DeVillbiss Air Power Company 102D-3 Owner's Manual

*A circuit breaker is preferred. Use only a fuse or circuit breaker that is the same rating as the branch
circuit the air compressor is operated on. If the air compressor is connected to a circuit protected by
fuses, use quick acting fuses.
This manual contains information that is important for you to know and understand. This information relates to protecting YOUR
SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols to the right.
Please read the manual and pay attention to these sections.
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death of serious injury.
Call our Toll Free Number 1-800-888-2468, Ext 2, then 1, to obtain the location of the nearest Authorized Service Center for
ordering repair parts and for warranty repairs.
When ordering repair parts from your local Authorized Service Center, always give the following information:
Retain Original Sales Receipt as Proof of Purchase for Warranty Repair Work.
MGP-102D-3A 10/12/99
All manuals and user guides at all-guides.com
OWNERS MANUAL FOR
PERMANENTLY LUBRICATED
AIR COMPRESSOR
MODEL NO.
102D-3
(For Home Use Only)
SPECIFICATION CHART
Model No.
Horsepower
SCFM @ 40 psig
SCFM @ 90 psig
Bore
Stroke
Volt/Hertz/Phase
Minimum Branch Circuit Requirement
*Fuse Type
Tank Size
SAFETY GUIDELINES - DEFINITIONS
• Model number of your compressor
• Part number and description of the item you wish to purchase
102D-3
3/4
3.0
2.2
1 3/4"
1 1/4"
120/60/1
15 AMPS
Quick Acting
2 Gallon
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
CAUTION used without the safety alert symbol indicates a
potentially hazardous situation which, if not avoided, may result
in property damage.
