Maxxima M20560 Instruction Manual

16,22 light head modules with stt + wl

Advertisement

M20560 - 16 Light Head Modules with STT + WL
M20561 - 22 Light Head Modules with STT + WL
LED Color
Amber, Amber/Red, Amber/White
Voltage
12V-24V
Patterns
30 Warning / 10 Traffic
DOT/SAE
SAE Class 1, CA T13
Qualifications: Installation or service of this equipment should be performed by individuals
with a thorough understanding of automotive electrical and mechanical procedures.
Always consult the vehicle's service manual during installation or maintenance.
Eye Safety: The lighting product emits bright light that can be harmful if viewed up close.
Avoid direct eye exposure to prevent potential permanent damage to your eyesight.
Installation Location: Do not mount the light system in a position that could obstruct or
distract the driver's vision. Ensure it is positioned outside the direct line of sight to facilitate
safe driving.
Component Handling: Lighting system components may become hot. Always disconnect
power and allow cooling before handling.
Antenna Placement: Maintain at least 18 inches of separation between the lighting system
and any radio antenna to avoid operational interference and damage from radio emissions.
Water Exposure: Avoid washing any part of the electrical system while it is powered.
Airbag Safety: Never install equipment or route wiring in the deployment path of an airbag.
info@maxxima.com
CAUTION
Page 1 of 11
866-MAXXIMA (629-9462)
www.maxxima.com
I
NSTRUCTION MANUAL
Mount
Bracket Mount
Material
PC Lens, AL Base Housing
Dimension
59.4"W x 11.8"H x 1.7"D
Warranty
5 Years
125 Cabot Court Hauppauge, NY 11788
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M20560 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxxima M20560

  • Page 1 NSTRUCTION MANUAL V1.0 M20560 - 16 Light Head Modules with STT + WL M20561 - 22 Light Head Modules with STT + WL LED Color Amber, Amber/Red, Amber/White Mount Bracket Mount Voltage 12V-24V Material PC Lens, AL Base Housing Patterns 30 Warning / 10 Traffic...
  • Page 2 After installation, thoroughly test the light system and all vehicle functions to confirm proper operation. Regularly inspect the system to ensure it remains properly secured and functional. MEASUREMENTS 59.4in (1509 mm) M20560 M20561 ▲ ▲ Metal Placeholder Amber Warning Module With Red Stop/Tail/Turn...
  • Page 3: Mounting Kit

    MOUNTING Cable Exit Bolt Insert Slots MOUNTING KIT Each M20560 & M20561 60” Tow Bar comes equipped with a pair of separately packaged mounting kits. Each mounting kit contains: 1x Mounting Bracket 2x M10x90mm Carriage Bolt 2x M10 Lock Washer...
  • Page 4 It connects to the ground and is shielded with a conductive layer, ensuring stable signals and preventing disruptions in the tow bar’s operation. Utilization of this wire is OPTIONAL. Page 4 of 11 info@maxxima.com 866-MAXXIMA (629-9462) www.maxxima.com 125 Cabot Court Hauppauge, NY 11788...
  • Page 5 When this feature is activated, all four worklights will illuminate, and the amber function on these modules will be disabled to prioritize worklight functionality. Page 5 of 11 info@maxxima.com 866-MAXXIMA (629-9462) www.maxxima.com 125 Cabot Court Hauppauge, NY 11788...
  • Page 6 W-Mode 1 W-Mode 2 W-Mode 3 T-Mode 1 T-Mode 2 C-Mode 1 Default Pattern W-Pattern 1 W-Pattern 10 W-Pattern 17 T-Pattern 1 T-Pattern 6 C-Pattern 1 Page 6 of 11 info@maxxima.com 866-MAXXIMA (629-9462) www.maxxima.com 125 Cabot Court Hauppauge, NY 11788...
  • Page 7 Steady ON DISCLAIMER: Patterns may not retain compliance when in Low Compliance Per Module Intensity Dim Mode. ▲ = California Title 13 ● = SAE Class 1 Page 7 of 11 info@maxxima.com 866-MAXXIMA (629-9462) www.maxxima.com 125 Cabot Court Hauppauge, NY 11788...
  • Page 8 Rolling w/Continuous Triple Center-Out Rolling w/Continuous Flash** Triple Flash** Purple (right) wires to +VDC. to +VDC simultaneously (with the mode wire unconnected). 8 or 10 modules, as noted. Page 8 of 11 info@maxxima.com 866-MAXXIMA (629-9462) www.maxxima.com 125 Cabot Court Hauppauge, NY 11788...
  • Page 9: Required Tools

    REQUIRED TOOLS The M20560 Series Tow Bars are designed to be easily opened and maintained. When unscrewing any portion of the tow bar, it is important that the right sized Philips head bit be used to avoid stripping any of the screws. If a powered tool is being used, it should be used with a low torque setting to prevent striping the screws or threaded holes.
  • Page 10: Main Board Replacement

    Install the New Main Board: Place the new board in position and reattach the screws. Then, reconnect the wires according to the original configuration. Test the System: After wiring is complete, power on the system to test and confirm proper functionality. Page 10 of 11 info@maxxima.com 866-MAXXIMA (629-9462) www.maxxima.com 125 Cabot Court Hauppauge, NY 11788...
  • Page 11: Limited Warranty

    Failure to properly ground Maxxima lights, improper wiring of such lights, or any other misuse, abuse, or unauthorized use of Maxxima products will void this limited warranty.
  • Page 12: Replacement Components

    REPLACEMENT COMPONENTS Part Description Part Number Mounting Kit MRP-20501 Top Dome, End Section MRP-20502 Top Dome, Center Section MRP-20503 Control Module Motherboard MRP-20504 Light Head, Front_Rear All Amber* MRP-20505 Light Head, Rear Amber/White Work Light* MRP-20506 Light Head, Rear Amber/Red S/T/T* MRP-20507 Cable Assembly, 25 foot MRP-20508...
