Legs and hardware are stored in the bottom of the seat, please take them out for assembly.
Note: Do not use power tools for assembly. Power tools increase the risk of over tightening which lead to spliting or
cracking the wood.
PART
DRAWING
A
B
C
STEP 1:
MADE IN VIETNAM
ASSEMBLING INSTRUCTIONS
ITEM NO: 1009GRY-1/ 1009BEG-1/ 1009CRC-1
QTY
DESCRIPTION
Seat
1 PC
Front Wooden Leg
2 PCS
16-1/2"x1-3/4"x1-3/4"
Rear Wooden Leg
2 PCS
16"x2"x1-1/2"
Accent Chair
PART
DRAWING
1
2
3
4
C
x8
x8
DESCRIPTION
Bolt
Ø5/16"×2-3/16"
Spring Washer
Ø5/16"
Flat Washer
Ø5/16"×19"
Allen Key M4
B
x8
x1
QTY
8 PCS
8 PCS
8 PCS
1 PC
Page: 1/3
Advertisement
Related Manuals for Homelegance 1009GRY-1
Summary of Contents for Homelegance 1009GRY-1
- Page 1 ASSEMBLING INSTRUCTIONS ITEM NO: 1009GRY-1/ 1009BEG-1/ 1009CRC-1 Accent Chair Legs and hardware are stored in the bottom of the seat, please take them out for assembly. Note: Do not use power tools for assembly. Power tools increase the risk of over tightening which lead to spliting or cracking the wood.
- Page 2 ASSEMBLING INSTRUCTIONS ITEM NO: 1009GRY-1/ 1009BEG-1/ 1009CRC-1 Accent Chair STEP 2: MADE IN VIETNAM Page: 2/3...
- Page 3 ASSEMBLING INSTRUCTIONS ITEM NO: 1009GRY-1/ 1009BEG-1/ 1009CRC-1 Accent Chair STEP 2: Care Instruction for Textured Furniture: In order to maintain the original appearance of your textured furniture, please follow below simple care procedures: · Avoid exposing furniture directly to sunlight or heating and air conditioning outlets.
