- Page 1 Quick Start Guide Model: 9600...
- Page 2 Thank You for Purchasing S 360™ ECUR Welcome to S 360 by HeathZenith. This quick start ECUR guide will help you setup the S 360 doorbell system. ECUR For additional support, go to www.heath-zenith.com/Se- cur360. Important Information • Minimum system requirement for the S...
- Page 3 Know Your System • Use the illustration below to get to know the different components of your new S ECUR doorbell. Push Button Backplate Camera Lens Microphone Push Button LED Indicator Ring Speaker Chime Wires Power (Connect to Module existing chime wires) Spade Connectors (Connect to chime...
- Page 4 Mount the Push Button Backplate • Remove existing wired push button. • Using a small phillips screwdriver, remove the screw on the bottom of the video doorbell to remove back. • Insert the existing push button wires through the hole in the backplate. •...
- Page 5 Wire the Push Button Backplate • A) Using a small phillips screwdriver, attach the two wires from the chime and transformer to the screw terminals on the push button backplate. NOTE: The wires may be connected to either screw. • B) To activate the battery, open the side of the rubber cover labeled “RST”...
- Page 6 Install the Power Module • Remove the chime cover from the existing chime. • Label the chime wires according to the terminal they are attached to (TRANS, FRONT, REAR). • Remove the transformer (TRANS) wire and connect it to one of the wires on the power module using the wire quick connect (includ- ed).
- Page 7 Ensure the orange quick connect paddles are completely up (perpendicular) before inserting chime wires. After wires are inserted, press the orange paddles down to secure the wires. Gently pull on the wires to ensure they are secured. Example 1: Electronic chime Example 2: Mechanical chime...
- Page 8 Download the S 360 App ECUR • Go to the App Store or Google Play™ and search for the “S 360” app and download. ECUR Create a S 360 Account ECUR • On your mobile device, open the S 360 app ECUR and press the “Register”...
- Page 9 “Add a Device” button. • Ensure “Add Manually” is selected at the top of the screen. • Select “HeathZenith” in the left-hand column and then select “Video Doorbell”. • Press “Confirm indicator slowly blinks” button. • Ensure the correct network is selected and type the network password.
- Page 10 Setup Your Chime Type • IMPORTANT: If you have a mechanical chime (see example 2), no setup is necessary. • For electronic chimes (see example 1), open the 360 app. ECUR • Go to “Settings” > “Bell Settings” > “Digital”. •...
- Page 11 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 12 For additional support, go to www.heath-zenith.com/S ECUR...
