LK-S450
Quick Start Guide
For more detailed information about the product and its operation, visit the CASIO website.
Available Information: User's Guide, Music Scores, etc.
https://support.casio.com/global/en/emi/manual/LK-S450/
Preparation
Preparing a Power Supply
■ Using the AC Adaptor
1
Connect the AC adaptor as shown in the
illustration on the right.
● Make sure that you use only the AC adaptor specified
for this Digital Keyboard.
■ Using Batteries
Bottom of console
1
2
Load six AA-size batteries.
Tabs
3
4
Specify the battery type.
See "Configuring Function Settings" on the reverse
side of this sheet.
Computer, smartphone, etc. (commercially available)
• Connect using a USB cable that is no more than two meters long.
CASIO-specified device
(sold separately) or
Open
USB flash drive
(commercially available)
Close
Back
After reading this document, keep it in a safe place along with the warranty certificate.
Be sure to read the "Safety Precautions" in the separate "READ THIS!" sheet, and use
the product correctly.
Included Accessories
● Music Stand
● Strap Lock (enclosed with music stand)
● Leaflets
Items included as accessories are subject to change
without notice.
Headphones (sold separately)
Portable audio player, etc.
AC adaptor
(commercially available)
● READ THIS! Sheet
● Other (Warranty, etc.)
Dynamic microphone
(commercially available)
Pedal
(sold separately)
To install the music stand
Insert the stand into the holes
on the back of the console.
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK-S450 and is the answer not in the manual?

Questions and answers

Related Manuals for Casio LK-S450

Summary of Contents for Casio LK-S450

  • Page 1 ● Music Stand Quick Start Guide ● Strap Lock (enclosed with music stand) For more detailed information about the product and its operation, visit the CASIO website. ● Leaflets ● READ THIS! Sheet Available Information: User’s Guide, Music Scores, etc.
  • Page 2 Playing with a Different Sound To change the keyboard’s high- To play with Touch Response To play with sustain range and low-range tones LIGHT NORMAL HEAVY To select a tone OFF: No Touch Response. Select a tone for the keyboard’s low LIGHT: Louder notes with lighter touch than range.
  • Page 3 Basic Operation P(Power) button HOME button SURROUND button Dial VOLUME knob Press to turn on power. Long- Press to return to the Home Press for a more expanded Rotate to change a displayed Rotate to adjust overall volume. press to turn off power. screen.
  • Page 4 Playing a Song for Enjoyment or Play-along To play the song To sound a count To practice a particular part RIGHT OFF COUNT LEFT OFF PRECOUNT BOTH OFF To select a song COUNT: A count sounds throughout song RIGHT OFF: Right-hand part muted for playback.
  • Page 5 Using a Lesson to Master Song Play To play using the Easy Mode To loop a section between points A and B EASY To select the song you want to learn To use the Challenge Mode to check your results CHALLENGE To select a lesson part RIGHT...

  • Page 6: Recording Your Performance

    To initialize a setting Select a function. Function name Select “All Initialize”. Display SETTING. For information about functions, refer to the User’s Guide available on the CASIO Website. Play what you want to record. Change the setting value. This starts recording. Stop recording.
  • Page 7 Selecting a Rhythm for Ensemble Play To change the pattern To insert an intro To sound the accompaniment pattern with chords Start the rhythm. I>V1 To select a rhythm Start the rhythm. Start the rhythm. Use the chord input keyboard to play Category chords.

  • Page 8: Product Specifications

    Product Specifications Model: LK-S450 Keyboard: 61 keys Touch Response: 3 levels, Off Lighted Keys: Maximum number of keys simultaneously lit: 10, can be turned off Maximum Polyphony: 48 notes Tone Functions: 600 preset tones Effects: Reverb (20 types, Off); Chorus (10 types, Tone); DSP Metronome: Bell sound off, 1 to 16 beats;...

  • Page 9: Declaration Of Conformity

    (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. ● The contents of this manual are subject to change without notice.
