INTERTECHNO ITLR-3500 Operating Instructions

Operating instructions for
Radio - controlled adapter plug
The radio - controlled adapter plugs ITLR - 3500 a nd ITLR - 3500T are suited
for the wireless switching of lamps and elec tr ical appliances with
a switching power o f up to 3500 w att s .
The ITLR - 300 is used to dim lights
(light bulbs and high - voltage halogen lamps ) with up to
max. 300 w att s (ohmic load ).
To start and stop the d imming process , press the On button again .
The brightness that was set last remains stored w hen you switch it on again .
With its automatic switch - off range from 7 sec. to 8 h, t he ITLR - 3500T
is suited for a variety of applications . Fig . 3
For example: kitchen grinders, heat pumps, lamps in entrance areas etc ...
All transmitters of intertechno are suitable for switching .
Please comply with the respective operating instructions for your
transmitter as well .
Radio - controlled hand - held transmitter ITLS - 16
For all types of self - learning radio - controlled receivers of intertechno .
For switching on and of f, dimming, controlling shutters and g arag e doors etc.
16 random codes of 67 million possible ones are available and ensure a high
degree of security . On = left side, off = right side of the button .
Batter y change Fig . 2
3 V CR2032 sufficient for approx. 20, 000 switching operations
(useful life approx . 3 years )
Have the transmitter you want to use ready .
Plug the radio - controlled adapter plug in the outlet .
1.) Briefly press the learn button (L) on the receiver (1 sec.). Fig . 1
The red LED flashes .
2. ) Press the desired "ON" button on the transmitter .
The radio - controlled receiver switches twice to indicate that the new c ode
has been accepted .
A total of up to 6 different codes can be programmed .
This also makes it very easy to realise a planned group switching.
Several radio - controlled receiv ers can be swit ched on and off
individually as well as simultaneously .
The codes remain stored even after a power fail ure or removal
If you want to delete one c ode on the receiver later on , proceed
as described in 1.) a nd 2.) .
Press the "OFF" b utton instead of the "ON" button now, however .
In order to delete all codes that have already been saved (reset) , press the
learn button "L" until the LED flashes (approx. 6 sec.) .
Then briefly press the learn button "L" once again . This deletes all c ode s.
No transmitters are required for this .
For the declaration of c onform ity, go to www.intertechno.at/CE
Coding
FINISHED !
of the receiver.
Deleting the c o ding
ITLR - 3500, ITLR - 3500T
ITLR - 300, ITLS - 16
