USER, MAINTENANCE AND INSTALLATION MANUAL
Manufacturer: Siem Nova S.r.l. Legal and operational offices 20087 ROZZANO (Milano) MADE IN ITALY
Product: SURGICAL ASPIRATOR MOD: 6110-A5 GASTRO EVER and 6110-A6 GASTRO JUNIOR
ASSISTANCE
Read the instruction manual before using the device.
This manual must be kept with the device for later reference.
SIGNS AND SYMBOLS
This symbol indicates the
compliance with the
essential requirements of
the Directive 93/42/ EEC
of 14 June 1993
concerning medical
devices. Reference IMQ
Spa - Milan
This symbol indicates the
date of production (four
digits for the year and two
digits for the month).
This symbol indicates the
manufacturer.
This symbol indicates that
interferences may occur in
the vicinity of equipment
marked with this symbol
This symbol indicates the
humidity limitation for
operation, transport and
storage
This symbol indicates to
keep the device away from
sunlight
This symbol indicates do
not dispose the device
together with unsorted
municipal waste (for EU
only).
PRESSURE MEASURE UNIT CONVERSION TABLE
Legenda: bar, KPa, cm Hg, cm H2O are all measure unit of pressure (vacuum)
bar
1 bar
1
1 KPa
0.01
1 cm Hg
0.133
1 cm H2O
0.098
1
APPLICATION
The suction equipment 6110-A5 GASTRO EVER and 6110-A6 GASTRO JUNIOR are approved exclusively for the use as described
in this user and maintenance manual. Siem Nova can only warranty the safe functioning of the equipment when the 6110-A5
GASTRO EVER and 6110-A6 GASTRO JUNIOR are used with the Siem Nova accessories.
Please read and observe these warning and safety instructions before use the device.
Please note that these instructions for use are a general guide for the use of the product.
Medical matters must be addressed by a physician.
Updated: 2021-06-30
This symbol
indicates an
insulation class I
device.
This Symbol
indicates a type B
applied part.
This symbol
indicates alternate
current
This symbol
indicates a single
use device. Do not
reuse the device.
This symbol
indicates the
atmospheric
pressure limitation
for operation,
transport and
storage.
This symbol
indicates to keep the
device dry.
DM SERIAL NUMBER
KPa
cm Hg
100
75.006
1
0.75006
1.333
1
0.00098
0.07355
reproduction forbidden
This symbol indicates
to follow instructions
for use.
This symbol indicates
a CAUTION or
WARNING associated
with the device.
This symbol indicates
the foot switch.
This symbol indicates
REF
the manufacturer's
reference number
This symbol indicates
the temperature
limitation for
operation, transport
and storage.
This symbol indicates
the protection against
harmful effects due to
IP33
ingress of solid foreign
objects and against
harmful effects due to
the ingress of water.
This symbol indicates
do not immerse in
water or other liquid
cm H2O
1019.72
10.1972
13.595
1
Pag: 1 di 9
