- Page 1 U n d e r c o u n t e r W i n e C a b i n e t I n s t r u c t i o n M a n u a l WI6 15 0 & WI6 1 55 Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk...
-
Page 2: Table Of Contents
Installing a slot-on Plinth Grille Wine Bottle Stacking Installation Dimensions Installing The Top Fixing Bracket Using The Foot Sliders Care and Maintenance Troubleshooting Recommended Temperatures Caple Contact Details Instruction manual Wi6150 & Wi6155 Please keep this instruction manual for future reference... -
Page 3: Introduction
Thank you for choosing this Caple Wine Cabinet. To ensure that you get the best results from your new wine cabinet, we strongly suggest that you read this instruction manual thoroughly before use. If treated with care, your Caple product should give you years of trouble-free use. -
Page 4: Safety Instructions
- If the supply cord is damaged, it must be replaced by a Caple service agent or a similarly qualified person in order to avoid a hazard. - This product is not designed for commercial use, it is a household appliance only. - Page 5 I M P O R T A N T Caple cannot be held liable for any non compliance with these instructions. E L E C T R I C A L S H O C K H A Z A R D - Read all instructions before using the wine cabinet.
- Page 6 - This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 7: Environmental Protection
Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase. If you fail to show your warranty card you will incur all repair charges. -
Page 8: Installation
I N S T A L L A T I O N B E F O R E U S I N G YO U R W I N E C A B I N E T › Remove the exterior and interior packing. I M P O R TA N T: Before connecting the wine cabinet to the power source, let it stand upright for at least 12 hours. - Page 9 (ground) pin from the plug. Any questions concerning power and/or grounding should be directed toward a certified electrician or Caple service. WA R N I N G : Incorrect earthing can result in the risk of electric shock.
-
Page 10: Operating Your Wine Cabinet
O P E R A T I N G Y O U R W I N E C A B I N E T Please use the cabinet within ambient temperatures between 16-32ºC, if the ambient temperature is higher or lower than this, it will cause the temperature to fluctuate in the cabinet, possibly preventing it from reaching 5-18ºC. -
Page 11: Control Panel And Operation
C O N T R O L PA N E L CONTROL PANEL AND OPERATION CONTROL PANEL AND OPERATION ONTROL PANEL AND OPERATION TOUCH CONTROL KEYS AND SYMBOLS CONTROL PANEL AND OPERATION TO U C H C O N T R O L K E YS To switch the appliance on/off . - Page 12 N OT E : The light must be replaced by qualified personnel. For instructions on how to replace the light, please contact Caple Service or visit our website. This button is used to toggle between the different operational functions. When selected,...
-
Page 13: Using The Shelves
Glass shelves are available if you wish to store cans or smaller bottles such as beer in your our wine cabinet. These can be purchased directly from www.caple.co.uk wine cabinet. These can be purchased directly from www.caple.co.uk ... -
Page 14: Installing The Charcoal Filter
Lower zone = 10-18ºC The charcoal filter should be replaced every 3-6 months depending on the unit’s exposure level to odour. Visit www.caple.co.uk to purchase the replacement charcoal filters. ow to replace the charcoal filter How to replace the charcoal filter •... -
Page 15: How To Change The Door Opening
H O W T O C H A N G E T H E D O O R O P E N I N G This appliance has reversible doors but is delivered with a right hinged door. The left hand hinge kit comes with the unit (in the box), should you wish to reverse the hinge on your unit follow the directions below: Fig.B... - Page 16 1. Remove the door pin(1) from both the upper and lower hinge, as shown in Fig A. 2. Take the door(2) off and keep it in a safe place, where it wont get damaged. 3. As shown in Fig C, take off the lower hinge cover(3) and upper hinge cover(8). 4.
-
Page 17: Installing The Handle
Remove the door gasket on the drilled holes side to install the handle (see below drawing). Fix the handle to the screws and push the gasket back into place. Visit our caple website to view a ‘How to video’ at www.caple.co.uk Scan the QR code below to access the ‘How to video’... -
Page 18: Installing The Full Height Plinth Grille
I N S T A L L I N G T H E F U L L H E I G H T P L I N T H G R I L L E Take out the full height plinth grille and the brackets from the accessories box. Fix the brackets to the cabinet with screws provided and fix both sides of the grille to the brackets with the 2 supplied screws as shown in below diagram. -
Page 19: Installing A Slot-On Plinth Grille
I N S T A L L I N G A S L O T- O N P L I N T H G R I L L E ’ This model is recessed to fit a kitchen plinth. A H55mm vent slot is required in the plinth to ensure air can ventilate correctly. -
Page 20: Wine Bottle Stacking
W I N E B O T T L E S T A C K I N G Stores max. 44 Bordeaux style bottles 750ml. Burgundy bottles Bordeaux bottles 12 Bordeaux 12 Bordeaux 7 Bordeaux 7 Bordeaux 7 Bordeaux 7 Bordeaux 7 Bordeaux 7 Bordeaux 11 Bordeaux... -
Page 21: Installation Dimensions
I O N S I N S T A L L A T I O N D I M E N S I O N S Instruction manual Wi6150 & Wi6155 Please keep this instruction manual for future reference... -
Page 22: Installing The Top Fixing Bracket
F I X I N G T H E T O P F I X I N G B R A C K E T After installing the wine cabinet, please open the door, adjust the fixing bracket (a) and fix this in position with three screws (c) using a screwdriver (d) into the work surface (b). -
Page 23: Using The Foot Sliders
U S I N G T H E F O O T S L I D E R S If you want to adjust the height over 820mm, please install the product using the foot sliders provided. These are provided to help prevent the feet catching on the floor when sliding the appliance into the aperture. -
Page 24: Care And Maintenance
C A R E A N D M A I N T E N A N C E C L E A N I N G YO U R W I N E C A B I N E T ›... - Page 25 M O V I N G YO U R W I N E C A B I N E T › Remove all items. › Securely tape down all loose items (shelves) inside your appliance. › Turn the adjustable leg up to the base to avoid damage. ›...
-
Page 26: Troubleshooting
The door was reversed and not properly installed. The gasket is dirty. The shelves are out of position. If the above table has not solved the problem please contact Caple Service by phone on 0117 938 7420 or by email service@caple.co.uk 26 Instruction manual Wi6150 & Wi6155... - Page 27 For more info and to order spares, please contact Caple service or visit our website www.caple.co.uk. Instruction manual Wi6150 & Wi6155...
-
Page 28: Recommended Temperatures
R E C O M M E N D E D T E M P E R A T U R E S R E C O M M E N D E D S TO R A G E T E M P E R AT U R E S : R E C O M M E N D E D B E V E R A G E T E M P E R AT U R E... - Page 29 NOTES: Instruction manual Wi6150 & Wi6155 Please keep this instruction manual for future reference...
- Page 30 NOTES: 30 Instruction manual Wi6150 & Wi6155 Please keep this instruction manual for future reference...
- Page 31 NOTES: Instruction manual Wi6150 & Wi6155 Please keep this instruction manual for future reference...
-
Page 32: Caple Contact Details
Caple Service Fourth Way Avonmouth T: 0117 938 1900 Bristol E: service@caple.co.uk BS11 8DW www.caple.co.uk...
