Chapter 2. Configuring an APC Switch as a Fence Device
Component Name
cluster node clusternode2.example.com node in cluster apcclust configured with APC switch to
cluster node clusternode3.example.com node in cluster apcclust configured with APC switch to
IP address 10.15.86.96
login apclogin
password apcpword
port 1
port 2
port 3
Table 2.1. Configuration Prerequisities

2.2. APC Fence Device Components to Configure

This procedure configures an APC switch as a fence device that will be used for each
node in cluster apcclust. Then the procedure configures that switch as the fencing
device for clusternode1.example.com, clusternode2.example.com, and
clusternode1.example.com.
Table 2.2, "Fence Device Components to Configure for APC Fence Device"
the components of the APC fence device that this procedure configures for cluster node
clusternode1.example.com.
Fence Value
Device
Component
Fencing APC Power Switch
Type
Name apcfence
IP address 10.15.86.96
login apclogin
4
Comment
administer power supply
administer power supply
IP address for the APC switch that controls
the power for for clusternode1.example.com,
clusternode2.example.com, and
clusternode3.example.com
login value for the APC switch that controls
the power for for clusternode1.example.com,
clusternode2.example.com, and
clusternode3.example.com
password for the APC switch that controls
the power for for clusternode1.example.com,
clusternode2.example.com, and
clusternode3.example.com
port number on APC switch that
clusternode1.example.com connects to
port number on APC switch that
clusternode2.example.com connects to
port number on APC switch that
clusternode3.example.com connects to
Description
type of fencing device to configure
name of the APC fencing device
IP address of the APC switch to configure as a fence
device for node1.example.com, node2.example.com,
node3.example.com
login value for the APC switch that controls
the power for for clusternode1.example.com,
