THE HEAT IS ON
Models E32R, E24R, E18R, E15R
OWNER'S MANUAL
READ AND SAVE THESE INSTRUCTIONS
Read all instructions carefully before setting up and operating this unit.
This manual is designed to provide you with the information needed to set up,
operate, and maintain your radiant heater.
Failure to follow these instructions may damage and / or impair its operation.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E32R and is the answer not in the manual?

Questions and answers

Related Manuals for RADtec E32R

Summary of Contents for RADtec E32R

  • Page 1 THE HEAT IS ON Models E32R, E24R, E18R, E15R OWNER’S MANUAL READ AND SAVE THESE INSTRUCTIONS Read all instructions carefully before setting up and operating this unit. This manual is designed to provide you with the information needed to set up, operate, and maintain your radiant heater.
  • Page 2 1. INTRODUCTION Thank you for your trust and support in choosing the RADtec Radiant Heater. Please read the instructions carefully before operating this product. You have purchased one of the most advanced heating systems for indoor and covered outdoor areas. The infrared radiant heater is characterized by a focused distribution of heat, which transports heat evenly to where it is needed.

  • Page 3: Product Overview

    Subtle, Slimline, No-Glow design The stylish, slimline black face of the Radtec radiant heater does not emit light or glow when in use, blending elegantly into your décor. Ceiling and wall mounting options ensure that your valuable floor, lounge and table space is not wasted.

  • Page 4: Performance Features

    4. PERFORMANCE FEATURES Coverage Area Table Model No. Indoors Outdoor Enclosed Outdoor Exposed eRAD10R 30ft ~ 2.8m 25ft ~ 2.3m 20ft ~ 1.9m eRAD15R 50ft ~ 4.6m 40ft ~ 3.7m 30ft ~ 2.8m eRAD18R 50ft ~ 4.6m 40ft ~ 3.7m 30ft ~ 2.8m eRAD24R...

  • Page 5: Installation Requirements

    Before starting the installation, you must ensure that the operating voltage corresponds to that stated on the Radtec specifications label located on the side-panel of the heater. Supply Voltage fluctuation range should be within ±10%. If condition not met, it must be resolved before installation b.

  • Page 6: Installation Instructions

    7. INSTALLATION INSTRUCTIONS...
  • Page 7 Model No. Dimension A (in) Dimension B (in) Dimension C (in) eRAD10R 23.6 3.74 eRAD15R 39.37 27.6 3.74 eRAD18R 39.37 27.6 3.74 eRAD24R 47.2 3.74 eRAD32R 78.7 66.9 3.74 Step 1: Remove packing materials from both ends of heater. Step 2: Installation of adjusting bracket and sliding bracket.
  • Page 8 Step 3: Installation of sliding bracket and heater, as arrow points. Step 4: Fix adjusting bracket into wall with expansion screws. Step 5: Installation of two adjusting brackets. Make sure to lock brackets tightly by using the butterfly hand screw.

  • Page 9: Installation Diagram

    8. INSTALLATION DIAGRAM ***THIS MODEL HEATER HAS A RECOMMENDED MOUNTING HEIGHT OF 7-9 FEET***...

  • Page 10: Remote Control Instructions

    9. REMOTE CONTROL INSTRUCTIONS Temperature controller parts LED indicating lights: As shown above, there are four indicating lights on the “temperature controller.” These four lights are used to indicate the machine’s operating level. No. 5 is the far-infrared receiver. *Attention: The No. 1 indicating light functions in two colors, red and green* 1.

  • Page 11: Inspection Items After Installation

    10. INSPECTION ITEMS AFTER INSTALLATION Items to be checked Improper installation Is the unit stable? The equipment may fall off or shake Is heat insulation adequate? May damage objects close to unit Is power voltage the same as voltage shown on product nameplate? Equipment failure Is the wired connection correct? Equipment failure...

  • Page 12: Packing List

    8. For cleaning, turn the unit off and wait for a minimum of 1 hour. Then use a damp cloth to wipe exterior of the unit. Never use any cleaning products/chemicals on the heater itself. DO NOT FLUSH OR SPRAY UNIT WITH WATER. 9.

  • Page 13: Warranty And Return Policy

    Except as provided below, RADtec is not liable for any loss, cost, expense, inconvenience or damage that may result from use or inability to use the heater. Under no circumstances shall RADtec be liable for any loss, cost, expense, inconvenience or damage exceeding the purchase price of the heater.
  • Page 14 6. You must have filled out and filed your Warranty Card with RADtec to activate this warranty. Return of Non-Defective Products A non-defective product may be returned to RADtec within thirty (30) days of the invoice date for a refund of the original purchase price with the following amendments/fees: 1.
  • Page 15 It will also be null and void if there are indications of misuse and/or abuse. RADtec has the option of voiding the warranty if anyone other than an RADtec technician attempts to service the product. RADtec will not warrant any problems arising from an act of God (lightning, flooding, tornado, etc.), electrical spikes or surges, or problems arising...
  • Page 16 Warranty Form Cut along dotted, fill out warranty card and mail to RADtec. -------------------------------------------------------------------------------------------------------------------...
