Sony DREAM MACHINE ICF-CD855 Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Sony Manuals
  4. Clock Radio
  5. DREAM MACHINE ICF-CD855
  6. Operating instructions manual
Sony DREAM MACHINE ICF-CD855 Operating Instructions Manual

Sony DREAM MACHINE ICF-CD855 Operating Instructions Manual

Hide thumbs Also See for DREAM MACHINE ICF-CD855:

Advertisement

Quick Links

Download this manual
FM/AM CD
Clock Radio
FM/MW/LW CD
Clock Radio
Operating Instructions
Mode d'emploi
Bedienungsanleitung (Rückseite)
Betjeningsvejledning (på bagsiden)
Sony Corporation Printed in Denmark
Dream Machine is a trademark of Sony Corporation.
Dream Machine est une marque commerciale de Sony Corporation.
Dream Machine ist ein Warenzeichen der Sony Corporation.
Dream Machine er et varemærke ejet af Sony Corporation.
RADIO
FM1FM2
FM MONO
LW
SLEEP
MWPM
ALARM A
AM
PM
Display window* (12-hour system)
Afficheur* (système par 12 heures)
BRIGHTNESS
CD
RADIO
BUZZER
ALARM A
The PRESET TUNING 3 button
has a tactile dot.
PRESET TUNING
La touche PRESET TUNING 3
1
comporte un point tactile.
i (headphones)
2
jack
Prise i
(casque)
3
4
5
PUSH CLOSE
SNOOZE•SLEEP OFF
SELECT
PRESET
PUSH OPEN
A
VOL
The VOL + button has a tactile dot.
La touche VOL + comporte un point
tactile.
http://www.sony-europe.com
VOL
AM
HI
MID
LOW
ICF-CD855
ICF-CD855L
WAKE UP
NAP
TRACK
MHz
AM
kHz
PM
* The display differs depending on your country.
* L'affichage diffère selon votre pays.
CLOCK
FM wire antenna
Antenne fil FM
AC power cord
Cordon
d'alimentation
secteur
MODE
The CD u button has a tactile dot.
La touche CD u comporte un point
tactile.
CD
SHUFFLE
REP 1 ALL
ALARM B
CD
RADIO
BUZZER
ALARM B
NAP
SLEEP
CD
RADIO ON
BAND
OFF
ALARM
RESET
TUNE
TIME SET

Advertisement

loading
Need help?

Need help?

Do you have a question about the DREAM MACHINE ICF-CD855 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony DREAM MACHINE ICF-CD855

Summary of Contents for Sony DREAM MACHINE ICF-CD855

  • Page 1 Sony Corporation Printed in Denmark Dream Machine is a trademark of Sony Corporation. Dream Machine est une marque commerciale de Sony Corporation. Dream Machine ist ein Warenzeichen der Sony Corporation. Dream Machine er et varemærke ejet af Sony Corporation.

  • Page 2: Setting The Brightness Of The Backlight

    TRACK SHUFFLE REP 1 ALL ALARM B English stem) * The display differs depending on your country. eures) * L’affichage diffère selon votre pays. WARNING To prevent fire or shock hazard, do not CLOCK expose the unit to rain or moisture. To avoid electrical shock, do not open the cabinet.
  • Page 3 Changing AM Channel Step The AM channel step differs depending on area. The channel step of this unit is factory-set to 9 kHz or 10 kHz to change the setting as shown below to be able to listen to the radio. Area Channel step North and South America...
  • Page 4 About CD-Rs/CD-RWs This unit is compatible with CD-Rs/CD-RWs but playback capability may vary depending on the quality of the disc, the recording device and application software. Music discs encoded with copyright protection technolo- gies This product is designed to play back discs that conform to the Compact Disc (CD) standard.

  • Page 5: Operating The Radio

    Operating the Radio —Manual Tuning Press RADIO ON•BAND to turn on the radio. “RADIO” appears on the display. Press RADIO ON•BAND repeatedly to select the desired band. Each press changes the band as follows: ICF-CD855 ICF-CD855L When using FM1 or FM2 preset mode, you may listen to the radio on either mode (See “Presetting Your Favorite Station”).

  • Page 6: Tuning In To A Preset Station

    Tuning into a Preset Station Press RADIO ON•BAND to turn on the radio. Press RADIO ON•BAND to select the band. Press the desired PRESET TUNING button. Adjust the volume using VOL + or –. After about 10 seconds, the display will return to the previous display but the PRESET TUNING button number will remain.
  • Page 7 A Setting the CD Alarm For the CD alarm, the track you specified as the wake- up track is played first. (If the CD play mode is set to “SHUFFLE” or “SHUFFLE REP,” however, all the tracks are played in random order.) Perform steps 1 to 5 in “To set the Alarm Time.”...

  • Page 8: Alarm Off

    ALARM ON— Press ALARM A or B to activate the alarm setting. If the setting indicator does not light, the alarm setting is not activated. You can only check the alarm setting when it is activated. If you set the CD alarm and there is no disc in the CD player, the buzzer alarm will sound in its place at the time set.

  • Page 9: Setting The Sleep Timer

    Should any problem occur with the unit, make the following checks to determine whether or not servicing is required. If the problem persists, consult the nearest Sony dealer. The clock does not show the correct time. • Has an electrical power outage lasting more than...

  • Page 10: Specifications

    Specifications CD player section System: Compact disc digital audio system Laser diode properties: Material: GaAlAs Wavelength: 780 nm Emission duration: Continuous Laser output: Less than 44.6 µW (This output is the value measured at a distance of about 200 mm from the objective lens surface on the optical pick-up block with 7 mm aperture.) Frequency response: 20-20 000 Hz –1.5...

This manual is also suitable for:

Dream machine icf-cd855lDream machine cf-cd855l
