Brook Wireless Fighting Board User Manual

The PS4+ Audio & Wireless ghting board supports to be
used wired or wirelessly on PS4/PS3/NS/PC, it also supports
LED, 3DVR, touch key and audio(PS4 only) function.
Function
• Bluetooth wireless connection and wired connection on
PS4/ PS3/ NS/ PC
• 18 digital inputs:
R2, L3, R3, Option, Share, PS key, Touch Key
• LS /RS/DP emulate or switch
• 4 Player LEDs
• Touchpad & 3DVR (optional)
• Turbo key
• 3.5mm audio connector (PS4 only)
• 2 SOCD selection
How To Use On Di erent Consoles
Wired Use
1. Hold down the button
2. While holding down the button, connect the board
to according console to use.
Note: The default is in PS4 mode if the designated button is not
hold down upon plug-in, and it can be simply connected to
PC without pressing any button.
Wireless Use
PS3/ PS4/ NS:
Wired used for the first time. For wireless use in the future, press
the PS/ Home key, the board will reconnect with the console.
PC:
Hold down SHARE, then hold down PS Key for 2 seconds. If you
have installed Player LED, then you' ll see the LED intermittently
flash, which shows the board has entered wireless pairing mode.
At the moment, you should see « Wireless Controller« in your
Bluetooth device list to pair.
Battery and Charge
To fulfill the wireless use function, a battery is needed, and you
can choose PS3/PS4 official controller's battery for the PS4+
Audio & Wireless fighting board. When the battery is charging
without connecting the board to console, you would see
breathing light on player LED.
, ○, □, △, Up, Down, Left, Right, L1, R1, L2,
╳
1P for PS3
2P for PS4
3P for NS
PS4
PS3
Switch
