Legs & hardware are stored under the seat cushion, please take out the legs and hardware for assembly
Note: Do not use power tools for assembly. Power tools increase the risk of over tightening which lead to spliting or
cracking the wood.
PART
DRAWING
A
B
C
D
STEP 1
MADE IN VIETNAM
ASSEMBLING INSTRUCTIONS
QTY
DESCRIPTION
Seat
1 PC
Front Wood Leg
2 PCS
3-1/2"x3-1/2"x8-3/4"
Rear Wood Leg
2 PCS
3-1/2"x3-1/2"x8-3/4"
Seat Cushion
1 PC
ITEM NO: 1004GRY-1/ 1004BEG-1/
1004BUE-1/ 1004DGY-1/ 1004GRN-1
Accent Chair
PART
DRAWING
1
2
3
4
x12
DESCRIPTION
Bolt
Ø5/16"×1''
Spring Washer
Ø5/16"
Flat Washer
Ø5/16"×19
Allen Key M4
B
C
x12
x12
QTY
12 PCS
12 PCS
12 PCS
1 PC
x1
Page: 1/2
