Contents Safety instructions Important safety instructions Before using your dishwasher Installation Product dimensions Cabinet dimensions Specifications Scan the QR code* to view our helpful installation videos. * Requires reader to be installed on your smartphone. English DW9900R_DD68-00208A-05_EN.indd 2 2023-12-15 4:07:07...
It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating the dishwasher. Samsung is not liable for damages resulting from improper use.
Safety instructions California Proposition 65 Warning WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Read all instructions before using the appliance. Install and store the dishwasher inside, away from exposure to weather. CAUTION • Do not install the dishwasher near electrical components. Keep the dishwasher away from open flames.
Make sure to use a new water supply line. Old lines are susceptible to breakage because they become hardened and may cause property damage due to a water leakage. The dishwasher must be connected to a hot water supply with a temperature between 120 °F (49 °C) ~ 149 °F (65 °C).
Installation Be sure that you or your installer follow these instructions closely so that the new dishwasher works properly and that you are not at risk of injury when washing dishes. STEP 1 Check the parts and tools Before starting on the installation, prepare all the necessary tools and parts required to install the dishwasher.
Page 7
Not provided Power cable Twist on wire Strain relief Electrical tape & connector Standard duct tape Hot water supply 90° Fitting ( ") Tube fittings Hose clamp line Air gap Rubber connector NOTE For the hot water supply line – We strongly recommend using "...
Page 9
NOTE New installation If the dishwasher is a new installation, most of the installation work must be done before the dishwasher is moved into place. Replacement If the dishwasher is replacing an old dishwasher, you must check the exising dishwasher connections for compatibility with the new dishwasher.
Page 10
Installation If this is a new installation, follow these steps: 1. Using a 2 inch hole saw, cut a hole into the side of the cabinet that holds the sink as shown in Figure 1-1 below. 2. If the base inside the sink cabinet is raised above the kitchen floor and is higher than the connections on the dishwasher, make a hole in the base inside the cabinet and in the cabinet side as shown in Figure 1-2.
Product dimensions Front view Rear view Junction box " (605 mm) Side view " (60 mm) " (520 mm) 25" (636 mm) You must arrange the water supply line, power cable and drain hose in the space behind the dishwasher. English 11 DW9900R_DD68-00208A-05_EN.indd 11 2023-12-15...
Installation Cabinet dimensions NOTE This dishwasher is designed to be enclosed on the top and on both sides by a standard 24" (610 mm) minimum residential kitchen cabinet unit. The installation cabinet must be clean and free of any obstructions. 24"...
STEP 3 Check water supply requirements and cautions • The hot water supply line pressure must be between 20 ~ 120 psi (140 ~ 830 kPa). • Adjust the water heater to deliver water between 120 °F (49 °C) ~ 149 °F (65 °C). - The dishwasher must be connected to a hot water supply between 120 °F (49 °C) ~ 149 °F (65 °C).
Page 14
Installation STEP 4 Check the electrical requirements and cautions The electrical requirements for the dishwasher are as follows: • In the United States, install in accordance with the National Electric Code/State and Municipal codes and/or local codes. • In Canada, install in accordance with the Canadian Electric Code C22.1-latest edition/ Provincial and Municipal codes and/or local codes.
STEP 5 Unpacking and inspecting the dishwasher Unpack the dishwasher in an open area free of obstruction both around the packaging and overhead. We recommend that you retain all of the packing materials until the dishwasher is fully installed and operational to ensure you have removed all the product’s components from the packing materials prior to disposal.
Page 16
Installation Inspecting Mechanical 1. Check the plastic base assembly to ensure that it is intact 2. Check the dishwasher’s feet to ensure they are in place and can be adjusted so you can level and secure the dishwasher. 3. Check all the visible components on the bottom of the dishwasher to ensure they are intact and secure.
STEP 6 Preparing the dishwasher 1. Attach the protective sticker (A). - To prevent damage, put the protective sticker on the bottom of the counter top as shown in the picture. NOTE • Before putting the protective sticker, clean the counter top as shown in the picture. •...
Page 18
Installation 3. Then, insert the " 90 degree fitting into the inlet valve (See Figure 4-B). Tighten until " fitting is tight. Do not over tighten. 4. Detach the Velcro strips that secure the drain hose to the back of the dishwasher. Roll- out the hose.
Page 19
Figure 4 Junction box Strain relief 90° fitting CAUTION Do not overtighten the 90° Fitting. (Below 280 lb·in (31.6 N·m)) Doing so may damage the water inlet valve and cause a water leak. English 19 DW9900R_DD68-00208A-05_EN.indd 19 2023-12-15 4:07:12...
Page 20
Installation STEP 7 Placing the dishwasher and connecting the hot water supply line 1. Adjust the three leveling legs at the bottom of the dishwasher after measuring the height of the cabinet opening from under the countertop to the floor. (See STEP 8, Leveling the Dishwasher.) 2.
Page 21
Figure 5 Side gasket Junction box Side gasket 1 inch Drain hose Hot Water Supply Line Power cable Inlet valve built-in hook Hot Water Supply Line Elbow ( " (9.5 mm)) CAUTION Do not overtighten the 90° Fitting. (Below 280 lb·in (31.6 N·m)) Doing so may damage the water inlet valve and cause a water leak.
Installation STEP 8 Leveling the dishwasher 1. Open the door and place the level against the top of the tub on the inside and check if the the dishwasher is level. If it is not level, rotate the leveling legs at the bottom front of the dishwasher until the dishwasher is level.
Page 23
NOTE • If the leveling legs are rotated to the left (clockwise), they are loosened and the front of the dishwasher is raised. If they are rotated to the right (counter clockwise), they are tightened and the front of the dishwasher is lowered. •...
Installation STEP 9 Securing the dishwasher You must fix the dishwasher to the countertop or cabinet side walls for additional stability and safety. To the countertop If the countertop is made of wood or the material will not be damaged by drilling, follow this.
Page 25
To the sides If the countertop is made of granite, marble, or any other material that can be damaged by drilling, follow this. 1. Put a large towel into the bottom of the dishwasher(covering the filter) to prevent wood shavings or a dropped screw from falling into the sump.
Page 26
Installation STEP 10 Securing 1. Check the parts on the sink to which the drain hose will be connected. 2. There are several ways to insert the drain hose into the drain hose connector of the sink, as shown in the following figures. You must connect the drain hose in accordance with the water pipe installation regulations in your region.
Page 27
3. Check the size of the sink’s drain hose connector. If needed, cut the drain hose so its end fits onto the sink connector (⅝ in. or 1 in. - as shown in Figure 9 below). If the end of the drain hose does not fit onto the drain hose connector of the sink, use an adaptor purchasable at a plumbing/hardware supply store.
Page 28
Installation Figure 9 1 in. (25 mm) (16 mm) (22 mm) If necessary, cut off the dotted line of the drain hose to fit the size. Figure 10 To prevent backflow for models without the air gap, secure the drain hose to the Sink side wall of the kitchen cabinet using cable ties or other fixtures.
STEP 11 Wiring connections 1. Before connecting the power cable to the dishwasher, make sure the circuit breaker is off. 2. Unfasten the screw on the left side of the junction box located at the front bottom right of the dishwasher, and then open the junction box cover. (Figure 11) 3.
Page 30
Installation Figure 12 Black to black White to white Power cable Green to green Junction box (Ground to ground) Strain relief Figure 13 WARNING • Electrical Shock Hazard To avoid electrical shock, do not work on an energized circuit. Doing so could result in serious injury or death.
STEP 12 Completing the installation 1. Open the door and remove all foam, paper packaging, and unnecessary parts. 2. Turn on the circuit breaker you turned off before you began the installation. 3. Open the water supply valve to supply water to the dishwasher. 4.
Page 32
Installation Kick plate Gasket CAUTION Make sure the kick plate does not interfere with the dishwasher's door opening and closing. English DW9900R_DD68-00208A-05_EN.indd 32 2023-12-15 4:07:14...
Specifications Power supply 120 V, 15 A, 60 Hz AC Water pressure 20 ~ 120 psi (140 ~ 830 kPa) Dimensions x 25 x 33 (Width×Depth×Height) (605 x 636 x 860 mm) 120 °F (49 °C) Minimum inlet water temperature NOTE Specifications are subject to change without notice for quality improvement purposes.
Page 37
Lavavajillas Manual de instalación Serie DW80R9950* DW9900R_DD68-00208A-05_MES.indd 1 2023-12-15 4:06:49...
Page 38
Contenidos Instrucciones de seguridad Instrucciones de seguridad importantes Antes de usar la lavavajillas Instalación Dimensiones del producto Dimensiones del gabinete Especificaciones Escanee el código QR* para ver videos útiles de instalación. * Debe tener un lector instalado en su teléfono inteligente.
Es su responsabilidad actuar con sentido común, precaución y cuidado cuando instale, realice el mantenimiento y ponga en funcionamiento la lavavajillas. Samsung no se responsabiliza por los daños ocasionados por un uso inadecuado. Instrucciones de seguridad importantes Significado de los íconos y señales de esta guía de instalación:...
Page 40
Instrucciones de seguridad Advertencia de la Propuesta 65 de California ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov Lea todas las instrucciones antes de usar el electrodoméstico. Instale y guarde la lavavajillas en un lugar interior, no expuesto a los factores climáticos. PRECAUCIÓN •...
Asegúrese de utilizar un conducto nuevo. Los conductos viejos pueden romperse debido a que se endurecen y pueden ocasionar daños materiales por pérdidas de agua. La lavavajillas debe estar conectada al suministro de agua caliente con una temperatura entre 120 ˚F (49 ˚C) y 149 °F (65 ˚C). Este rango de temperatura ofrece un mejor resultado en el lavado y un ciclo más corto.
Instalación Asegúrese de que usted o su instalador siga estas instrucciones minuciosamente para que su nueva lavavajillas funcione adecuadamente y no existan riesgos de sufrir lesiones al lavar la vajilla. PASO 1 Verifique las piezas y las herramientas Antes de comenzar la instalación, prepare todas las herramientas y piezas necesarias requeridas para instalar la lavavajillas.
Page 43
No provisto Cable de alimentación Conector de resorte Alivio de tensión Cinta aislante y cinta americana estándar Conducto de Adaptador de 90° Adaptador del tubo Abrazadera de suministro de agua ") manguera caliente Espacio de aire Conector de goma NOTA Para el conducto de suministro de agua caliente –...
Instalación Herramientas requeridas Taladro eléctrico Lentes de seguridad Guantes Linterna Llave ajustable Alicate pelacable Pinza Alicate de corte Cinta métrica Lápiz Destornillador Destornillador plano Phillips Cortatubos Cúter Fresa para escariar Nivel Torx t20 Llave en forma de L para cabezas hexagonales Español DW9900R_DD68-00208A-05_MES.indd 8...
Page 45
NOTA Instalación nueva Si la instalación del lavavajillas es nueva, la mayor parte del trabajo debe realizarse antes de colocar el lavavajillas en su lugar. Reemplazo Si el lavavajillas reemplazara a un lavavajillas anterior, debe verificar que las conexiones existentes sean compatibles con el nuevo lavavajillas. Reemplace las conexiones existentes si fuera necesario.
Page 46
Instalación Si se trata de una instalación nueva, siga estos pasos: 1. Utilizando una fresa para escariar de 2 pulgadas, realice una perforación en la pared del gabinete que soporta el fregadero como se detalla en la Figura 1-1 a continuación. 2.
Dimensiones del producto Vista frontal Vista posterior Caja de " (605 mm) conexiones Vista lateral " (60 mm) " (520 mm) 25" (636 mm) Acomode el conducto, el cable de alimentación y la manguera de desagüe en el espacio detrás de la lavavajillas.
Instalación Dimensiones del gabinete NOTA Esta lavavajillas está diseñada para 24" (610 mm) mínimo colocarse entre los lados y encima de un gabinete en una cocina residencial estándar. El gabinete para la instalación debe estar limpio y libre de obstrucciones. 24"...
Page 49
PASO 3 Verifique los requisitos para el suministro de agua y precauciones • La presión del conducto de agua caliente debe estar entre 20 y 120 psi (140 y 830 kPa). • Ajuste el calentador de agua para obtener una temperatura de agua entre 120 ˚F (49 ˚C) y 149 ˚F (65 ˚C).
Page 50
Instalación PASO 4 Verifique los requisitos eléctricos y advertencias Los requisitos eléctricos para la lavavajillas son los siguientes: • En los Estados Unidos, instalar de conformidad con el Código Eléctrico Nacional/códigos estatales y municipales y/o códigos locales. • En Canadá, instalar de conformidad con el Código Eléctrico Canadiense C22.1-última edición/ códigos provinciales y municipales y/o códigos locales.
Page 51
PASO 5 Desempacar e inspeccionar el lavavajillas Desempaque la lavavajillas en una zona libre de obstrucciones ya sea alrededor de la caja como en la parte superior. Recomendamos que conserve todos los materiales del empaque hasta que la lavavajillas esté completamente instalada y en funcionamiento para asegurarse de que haya retirado todas las piezas del producto de la caja antes de desecharla.
Page 52
Instalación Inspección Mecánica 1. Verifique el montaje de la base de plástico para asegurarse que esté intacto. 2. Verifique los soportes de la lavavajillas para asegurarse de que estén en su lugar y que puedan ajustarse con el fin de nivelar y asegurar la lavavajillas. 3.
Page 53
PASO 6 Preparación del lavavajillas 1. Una el autoadhesivo protector (A). - Para evitar daños, coloque el autoadhesivo protector en la parte inferior de la encimera como se muestra en la imagen. NOTA • Antes de aplicar el autoadhesivo protector, limpie la encimera como se muestra en la imagen. •...
Page 54
Instalación 3. Luego, inserte el adaptador de " 90 grados en la válvula de entrada (ver la Figura 4-B). Ajuste hasta que el adaptador de " quede ajustado. No lo ajuste demasiado. 4. Separe las tiras que velcro que fijan la manguera de desagüe a la parte trasera de la lavavajillas.
Page 55
Figura 4 Caja de conexiones Alivio de tensión Adaptador de 90° PRECAUCIÓN No ajuste demasiado el adaptador de 90°. (Menos de 280 lb·en (31.6 N·m)) Si lo hiciera, podría dañar la válvula de entrada de agua y ocasionar una pérdida de agua. Español 19 DW9900R_DD68-00208A-05_MES.indd 19 2023-12-15...
Page 56
Instalación PASO 7 Colocación del lavavajillas y conexión del conducto del suministro de agua caliente 1. Regule las tres patas niveladoras en la parte inferior de la lavavajillas después de medir la altura de la abertura del gabinete desde abajo de la encimera hasta el piso. (Ver el PASO 8, Nivelación de la lavavajillas.) 2.
Page 57
Figura 5 Burlete lateral Caja de conexiones Burlete lateral 1 in Manguera de desagüe Conducto de suministro de agua caliente Cable de alimentación Válvula de entrada gancho incorporado Conducto de suministro de agua caliente Codo de ( " (9.5 mm)) PRECAUCIÓN No ajuste demasiado el adaptador de 90°.
Page 58
Instalación PASO 8 Nivelación del lavavajillas 1. Abra la puerta y coloque el nivel contra la parte superior de la cuba desde adentro y verifique si la lavavajillas está nivelada. Si no lo está, gire las patas niveladoras en la parte inferior delantera de la lavavajillas hasta que quede nivelada.
Page 59
NOTA • Si gira las patas niveladoras hacia la izquierda (en el sentido de las agujas del reloj), estas se aflojan y la parte delantera del lavavajillas se levanta. Si las gira hacia la derecha (en el sentido contrario al de las agujas del reloj), se ajustan y la parte delantera del lavavajillas baja.
Page 60
Instalación PASO 9 Asegurar la lavavajillas La lavavajillas debe fijarse a la encimera o a las paredes laterales para mayor estabilidad y seguridad. A la encimera Si la encimera está hecha de madera de un material que no se daña por la perforación, siga las siguientes instrucciones.
Page 61
Hacia los laterales Si la encimera está hecha de granito, mármol o cualquier otro material que no se daña por la perforación, siga las siguientes instrucciones. 1. Coloque una toalla grande en la parte inferior de la lavavajillas (que cubra el filtro) para evitar que caigan restos de madera o un tornillo dentro del sumidero del sumidero.
Page 62
Instalación PASO 10 Ajuste 1. Verifique las piezas del fregadero a las cuales se conectará la manguera de desagüe. 2. Hay muchas maneras de insertar la manguera de desagüe en el conector de la manguera de desagüe del fregadero, como se muestra en las siguientes figuras. Debe conectar la salida del desagüe conforme a las reglamentaciones de instalación de tuberías de agua de su región.
Page 63
3. Verifique el tamaño del conector de la manguera de desagüe del fregadero. Si fuera necesario, corte la manguera de desagüe para que encaje en el conector del fregadero (⅝ pulgada o 1 pulgada, como se muestra en la Figura 9 siguiente). Si el extremo de la manguera de desagüe no calza en el conector de la manguera de desagüe del fregadero, use un adaptador que pueda adquirir en un negocio de suministros de plomería/ ferretería.
Page 64
Instalación Figura 9 1 pulgada pulgada (25 mm) (16 mm) pulgada (22 mm) Si es necesario, corte por la línea punteada de la manguera de desagüe para que se adapte al tamaño. Figura 10 Para evitar el flujo de retorno en los modelos sin espacio de aire, asegure la manguera de Fregadero desagüe en la pared lateral del gabinete de...
Page 65
PASO 11 Conexiones del cableado 1. Antes de conectar el cable de alimentación a la lavavajillas, asegúrese de desactivar el disyuntor. 2. Afloje el tornillo en el lado izquierdo de la caja de conexiones ubicada en la parte inferior derecha de la lavavajillas y, luego, abra la tapa de la caja. (Figura 11) 3.
Page 66
Instalación Figura 12 Negro con negro Blanco con blanco Cable de alimentación Verde con verde Caja de conexiones (Tierra a tierra) Alivio de tensión Figura 13 ADVERTENCIA • Riesgo de descarga eléctrica Para evitar descargas eléctricas, no manipule un circuito energizado. Si lo hiciera, podría sufrir lesiones graves o incluso la muerte.
Page 67
PASO 12 Finalización de la instalación 1. Abra la puerta y quite todas las piezas innecesarias, goma espuma y empaque de papel. 2. Active el disyuntor desactivado antes de comenzar la instalación. 3. Abra la válvula del suministro de agua para suministrar agua a la lavavajillas. 4.
Page 68
Instalación Placa de protección Burlete PRECAUCIÓN Asegúrese de que la placa de protección no interfiera con la apertura y cierre de la puerta de la lavavajillas. Español DW9900R_DD68-00208A-05_MES.indd 32 2023-12-15 4:06:55...
Especificaciones Suministro eléctrico 120 V, 15 A, 60 Hz CA Presión de agua 20 ~ 120 psi (140 ~ 830 kPa) Dimensiones x 25 x 33 pulgadas. (605 x 636 x 860 mm) (Ancho×Profundidad×Altura) Temperatura mínima del agua en la entrada 120 °F (49 °C) NOTA Las especificaciones están sujetas a cambios sin previo aviso a los efectos de las mejoras de...
