Frient Electricity Meter Interface Installation Manual

Hide thumbs Also See for Electricity Meter Interface:
1
2
3
4
5
6
7

Advertisement

Table of Contents

eng
Electricity Meter Interface
INSTALLATION MANUAL
Product description
The
Electricity Meter
readings from your existing electricity meter
and, via a compatible hub, the data is sent to a
connected device, e.g. your smartphone.
This way, the Electricity Meter Interface
enables
consumption remotely.
Precautions
• Do not remove the product label as it
contains important information.
• It is a good idea to take a picture of the
electricity meter before installation so
you can save the number of imp/kWh.
Occasionally, the number is close to the
LED and by attaching the probe you might
cover the number.
Version 1.1
you
to
Interface
follow your
collects
electricity

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Electricity Meter Interface and is the answer not in the manual?

Questions and answers

Related Manuals for Frient Electricity Meter Interface

Summary of Contents for Frient Electricity Meter Interface

  • Page 1 Electricity Meter Interface collects readings from your existing electricity meter and, via a compatible hub, the data is sent to a connected device, e.g. your smartphone. This way, the Electricity Meter Interface enables follow your electricity consumption remotely. Precautions • Do not remove the product label as it contains important information.

  • Page 2: Getting Started

    2. Place enclosed AA-batteries into the device respecting the polarities. 3. The Electricity Meter Interface will now start searching (up to 15 minutes) for a Zigbee network to join. 4. Make sure that the Zigbee network on your hub is open for joining devices and will accept the Electricity Meter Interface.

  • Page 3: Installation Steps

    Meter Interface successfully joined the Zigbee network. Installation steps The Electricity Meter Interface is equipped with an optical probe, which is easily attached to your meter. 1. Insert the end of the probe into the indicated socket on the Electricity Meter Interface.
  • Page 4 -20 and +60°C, close to the electric- ity meter. Resetting Resetting is needed if you want to reconnect your Electricity Meter Interface or if you need to perform a factory reset to remove abnormal behaviour. STEPS FOR RESETTING 1. Open the casing of the device.

  • Page 5: Battery Replacement

    Battery replacement CAUTION: RISK OF EXPLOSION IF BATTERIES REPLACED INCORRECT TYPE. DISPOSE OF THE BATTERIES IN ACCORDANCE WITH INSTRUCTIONS. When removing cover for battery CAUTION: change - Electrostatic Discharge (ESD) can harm electronic components inside 1. To remove the batteries, open the casing of the interface.
  • Page 6 Fault finding • If the Electricity Meter Interface does not send correct meter data, validate that the probe is mounted correctly to the meter. • In case of a weak or a bad signal, change the location of the connected gateway or strengthen the signal with a smart plug.

  • Page 7: Other Certifications

    Furthermore, frient A/S reserves the right to alter the hardware, software, and/or specifications detailed herein at any time without notice, and frient A/S does not make any commitment to update. All the information contained herein. All the trademarks listed herein are owned by their respective owners.
