parts
▼ – this control is useful to change the settings in the menu and to adjust the volume level /MENU – Keep pressed to turn on/off 777 PRO. Press to enter the radio’s menu. SPK/MIC jack – Jack for external speaker/mike 3.5mm 10. -
Page 7: Display
The three smaller digits indicate the CTCSS tone or DCS code se- lected (CTCSS: 1-38; DCS: 1–104) Type of subaudio tone selected DCSCTCSS Vibra-Call function activated This icon indicates the radio is operating on the new 8 PMR446 channels Midland 777 PRO user manual... -
Page 8: Recharging The Li-Ion Battery Pack "Pb-777Pro
To turn off the transceiver, keep pressed again the MENU button for 3 seconds. Selecting the PMR446 bands: 16CH or 8CH 777 PRO can operate on two PMR446 bands thanks to a simple procedure de- scribed in this chapter: a traditional band with 8 channels and a new one with 16 channels. -
Page 9: Volume Adjustment
Scanning all channels 777 PRO can automatically search for signals throughout the PMR/LPD bands by scanning, i.e. selecting the channels in rapid sequence. When a signal is detected, the scanning pauses on that channel and you can transmit by pushing PTT . -
Page 10: Display Backlight
5 seconds. When the batteries are discharged, “bt LO” appears on the display: recharge the battery pack. When the backlight is always on, the Power Save won’t be enabled. 10 | Midland 777 PRO user manual... -
Page 11: Channel Selection
LPD: from 1 to 69. Press the PTT button to confirm, or wait for 5 seconds. CTCSS /DCS tones selection 777 PRO can receive in two modes: • Open traffic: in this case you will hear any communication transmitted on the selected channel;... -
Page 12: Roger Beep Function (End Transmission Tone)
By pushing ▲/▼ you will hear the 5 pre-set melodies. Confirm by pressing the PTT or wait for 5 seconds. Now, each time your 777 PRO sends out a call tone, it will beep with the selected melody. 12 |... -
Page 13: Keypad Beep
Confirm by pushing the PTT or wait for 5 seconds. Now you won’t hear any beep at the pressure of any button. Vibra-Call function 777 PRO is equipped with the “Vibra-Call” feature, which provides a vibration for incoming calls. To activate it, follow these steps: In the PMR band, press the MENU button for 9 times, until the display shows Use the ▲/▼... -
Page 14: Troubleshooting And Radio Reset
Troubleshooting and radio reset 777 PRO is designed to provide you with years of optimal performance. If for some reason any problems arise, refer to this chapter before contacting a service centre in your region. Reset If your transceiver experiences a logical malfunction (improper symbols on the di- splay, blocking of functions, etc.), it may not be experiencing a true failure, but... -
Page 15: Technical Specifications
3 (for LPD only) Jack for ext speaker/mike jack stereo 3.5 mm Maximum TX time in 1 hour 6 minutes, equivalent to a duty cycle of 10% Specifications are subject to change without notice. Midland 777 PRO user manual | 15... - Page 16 The use of this transceiver can be subject to national restrictions. Read the instructions carefully before installation and use. Importado por: MIDLAND IBERIA, SA C/Cobalt, 48 - 08940 Cornellà de Llobregat (Barcelona - España) www.midland.es El uso de este equipo puede estar sujeto a la obtención de la correspondiente autorización administrati- va.
