INSTALLATION MANUAL FOR
PHOTOVOLTAIC MODULES
...................................................................................................................................................................................................................
6.3.1.
6.3.2.
6.3.2.1.
.........................................................................................................................................................................................................
................................................................................................................................................................................................
HEADQUARTERS
Aydın Mahallesi Aydın Küme Evleri
No: 78 06980 K.Kazan / ANKARA
...............................................................................................................................................................
......................................................................................................................................................
...................................................................................................................................
...........................................................................................................................................................................
..........................................................................................................................................................
...................................................................................................................................................
..............................................................................................................................
.............................................................................................................................................
.................................................................................................................................................................
................................................................................................................................................................................
.................................................................................................................................................................................
................................................................................................................................................
FACTORY
Büyükosb Mah. Nevzat Ayaz Bulvarı
No: 2 Korgun OSB, Korgun / ÇANKIRI
...................................................................................................................
..............................................................................................
.............................................................................
....................................................................................................................
www.setsolar.com.tr
2
2
2
2-3
3
4
4-5
5
5
6
6
6
6
7
7
7
8
..................
8-9
9
9
/setsolartr
UR-TL-18/08.12.2023/Rev.01/18.04.2025
Advertisement
Table of Contents
Related Manuals for SET SOLAR Volta SETM60
Summary of Contents for SET SOLAR Volta SETM60
-
Page 1: Table Of Contents
INSTALLATION MANUAL FOR PHOTOVOLTAIC MODULES 1. PURPOSE OF INSTALLATION MANUAL ........................2. SAFETY PRECAUTIONS ................................2.1. GENERAL WARNING ..............................2.2. INSTALLATION SAFETY ........................... 2.3. FIRE SAFETY ................................... 3. LIMITATION OF LIABILITY ................................4. GENERAL INFORMATION ..............................5. LABEL ........................................... 5.1. VOLTA AND VOLTA+ SERIES LABELING .................... -
Page 2: Purpose Of Installation Manual
▪ Electricians must take precautions about occupational health and safety. ▪ All Set Solar PV module have junction box, wires and connectors so PV module do not need any extra wires. ▪ Do not use any mirror or glass etc. for focusing sunlight to the PV module ▪... -
Page 3: Fire Safety
Please refer to local laws and regulations before installing ▪ modules and abide by requirements on building fire protection. According to the corresponding certification standards, the fire rating of Set Solar modules is Class C. INSTALLATION MANUAL FOR /setsolartr PHOTOVOLTAIC MODULES... -
Page 4: Limitation Of Liability
3. LIMITATION OF LIABILITY Set Solar is not responsible for any kind of damage, including but not limited to module operation and system installation error, and personnel injury, hurt, and property loss caused by failure to following the instructions in this Manual. -
Page 5: Label
1 and 2 are updated as items 9 and 10. 5. LABEL All Set Solar PV modules have two barcodes and one label. Nameplate: It is found on the back of the PV module. Specific information from datasheets exist in there . -
Page 6: Galvani Series Labeling
6.1. SITE SELECTION In most applications, Set Solar PV modules should be installed in a location where they will receive maximum sunlight throughout the year. Even minor partial shading reduces yields. A module can be considered to be unshaded if its entire surface is free from shading all year round. -
Page 7: Mounting
6.3. MOUNTING 6.3.1. MOUNTING USING FRAME BOLTS HOLES Each module must be securely fastened using a minimum of 4 mounting holes (9mm×14mm) at locations shown below. For maximum security against strong winds and heavy snow falls, all 10 mounting holes should be used to secure the module. -
Page 8: Clamp Mounting On Long Sides Of The Frames
6.3.2.1. CLAMP MOUNTING ON LONG SIDES OF THE FRAMES Mounting Rail Clamp Module Type Module Dimensions (AxB) J (mm) K (mm) VOLTA SERIES SETM60 1665x1002 VOLTA SERIES SETM72 1979x1002 VOLTA+ SERIES SETM120 1755x1038 VOLTA+ SERIES SETM144 2094x1038 GALVANİ SERIES SETT144 2278x1134 7. -
Page 9: Grounding
Accordingly, the values of Isc and Voc marked on this module should be multiplied by a factor of 1.25 when determining component voltage ratings, conductor ampacities, fuse sizes, and size of controls connected to the PV output. The maximum number of series connected modules depends on system design, the type of inverter used and environmental conditions.
