Chapter 3. Configuring Directory Databases
nsCheckLocalACI: on
Setting this attribute to on in the cn=default instance config,cn=chaining
database,cn=plugins,cn=config entry means that all new database link instances will
have the nsCheckLocalACI attribute set to on in their cn=database_link, cn=chaining
database,cn=plugins,cn=config entry.
5. Create client ACIs on all intermediate database links and the final destination database.
Because local ACI evaluation is enabled, the appropriate client application ACIs must be created
on all intermediate database links, as well as the final destination database. To do this on the
intermediate database links, first create a database that contains a suffix that represents a root
suffix of the final destination suffix.
For example, if a client request made to the c=africa,ou=people,dc=example,dc=com
suffix is chained to a remote server, all intermediate database links need to contain a database
associated with the dc=example,dc=com suffix.
Add any client ACIs to this superior suffix entry. For example:
aci: (targetattr = "*")(version 3.0; acl "Client authentication for database link users";
allow (all) userdn = "ldap:///uid=* ,cn=config";)
This ACI allows client applications that have a uid in the cn=config entry of Server 1 to perform
any type of operation on the data below the ou=people,dc=example,dc=com suffix on server
three.
3.3.7.5. Detecting Loops
An LDAP control included with Directory Server prevents loops. When first attempting to chain, the
server sets this control to be the maximum number of hops, or chaining connections, allowed. Each
subsequent server decrements the count. If a server receives a count of 0, it determines that a loop
has been detected and notifies the client application.
The number of hops allowed is defined using the nsHopLimit attribute. If not specified, the default
value is 10.
To use the control, add the following OID to the nsTransmittedControl attribute in the
cn=config,cn=chaining database,cn=plugins,cn=config entry:
nsTransmittedControl: 1.3.6.1.4.1.1466.29539.12
If the control is not present in the configuration file of each database link, loop detection will not be
implemented.

3.3.7.6. Summary of Cascading Chaining Configuration Attributes

The following table describes the attributes used to configure intermediate database links in a
cascading chain:
